Summarization of Contents
General Description
Detector
Details the sensing element, response temperature, and category for the heat detector types.
Latching
Explains the detector's latching behavior and LED indication when an alarm condition occurs.
External LED
Describes how to connect an external indicator (LED) to the detector's terminals.
Connection Box
Notes that the connection box is prepared for the required number of compression glands.
Zone Line Input
Explains the connection of the conventional detector to a CIE zone line input.
Installation and Wiring
Common Installation (6295-6298)
Details common installation wiring, including screen wire termination and wire size specifications.
Intrinsically Safe Installation (6295-6296)
Explains intrinsically safe installation methods using galvanic isolator/barrier units.
Rating Label
Describes the serial number indication on the rating label for types 6295/6296.
Cable Gland
Specifies the included cable gland and its compatible wire size range.
