- Page 1 Installation manual ELITE NEW AUTOMATION FOR SWING GATES...
-
Page 3: Table Of Contents
Contents GENERAL SAFETY PRECAUTIONS ........................page 2. INTENDED USE AND APPLICATION ........................page ..........................page Kit contents ........................Technical features page ......................... Operator dimensions page 3. INSTALLATION ............................page Preliminary checks ........................ page Tools and materials (not included) ......................page Wiring ........................ -
Page 4: General Safety Precautions
Use only original spare parts. No alteration on the system has to be carried out. Proteco Srl will not respond in case of using additional and/or fake spares. INTENDED USE AND APPLICATION The ELITE NEW operator is designed to automate swing gates. -
Page 5: Technical Features
TECHNICAL FEATURES ELITE NEW 3 ELITE NEW 4 ELITE NEW 5 ELITE NEW 6 Motor power supply 24Vdc 230V~50Hz 115V~60Hz 24Vdc 230V~50Hz 115V~60Hz 230V~50Hz 24Vdc 230V~50Hz 115V~60Hz 230V~50Hz Max draw. 1,2-1,7A 2,0-2,3A 1,2-2A 2,0-2,3A 1,2-1,7A 2,0-2,3A 0,5-0,75A 0,5-0,75A 1,2-1,7A 0,5-0,75A... -
Page 6: Tools And Materials (Not Included)
TOOLS AND MATERIALS (NOT INCLUDED) PILLARS AND WALLS stainless steel concrete brick inox/alu. tubular Ø 15mm Ø 18mm LEAF wood stainless steel/alu 2 +2 12_2018... -
Page 7: Wiring
WIRING INSTALLATION OVERVIEW (pic. A) PROPERTY VIEW N.B.: The number of tubes and cables (not included in the kit) depends on the type of the accessories employed CABLES NEEDED 230V 3 x 1,5 mm² + Terra 2 x 1,5 mm² Control panel 2 x 1,5 mm²... -
Page 8: Installing The Operator
The ideal approach is to fix the brackets complying with the measures A and B as indicated in the below table for an opening angle of 90° (picture E). Elite New 3 = max 125 mm Elite New 4 = max 175 mm... -
Page 9: Outward Opening
3.3.2. CONSIGLI PER L’INSTALLAZIONE Tutti i collegamenti devono essere effettuati in assenza d’alimentazione. If this ideal scenario of A and B is not applicable, then refer to the below table to determine the brackets position (values are expressed in mm) Prevedere un dispositivo di sezionamento onnipolare nelle vicinanze dell’apparecchio (i contatti devono essere di almeno 3mm). -
Page 10: Pillar Bracket S1
3.4.3. PILLAR BRACKET S1 Anchor the pivot bracket S1 onto the pillar by welding or bolting (Ø 13 mm bolts) , making sure the quotas shown in the previous table are met. Ensure to keep a minimum distance of 30 mm from the pillar edge as shown in picture H. Pic. -
Page 11: Manual Release
Any form of guarantee provided here is strictly conditional upon compliance with the instructions for use and maintenance. The limited warranty does not apply when the goods are not PROTECO’S originals and the fault comes from an incorrect installation or is due to force majeure. - Page 12 Elite New 3, Elite New 4, Elite New 5, Elite New3 24, Elite New 4 24, Elite New 5 24, Elite New 3 115, Elite New 4 115, Elite New 5 115 electromechanical gear motor for swing gates comply the following Essential Requirements of Directive 2006/42/CE Annex I (Machinery directive): 1.1.2 1.1.3 1.1.5 1.2.1 1.2.2 1.2.3 1.2.6 1.3.2 1.3.4 1.3.9 1.4.1...
