- Page 1 Operating personnel Assembly and Operating Instructions High Pressure Cleaner cold water, mobile Series KD 4x4 KD1140 Premium KD1340 Premium KD1840 Premium KD1540 Premium KD1140 Standard KD1340 Standard KD2040 Premium...
- Page 2 Declaration of Conformity Manufacturer: Ehrle GmbH Adress: Industriestraße 3 D – 89165 Dietenheim Standard: KD1140, KD1340 Product: Premium: KD1140, KD1340, High Pressurce Cleaner cold water, mobile Series 4x4 KD1840, KD1540, KD2040 The product given below is in conformity with the European Directives:...
-
Page 3: Table Of Contents
Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 Table of content User information General ............................... 5 Functional device concept ........................ 5 Terminology ............................6 Meaning of the emphasis ......................... 6 Meaning of the symbols ........................7 Target groups............................. 9 Warranty and Liability........................ - Page 4 7.1.2 Device version Premium ........................34 Decommissioning for a longer period of time ................35 Maintenance General Information ........................36 EHRLE Maintenance and Inspection Contract ................36 Maintenance work .......................... 36 8.3.1 Frost Protection ..........................38 8.3.1.1 Drain water from high pressure cleaner ..................38 8.3.1.2...
-
Page 5: User Information
General General information For a comprehensive advice and information on the High Pressure Cleaner cold water, mobile - Series 4x4 please contact the EHRLE Customer Service. With the purchase of a EHRLE High Pressure Cleaner cold water, mobile - Series 4x4 you are the owner of a quality product, which is characterised by: ●... -
Page 6: Terminology
Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 Terminology In this manual the terminology listed below is replaced by the relevant short terms whenever possible ● High Pressure Cleaner cold water, mobile - Series 4x4 high pressure cleaner or device ●... -
Page 7: Meaning Of The Symbols
Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 Meaning of the symbols Symbol Meaning WARNING Follow instructions! Non-observance or neglecting of prescribed instructions, incorrect operation or misuse of the device may endanger life and limb of persons. WARNING Danger of death due to electric shock. - Page 8 Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 Symbol Meaning General Information General additional information. Information on recycling General information on recycling. Information on disposal General information on the proper and en- vironmentally sound disposal of materials and consumables.
-
Page 9: Target Groups
This Operating Instruction contains information and instructions for operating personnel for carrying out general cleaning work. Warranty and Liability The EHRLE High Pressure Cleaner cold water, mobile - Series 4x4 may only be used for its intended purpose. Intended use includes: ●... -
Page 10: Environmental Protection
Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 Environmental protection Note on recycling The packaging materials are recyclable. Please do not throw the packaging into the household waste, but recycle it. Note on disposal Old appliances contain valuable recyclable materials which should be recycled. -
Page 11: Safety
Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 Safety General safety information Observe the respective national regulations of the legislator for liquid sprayers. Observe the relevant national regulations of the legislator on accident prevention. Liquid sprayers must be inspected regularly and the result of the inspection must be recorded in writing. -
Page 12: Accident Prevention Regulations
If the sound levels exceed the permissible values, the personnel and persons in the area of exposure must wear hearing protection. The sound level for EHRLE high pressure cleaners under maximum load is 82 dB (A). A high sound level over a long period can cause hearing loss. If... -
Page 13: Periodic Inspections
In the appendix of this manual there is a test sheet (proof of customer service) to record the tests carried out. EHRLE service technicians are experts and can be consulted and commissioned by EHRLE service for this prescribed inspection. Design changes to the device Design changes to the high pressure cleaner are not permitted. -
Page 14: Product Description
Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 Product description Product data sheet High Pressure Cleaner Cold water, mobile - Series 4x4 KD1140 High Pressure Cleaner Cold water, mobile - Series 4x4 KD1140 Type KD1140-Standard KD1140-Premium Voltage 3/PE/AC/50Hz/400V ►... -
