BC4000 Series RAID Controllers

--default, -def

Splits an array using the default settings, no disks need be specified.

--array, -a

Array is a required qualifier used to specify arrays, where <list> identifies the array number(s).

--disk, -d

Disk is a required qualifier used to specify disks, where <list> identifies the disk number(s).
E
XAMPLES
Note: On Linux, anywhere that an asterisk (*) is used in a command as a wildcard argument, you
need to prevent shell expansion by either adding quotes around the asterisk (' or ") or preceding it
with a backslash (\).
Example 1:
Example 2:
Note: In example 2 above, equal numbers of disks must be selected from each mirror or submirror
for the split to occur.
Page 140 Splitting Mirrored Arrays: bcadm --split
Split a RAID10 array using the default option. Afterwards there will be
two arrays, and one will be hidden from the operating
system.
bcadm -S --array 1 --default
Split a RAID10n array into two arrays. The disks in the disk list will not
be split off from the original array.
bcadm -S --array 2 --disk 1 2 4 5 6 7 --no-hide
