ILVE Quadra User Instructions, Installation, Maintenance

U s e r I nst r uct i on s, In s ta lla ti on , ma in ten an c e fo r
Ma jestic • Prof e s s i o na l • Qu ad r a Ma j estic • Profe s s io n a l • Qu ad r a
C o o k e r s c h a ra ct eri st i cs
These warnings refer to different models of cookers.
Be sure that you have correctly identifiedthe model that you possess (see the data plate).
MODEL
UP60
UP76
UM76
UP90, UPD90
UM90
UPD100
UQM100
UMD100
UP120,UPD120
UM120
UP150
UM150
cod. I/301/89
• C O O K E R S •
DIMENSIONS
23 5/8" (W) x 23 5/8" (D) x [33 15/32"- 35 53/64"] (H)
29 7/8" (W) x 23 5/8" (D) x [33 15/32" - 35 53/64"] (H)
29 7/8" (W) x 27 9/16" (D) x [34 1/4"- 36 20/32"] (H)
35 7/16" (W) x 23 5/8" (D) x [33 15/32"- 35 53/64"] (H)
35 7/8" (W) x 27 9/16" (D) x [34 1/4"- 36 20/32"] (H)
39 3/8" (W) x 23 5/8" (D) x [33 15/32"- 35 53/64"] (H)
39 3/8" (W) x 25 19/32" (D) x [34 1/4"- 36 20/32"] (H)
39 3/8" (W) x 27 9/16" (D) x [34 1/4"- 36 20/32"] (H)
47 1/4" (W) x 23 5/8" (D) x [33 15/32"- 35 53/64"] (H
47 7/8" (W) x 27 9/16" (D) x [34 1/4"- 36 20/32"] (H)
59 1/16" (W) x 23 5/8" (D) x [33 15/32"- 35 53/64"] (H)
59 1/2" (W) x 27 9/16" (D) x [34 1/4"- 36 20/32"] (H)
10/2016
