SUPERTERM-4
CICP1400UL 4-Door Intelligent Controller
The four-reader Superterm (CICP1400UL) supports
4 readers and has 16 inputs, 1 tamper alarm and 9
outputs. A locking steel enclosure, power supply and
battery are included.
Superterm-4 is an expandable intelligent controller capable of
supporting all access control functions for one to four doors. This
distributed processor-based panel will operate as a standalone
unit in the event server-communications are interrupted. The
Superterm is programmed via Continental Instruments (CIC)
CardAccess ® software program, a Windows-based access control
and security management solution. Once programmed, the
controller does not require continuous server communications,
as it automatically stores system transactions in its internal
memory. The Superterm's memory is field expandable, allowing
for greater cardholder populations and/or a larger transaction
buffer. The controller's Flash EPROM firmware is easily
upgraded when additional features or system enhancements
are required. All Continental Instrument's controllers feature
extensive multi-stage lightning/transient protection on-
board for maximum reliability even in harsh environments.
The Superterm accepts industry standard Wiegand output devices
and supports virtually all card/reader technologies. Proximity,
Biometric, Magnetic Stripe, Barcode, Wiegand, Barium Ferrite,
Keypad and Smart Readers are easily connected and controlled.
The Superterm can store multiple card (bit) formats in its internal
memory, making it a cost-effective retrofit panel. Supporting
multiple bit formats allows existing card populations and readers
to remain in place.
Continental Instruments, A Napco Security Group Company
(631) 842-9400
Up to 63 CIC Intelligent Controllers (Microterm, Miniterm,
Smarterm or Superterm) can be intermixed on the same
communications network. Multiple communication networks
(ports) can be connected to the CardAccess ® server for maximum
system expansion. Controller communication choices include:
hardwire (repeat or multi-drop mode), LAN/WAN, dial-up or
fiber optics for maximum flexibility. Continental Instruments
supports RS232, RS422 and RS485 communication formats for
optimal system configuration.
In addition to memory and power expansion capabilities, the
Superterm will accept up to 3 input/output expansion boards.
The Superterm can be ordered with the expansion boards pre-
installed at the factory. The boards can also be ordered separately
and field installed within the Superterm enclosure. The boards
are mounted to the inside of the hinged enclosure cover. The
Alarm Expander Board provides 16 supervised inputs while
the Relay Expander Board provides 16 relay outputs and 8
unsupervised inputs.
Cards
Readers (5-wire)
Keypads (5-wire)
Keypads (7-wire)
Readers
w/Keypad
Standard
Inputs
Expanded
Inputs
Standard
Outputs
Expanded
Outputs
Transaction
Buffer
Time Schedules
Access Groups
Holidays
Reader Power
Battery Backup
Enclosure
UL Listings
**UL1950 replaced with EN60950 in Q2/2003
•
FAX (631) 842-9135 www.cicaccess.com GSA GS-07F-00039H
Superterm-4 Capacities
20,000 standard (exp. to 145,000)
4 (Wiegand output)
4 (Wiegand output)
4 X-Y Matrix type
4 5-wire Readers with 8 or 4 X-Y Matrix Keypads
16 (Supervised)
48 Additional inputs (Supervised)
9 Form C rated at 3A@24VDC/VAC
48 Additional Form C rated at 3A@24VDC/VAC
1000 Standard (exp. to 30,000)
128
1000
50
800mA@5VDC, 500mA@12VDC
4-6 hours included
Size 21.5"H x 21.25"W x 7"D, 48lbs.
UL294, UL1076, UL1950**
•
355 Bayview Ave., Amityville, NY 11701
