MINITERM
CICP1200 2-Door Intelligent Controller
The Miniterm (CICP1200) has 8 inputs, 1 tamper
alarm and 5 outputs. A locking steel enclosure, power
supply and battery are included.
Miniterm is an intelligent controller capable of supporting all
access control functions for one to two doors. This distributed
processor-based panel will operate as a standalone unit in the
event server communications is interrupted. The Miniterm is
programmed via Continental Instruments (CIC) CardAccess
software program, a Windows-based access control and
security management solution. Once programmed, the
controller does not require continuous server communications,
as it automatically stores system transactions in its internal
memory.
Up to 63 CIC Intelligent Controllers (Microterm, Miniterm,
Smarterm or Superterm) can be intermixed on the same
communications network. Multiple communication networks
(ports) can be connected to the CardAccess ® server for
maximum system expansion. Controller communication
choices include: hardwire (repeat or multi-drop mode), LAN/
WAN, dial-up or fiber optics for maximum flexibility. The
Miniterm supports RS232 and RS422 communication formats
for optimal system configuration.
Continental Instruments, A Napco Security Group Company
(631) 842-9400
The Miniterm accepts industry standard Wiegand output
devices and supports virtually all card/reader technologies.
Proximity, Biometric, Magnetic Stripe, Barcode, Wiegand,
Barium Ferrite, Keypad and Smart Readers are easily
connected and controlled. The Miniterm can store multiple card
(bit) formats in its internal memory, making it a cost-effective
retrofit panel. Supporting multiple bit formats allows existing
card populations and readers to remain in place. The Miniterm
contains a 2.4AH rechargeable standby battery, providing 4-6
hours standby. In addition to the rechargeable standby battery,
each Miniterm includes a lithium battery for up to one year of
data protection.
This Intelligent Controller is UL Listed for UL294 (Access
Control System Unit), UL1076 (Proprietary Burglar Alarm
Unit) and UL1950 (Information Technology Equipment).**
Cards
Readers (5-wire)
Keypads (5-wire)
Keypads (7-wire)
Readers
w/Keypad
Standard
Inputs
Expanded
Inputs
Standard
Outputs
Expanded
Outputs
Transaction
Buffer
Time Schedules
Access Groups
Holidays
Reader Power
Battery Backup
Enclosure
UL Listings
** UL1950 replaced with EN60950 in Q2/2003
• FAX (631) 842-9135 www.cicaccess.com GSA GS-07F-00039H
Miniterm Capacities
3300 standard
2 (Wiegand output)
2 (Wiegand output)
2 X-Y Matrix type
2 5-wire Readers with 2 or 4 X-Y Matrix Keypads
8 (Supervised)
N/A
5 Form C rated at 3A@24VDC/VAC
N/A
1000
128
1000
50
200mA@5VDC, 200mA@12VDC
4-6 hours included
Size 15.25"H x 12.5"W x 4"D, 18lbs.
UL294, UL1076, UL1950**
