Continental Instruments CICP1100 Datasheet

Single door intelligent controller

Advertisement

Quick Links

MICROTERM
CICP1100 Single Door Intelligent Controller
The Microterm (CICP1100) has 2 inputs, 1
tamper alarm and 3 outputs, and is housed
in a steel enclosure.
Microterm is a single-door intelligent controller designed to be
installed at or near the protected door. The Microterm is capable
of controlling all access control functions for one door, including
two-reader support. The two-reader configuration is generally
used for in-reader and out-reader applications. It is possible
to use the Microterm's 2-reader configuration on two separate
doors with certain limitations. This distributed processor-based
panel will operate as a standalone unit in the event server
communications is interrupted. The Microterm is programmed
via CIC CardAccess® software program. Once programmed, the
controller does not require continuous server communications, as
it automatically stores system transactions in its internal memory.
The Microterm (CICP1100) has 2 inputs, 1 tamper alarm and 3
outputs, and is housed in a steel enclosure.
The Microterm accepts industry standard Wiegand output devices
and supports virtually all card/reader technologies. Proximity,
Biometric, Magnetic Stripe, Barcode, Wiegand, Barium Ferrite,
Keypad and Smart Readers are easily connected and controlled.
The Microterm can store multiple card (bit) formats in its internal
memory, making it a cost-effective retrofit panel. Supporting
multiple bit formats allows existing card populations and readers
to remain in place. An optional standby battery is available,
providing 4-6 hours standby power. The Microterm includes a
lithium battery for up to one year of data protection.
Continental Instruments, A Napco Security Group Company
(631) 842-9400
Up to 63 CIC Intelligent Controllers (Microterm, Miniterm,
Smarterm or Superterm) can be intermixed on the same
communications network. (A maximum of 31 Microterms
are permitted on each network.) Multiple communication
networks (ports) can be connected to the CardAccess ® server for
maximum system expansion. Controller communication choices
include: hardwire (repeat or multi-drop mode), LAN/WAN,
dial-up or fiber optics for maximum flexibility. The Microterm
supports RS232 and RS422 communication formats for optimal
system configuration.
This Intelligent Controller is UL Listed for UL294 (Access
Control System Unit), UL1076 (Proprietary Burglar Alarm Unit)
and UL1950 (Information Technology Equipment).**
Cards
Readers (5-wire)
Keypads (5-wire)
Keypads (7-wire)
Readers
w/Keypad
Standard
Inputs
Expanded
Inputs
Standard
Outputs
Expanded
Outputs
Transaction
Buffer
Time Schedules
Access Groups
Holidays
Reader Power
Battery Backup
Enclosure
UL Listings
** UL1950 replaced with EN60950 in Q2/2003
FAX (631) 842-9135 www.cicaccess.com GSA GS-07F-00039H
Microterm Capacities
1400 standard
1 or 2 (Wiegand output)
1 or 2 (Wiegand output)
1 X-Y Matrix type
1 5-wire Reader with 1 X-Y Matrix Keypads
2 (Supervised)
N/A
3 Form C rated at 3A@24VDC/VAC
N/A
1000 Standard (exp. to 30,000)
128
1000
50
100mA@5VDC
4-6 hours (optional)
Size 7.5"H x 7.5"W x 2"D, 2lbs.
UL294, UL1076, UL1950**
355 Bayview Ave., Amityville, NY 11701
