Continental Instruments CICP1400 Datasheet

SMARTERM
CICP1400 4-Door Intelligent Controller
The standard Smarterm has 16 inputs, 1 tamper alarm
and 9 outputs. A locking steel enclosure, power supply
and battery are included.
Smarterm is an expandable intelligent controller capable of
supporting all access control functions for one to four doors. This
distributed processor-based panel will operate as a standalone
unit in the event server communications are interrupted. The
Smarterm is programmed via Continental Instruments (CIC)
CardAccess software program, a Windows-based access control
and security management solution. Once programmed, the
controller does not require continuous server communications,
as it automatically stores system transactions in its internal
memory. The Smarterm's memory is field expandable, allowing
for greater cardholder populations and/or a larger transaction
buffer. Continental's controllers feature extensive multi-stage
lightning/transient protection on-board for maximum reliability
even in harsh environments.
The Smarterm accepts industry standard Wiegand output devices
and supports virtually all card/reader technologies. Proximity,
Biometric, Magnetic Stripe, Barcode, Wiegand, Barium Ferrite,
Keypad and Smart Readers are easily connected and controlled.
The Smarterm can store multiple card (bit) formats in its internal
memory, making it a cost-effective retrofit panel. Supporting
multiple bit formats allows existing card populations and readers
to remain in place. In addition to the rechargeable standby
battery, each Smarterm includes a lithium battery for up to one
year of data protection.
Continental Instruments, A Napco Security Group Company
(631) 842-9400
Up to (63) CIC Intelligent Controllers (Microterm, Miniterm,
Smarterm or Superterm) can be intermixed on the same
communications network. Multiple communication networks
(ports) can be connected to the CardAccess ® server for maximum
system expansion. Controller communication choices include:
hardwire (repeat or multi-drop mode), LAN/WAN, dial-up or
fiber optics for maximum flexibility. Continental Instruments
supports RS232, RS422 and RS485 communication formats for
optimal system configuration.
Cards
Readers (5-wire)
Keypads (5-wire)
Keypads (7-wire)
Readers
w/Keypad
Standard
Inputs
Expanded
Inputs
Standard
Outputs
Expanded
Outputs
Transaction
Buffer
Time Schedules
Access Groups
Holidays
Reader Power
Battery Backup
Enclosure
• FAX (631) 842-9135 www.cicaccess.com GSA GS-07F-00039H
Smarterm Capacities
2500 standard (exp. to 120,000)
4 (Wiegand output)
4 (Wiegand output)
4 X-Y Matrix type
4 5-wire Readers with 8 or 4 X-Y Matrix Keypads
16 (Unsupervised)
64 Additional inputs (Supervised)
9 Form C rated at 3A@24VDC/VAC
64 Additional Form C rated at 3A@24VDC/VAC
1000 Standard (exp. to 30,000)
128
1000
50
200mA@5VDC
4-6 hours included
Size 20.75"H x 16.4"W x 4.7"D, 22lbs.
• 355 Bayview Ave., Amityville, NY 11701