Page 15: Product Data Sheet Kd1340
Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 High Pressure Cleaner High Pressure Cleaner Cold water, mobile - Series 4x4 KD1340 Cold water, mobile - Series 4x4 KD1140 Type KD1140-Standard KD1140-Premium Voltage 3/PE/AC/50Hz/400V ► 10m HP-Hose DN08 - 315bar ►... -
Page 16: Product Data Sheet Kd1840
Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 High Pressure Cleaner Cold water, mobile - Series 4x4 KD1840 High Pressure Cleaner Cold water, mobile - Series 4x4 KD1840 Type KD1840-Premium Voltage 3/PE/AC/50Hz/415V ► Hose-Reel ► 20 m HP-Hose DN08 - 315bar Operating pressure 30-120bar/3-12MPa ►... -
Page 17: Product Data Sheet Kd1540
Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 High Pressure Cleaner High Pressure Cleaner Cold water, mobile - Series 4x4 KD1540 Cold water, mobile - Series 4x4 KD1840 Type KD1840-Premium Voltage 3/PE/AC/50Hz/415V ► Hose-Reel ► 20 m HP-Hose DN08 - 315bar Operating pressure 30-120bar/3-12MPa ►... -
Page 18: Product Data Sheet Kd2040
Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 High Pressure Cleaner Cold water, mobile - Series 4x4 KD2040 High Pressure Cleaner Cold water, mobile - Series 4x4 KD2040 Type KD2040-Premium Voltage 3/PE/AC/50Hz/415V ► Hose-Reel ► 20 m HP-Hose DN08 - 315bar Operating pressure 30-220bar/3-22MPa ►... -
Page 19: Device Assembly
For loads of more than 23 kg, use suitable lifting equipment (e.g. forklift, lift truck). General Information For detailed advice and information on the device assembly of the High Pressure Cleaner cold water, mobile - Series 4x4, please contact the EHRLE customer service. 19 of 46... -
Page 20: Commissioning
For commissioning, operators must follow the instructions in this section. Otherwise the life and limb of persons may be endangered. The Ehrle high pressure cleaners are subjected to a final test for correct function and safety before delivery. The first commissioning and the first cleaning operation serve to check the correct functioning of the device, if damage to components that is not immediately visible during transport has occurred. -
Page 21: Establishing The Water Connection
Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 Establishing the water connection CAUTION Do not operate the device with contaminated or too hot water. Operate the high pressure cleaner only with clear and unpolluted water. The water inlet temperature to the device may be as follows ●... -
Page 22: Establishing The Electrical Mains Connection
Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 Establishing the electrical mains connection WARNING Ensure that the electrical connection is properly installed. Only connect the device to voltage sources earthed in accordance with the safety regulations (mains connection of buildings or mains junction box e.g. -
Page 23: Commissioning The Device
Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 Commissioning the device For commissioning the device proceed as follows: Open the water supply from the tap water network via the shut-off valve. Switch on the mains voltage via the main switch or circuit breaker of the mains connection (e.g. -
Page 24: Operation
Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 Operation Control elements of the trigger gun The following figure shows the control elements of the trigger gun. To assemble (disassemble) the spray lance to the (from the) trigger gun see arrows in the figure below. -
Page 25: Emergency Stop - Switch-Off In Case Of Danger
Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 EMERGENCY STOP - Switch-off in case of danger WARNING In case of electrical accidents, never directly touch persons exposed life-threatening voltages. In the event of accidents with persons at life-threatening voltages, im- mediately switch off the supply voltage to the high pressure cleaner or disconnect the power supply cable from the infrastructure mains plug. - Page 26 Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 To carry out cleaning work, proceed as follows: Unlock and pull the trigger lever (4, Fig. 6-2) of the trigger gun. WARNING Before activating, hold the trigger gun and the spray lance tightly. After activation of the trigger gun the emerging water jet exerts a jerky recoil force (see also Fig.
- Page 27 Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 Set device switch 0/I (3, Fig. 6 - 1) into position I. The high pressure cleaner starts. The pump first delivers air from the high pressure nozzle. After a short time, water then escapes. ...
