- Page 1 Koko 3B/56 Instruction Manual Version: 2020 V1...
-
Page 3: Table Of Contents
Content Item Page No. 1. Safety Precaution 2. Parts & Accessories 3. Installation Instruction 4. Transmitter Function & Assembly 5. Power Supply Connection & Circuit Diagram 6. Maintenance 7. Technical Specifications 8. Customer Service Centre... -
Page 4: Safety Precaution
Safety Precaution WARNING Installation and maintenance work shall only be performed by qualified persons, familiar with local code and regulation, and experienced with this type of appliance. All field wiring must be installed in accordance with the national wiring regulation. Ensure that the rated voltage of the unit corresponds to that of the name plate before commencing wiring work according to the wiring diagram. - Page 5 Safety Precaution WARNING This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
- Page 6 Safety Precaution CAUTION Please take note of the following important points when installing. The fixing means for attachment to the ceiling such as hooks or other devices shall be fixed with a sufficient strength to withstand 4 times the weight of the ceiling fan. The mounting of the suspension system shall be performed by the manufacturer, its service agent or suitably qualified persons.
- Page 7 Safety Precaution CAUTION Before turning off the power supply set the remote controller’s ON/OFF switch to the “OFF” position. If this is not done, the unit’s fans will start turning automatically when power resumes, posing a hazard to service personnel or the user. Do not operate any heating apparatus too close to the ceiling fan unit or use in room where mineral oil, oil vapour or oil steam exist, this may cause plastic part to melt or deform as a result of excessive heat or chemical reaction.
-
Page 8: Parts & Accessories
Parts & Accessories Rubber Pulley Assembly x 1 Canopy x 1 Coupling Cover x 1 Motor Assembly With Downrod Receiver x 1... - Page 9 Parts & Accessories Blade x 3 Wall Screw x 2 Battery x 2 Blade Screw and Washer x 10 Transmitter & Holder x 1...
-
Page 10: Installation Instruction
Installation Instruction Safety Wire Assemble the Canopy and Coupling Cover through the Downrod. Canopy Downrod Coupling Cover... - Page 11 Installation Instruction Bolt Fix the Rubber Pulley Assembly to the Downrod with Bolt, Washer, Washer, Nut and tighten them Nut & firmly then insert the Clevis Pin. Clevis Pin IMPORTANT : CLEVIS PIN MUST BE INSERT TO PREVENT NUT FROM LOOSENING.
- Page 12 Installation Instruction Clevis Pin Rubber Pulley Remove the Bolt, Washer, Nut, Clevis Pin and Rubber Pulley from downrod. Washer Bolt Place the Rubber Pulley onto the ceiling hook and fix back the Bolt, Safety Wire Washer, Nut and Clevis Pin. IMPORTANT : CLEVIS PIN MUST BE INSERT TO PREVENT NUT FROM...
- Page 13 Installation Instruction Tie the Safety Wire across the hook as shown and firmly screw the Safety Wire onto the Downrod.
- Page 14 Installation Instruction House Supply Wires Brown (L) Green/Yellow (E) Blue (N) Connect the Connectors from Fan to Receiver. Green/Yellow (E) Brown (L) Grey Connect the wires from receiv- Blue (N) Pink er to House’s Supply Wire. Connect Earth Wire to House Receiver Supply Earth Terminal.
- Page 15 Installation Instruction IMPORTANT : ASSEMBLE THE BLADES ONLY AFTER THE CEILING FAN IS MOUNTED ON THE HOOK. Install the Blades on Motor with Blade Screw...
- Page 16 Installation Instruction Below shows a complete installation diagram...
- Page 17 Transmitter Learning Process The receiver & transmitter is pre-programmed in factory. If you wish to control 2 or more fans using 1 transmitter, the below steps are required. DO NOT PRESS ANY OTHER BUTTON DURING THIS PROCESS Turn on power to fan. Within 30 sec, press and hold Press and hold “- Timing”...
-
Page 18: Transmitter Function & Assembly
Transmitter Function Timer On Timing Timing Fan Speed Sleep Wind Baby Wind Natural Wind Turbo Wind Forward/Reverse The transmitter & receiver is incorporated with last memory function. This function stores your last setting in memory and the next time you turn on the fan, fan will operate as the last setting. - Page 19 Transmitter Function Timer On - To turn ON the fan at a preset time. 0.5hr 1.5hr ..9.5hr On standby mode, press to select the desire setting then press to confirm. Timing Timing Fan Speed - 1 - Lowest speed. 7 - Highest speed Natural Wind - Fan speed changes within its range creating gentle sea-breeze effect.
- Page 20 Function of Forward & Reverse Fan must be turned on and rotating. Fan will slow down and then change direction (approx. 15 sec). When the fan is slowing down to change direction, the Fan Speed function is disabled until direction has been changed. Forward Reverse Fan rotates anti-clockwise blowing...
- Page 21 Transmitter Assembly Install the Transmitter Holder to wall with the 2 Screws provided. Transmitter Holder...
- Page 22 Power Supply Connection IMPORTANT : DO NOT CONNECT THIS REMOTE CONTROL CEILING FAN TO REGULATOR OR DIMMER SWITCH. Regulator Dimmer Switch Double Pole Switch 220-240V~ 50Hz Power Supply Earth Single Pole Switch...
- Page 23 Circuit Diagram Motor ANT1 MAIN PCB Blue Neutral (Blue) Brown Live (Brown) Power Supply 220-240V~ 50Hz Green/Yellow Earth (Green/Yellow)
-
Page 24: Maintenance
Maintenance Due to the fan’s natural movement, connections may get loose after a period of usage. To ensure a proper and safety usage, it is highly recommended to inspect and tighten all connections every 6 months. Cleaning Cleaning your fan periodically will prolong its new appearance. Basic cleaning procedures are as follows : 1. -
Page 25: Technical Specifications
Technical Specifications Koko-3B/56 MODEL No. of Blades 56” Fan Width 70 - 185 Motor RPM Voltage 220-240V~ 50Hz Motor Wattage 4W - 48W Nett Weight 5.4 kg Information may subject to 5% variation. - Page 26 Technical Specifications 287mm 400mm (11”) (1’ 4”) More than 1m 1420mm (4’ 8”)
- Page 27 Customer Service If you need any technical assistance or faulty report, please contact our customer service centre at : ALPHA HOME APPLIANCES SDN. BHD. (390258-H) Head Office Perak 6, Jalan Sungai Kayu Ara 32/37, Berjaya Park, 16, Jalan Tasek Timur, Section 32, 40460 Shah Alam, Selangor.
