- Page 1 Axis 3B/56 Instruction Manual Version: 2021 (SIN)
-
Page 3: Table Of Contents
Content Item Page No. 1. Safety Precaution 2. Parts & Accessories 3. Installation Instruction 4. Transmitter Function & Assembly 5. Power Supply Connection & Circuit Diagram 6. Maintenance 7. Technical Specifications 8. Customer Service Centre... -
Page 4: Safety Precaution
Safety Precaution WARNING Installation and maintenance work shall only be performed by qualified persons, familiar with local code and regulation, and experienced with this type of appliance. All field wiring must be installed in accordance with the national wiring regulation. Ensure that the rated voltage of the unit corresponds to that of the name plate before commencing wiring work according to the wiring diagram. - Page 5 Safety Precaution WARNING Tighten the blade firmly using a screw driver. Blades that are detached from the unit during operation will cause serious injuries and property dam- ages. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
- Page 6 Safety Precaution CAUTION Please take note of the following important points when installing. The fixing means for attachment to the ceiling such as hooks or other devices shall be fixed with a sufficient strength to withstand 4 times the weight of the ceiling fan. The mounting of the suspension system shall be performed by the manufacturer, its service agent or suitably qualified persons.
- Page 7 Safety Precaution CAUTION Before turning off the power supply set the remote controller’s ON/OFF switch to the “OFF” position. If this is not done, the unit’s fans will start turning automatically when power resumes, posing a hazard to service personnel or the user. Do not operate any heating apparatus too close to the ceiling fan unit or use in room where mineral oil, oil vapour or oil steam exist, this may cause plastic part to melt or deform as a result of excessive heat or chemical reaction.
-
Page 8: Parts & Accessories
Parts & Accessories Notch Ball x 1 Canopy & Canopy Cover x 1 Mounting Bracket Connecting Ring x 1 Motor Assembly Receiver x 1 With Downrod & Coupling Cover x 1 Decorative Cover x 1... - Page 9 Parts & Accessories Blade x 3 Wall Screw x 2 Blade Screw x 7 Battery x 2 Transmitter Expansion & Holder x 1 Expansion Screw x 4 ‘J’ x 1 Connecting Ring Screw x 4...
-
Page 10: Installation Instruction
Installation Instruction Safety Wire Assemble the Notch Ball, Canopy, Canopy Cover and Coupling Cover through the Downrod. Notch Ball Canopy Canopy Cover Downrod Current carrying wires Coupling Cover Locking pin Cross bolt Motor shaft Locking nut Insulating sleeve Safety cord Earth wire... - Page 11 Installation Instruction Expansion Screw Expansion ‘J’ Hook Mounting Bracket Drill the 4 Expansion Screws and 1 Expansion ‘J’ Hook provided to the concrete ceiling. Align the slotted holes in the Mounting Bracket with the Expansion Screws and secure with the washer and nuts. IMPORTANT : THE EXPANSION SCREWS, EXPANSION ‘J’...
- Page 12 Installation Instruction Mounting Bracket Indent Notch Notch Ball Safety Wire Raise the fan and place the Notch Ball into the Mounting Bracket. Align the notch on the Notch Ball with the indent in the Mounting Bracket until you hear the Notch pop into place. Hook the Safety Wire onto the Expansion ‘J’...
- Page 13 Installation Instruction House Supply Wire Insert the receiver into the Brown (L) canopy and store all wires Green/Yellow (E) Blue (N) neatly. Orange Blue Green/Yellow(E) Brown (L) Blue (N) White White Yellow Yellow Grey Grey Green/Yellow(E) VIEW AFTER INSTALLATION Connect the Connectors from Fan and Receiver. Connect the wires from the Receiver t Connect Earth Wire to House Supply Earth Terminal.o House’s Supply Wire.
- Page 14 Installation Instruction IMPORTANT : ASSEMBLE THE BLADES Step 6a ONLY AFTER THE CEILING FAN IS MOUNTED ON THE HOOK. a. Install the Blades on Motor with Blade Screw. b. Install the Connecting Ring Step 6b with Connecting Ring Screw. c. Install the Decorative Cover by twisting in.
- Page 15 Installation Instruction Below shows a complete installation diagram...
- Page 16 Transmitter Learning Process The receiver & transmitter is pre-programmed in factory. If you wish to control 2 or more fans using 1 transmitter, the below steps are required. DO NOT PRESS ANY OTHER BUTTON DURING THIS PROCESS Transmitter Turn on power to fan. Within 30 sec, press and hold “LEARN”...
-
Page 17: Transmitter Function & Assembly
Transmitter Function Power Turn off fan Fan Speed 1 - Lowest speed 8 - Highest speed Natural Wind Fan speed changes within Forward/Reverse its range creating gentle Anti-clockwise or sea-breeze effect clockwise rotation Timer On 1h - Fan turns on after 1 hour 3h - Fan turns on after 3 hours 6h - Fan turns on after 6 hours 8h - Fan turns on after 8 hours... - Page 18 Function of Forward & Reverse Fan must be turned on and rotating. Press and hold Forward/Reverse button for 3 sec. Fan will slow down and then change direction (approx. 15 sec). When the fan is slowing down to change direction, the Fan Speed function is disabled until direction has been changed.
- Page 19 Transmitter Assembly Install the Transmitter Holder to wall with the 2 Screws provided. Transmitter Holder...
-
Page 20: Power Supply Connection & Circuit Diagram
Power Supply Connection IMPORTANT : DO NOT CONNECT THIS REMOTE CONTROL CEILING FAN TO REGULATOR OR DIMMER SWITCH. Regulator Dimmer Switch 220-240V~ 50Hz Power Supply Double Pole Switch Earth Single Pole Switch... - Page 21 Circuit Diagram Motor ANT1 MAIN PCB Blue Neutral (Blue) Brown Live (Brown) Power Supply 220-240V~ 50Hz Green/Yellow Earth (Green/Yellow)
-
Page 22: Maintenance
Maintenance Due to the fan’s natural movement, connections may get loose after a period of usage. To ensure a proper and safety usage, it is highly recommended to inspect and tighten all connections every 6 months. Cleaning Cleaning your fan periodically will prolong its new appearance. Basic cleaning procedures are as follows : 1. -
Page 23: Technical Specifications
Technical Specifications AXIS-3B/56 MODEL No. of Blades Fan Width 56” Motor RPM 90 - 220 Voltage 220-240V~ 50Hz Motor Wattage 5W - 38W Nett Weight 5.5 kg Information may subject to 5% variation. - Page 24 Technical Specifications 184mm 274mm (7”) More than 1m (11”) 1422mm (4” 8”)
-
Page 25: Customer Service Centre
Customer Service If you need any technical assistance faulty report, please contact our customer service centre at : Alpha Sales & Services Pte. Ltd. (200709461 R) 50, Ubi Avenue 3, #02-16/17, Frontier, Singapore 408866. : +65 6841 0111 : +65 6747 0030 Website : www.alphasingapore.com Email...