-
Page 28: Operation With Cleaning Detergent (Chemistry)
Operation with cleaning detergent (chemistry) WARNING Only use permitted detergents. Only use cleaning detergents approved by the manufacturer EHRLE. The use of inadmissible detergents can endanger the operational safety of the device and thus the life and limb of persons. -
Page 29: Cleaning Detergent Operation With Version Standard
Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 6.4.2 Cleaning detergent operation with version Standard CAUTION Chemical dry run or inadmissible detergents can damage the device. Before starting cleaning detergent operation, make sure that the cleaning agent container is sufficiently filled with cleaning agent. Intake air or inadmissible causes damage to seals and pumps. -
Page 30: Cleaning Detergent Operation With Version Premium
Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 Adjustment controller for setting the quantity of cleaning detergent Fig. 6 - 4 Adjustment controller for quantity of cleaning detergent (Version Standard) 6.4.3 Cleaning detergent operation with version Premium CAUTION Chemical dry run or inadmissible detergents can damage the device. -
Page 31: Special Application Of Detergent Agents For Food Appliance (Only Version Premium)
Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 To remove the dirt, spray on the detergent sparingly onto the cleaning object and let it work for approx. one to five minutes. Then spray the loosened dirt with the high pressure jet. ... - Page 32 Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 Fig. 6 - 5 Attachment of SoftFoam KIT HP with 2 l bottle to trigger gun Adjustment controller for dosage of additional chemistry 2 l bottle for additional chemistry (food appliance) Fig.
-
Page 33: Decommissioning
Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 Decommissioning General Information Provide a frost sheltered location for the high pressure cleaner as well as all accessories (trigger gun, spray lance, water inlet hose, etc.) for ● temporary storage until the next operation or ●... -
Page 34: Device Version Premium
Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 Remove the HP-Hose from the high pressure outlet (pump). Wind up the power cable on the device holder. Roll up HP-Hose. Stow the accessories on the device holdings provided. 7.1.2 Device version Premium After completion of cleaning work for temporary decommissioning until... -
Page 35: Decommissioning For A Longer Period Of Time
Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 Decommissioning for a longer period of time If the high pressure cleaner is to be taken out of operation for a longer period of time, refer to Section 7.1 and take it out of operation. Store the device in a frost-protected room. -
Page 36: Maintenance
● Achieving a long service life. ● Maintaining the performance. EHRLE Maintenance and Inspection Contract With the sale of the high pressure cleaner the manufacturer EHRLE offers a maintenance contract or especially a safety inspection agreement. The maintenance contract includes: ●... - Page 37 Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 Period Component Measure Authorized personnel Daily Trigger gun Check if trigger gun closes tightly; check Trained operator function of mechanical locking to prevent unintentional switch-on; replace defective trigger gun. HP-Hoses Check the HP-Hoses (see Section 8.3.3).
-
Page 38: Frost Protection
Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 8.3.1 Frost Protection For optimum protection, operate or store the device in a frost-protected area. If the device is exposed to temperatures below freezing point during temporary or prolonged decommissioning (e.g. storage in warehouse), frost protection must be provided (see Section 8.3.1.1 and Section 8.3.1.2). -
Page 39: Checking The Hp-Hoses
Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 8.3.3 Checking the HP-Hoses WARNING Operation with worn, damaged or repaired HP-Hoses can endanger life and limb of persons. Ensure that HP-Hoses are removed immediately in the case of: ● Signs of wear. ●... -
Page 40: Troubleshooting
Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 Troubleshooting WARNING Carry out troubleshooting and rectification properly. Troubleshooting of the high pressure cleaner may only be carried out by trained and qualified personnel. Before troubleshooting inside the high pressure cleaner, take the device out of operation and disconnect it from the mains connection of the building or mains junction box (e.g. - Page 41 Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 Error Possible cause Remedying Authorized personnel Device Motor of high pressure Allow motor to cool down, set Trained operator switched off cleaner overheated. device switch into position 0, during then switch on again (into operation position I).
- Page 42 Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 Error Possible cause Remedying Authorized personnel No pressure High pressure nozzle dirty or Clean or replace high pressure Trained operator build-up with defective. nozzle high pressure cleaners Filter in water inlet dirty. Clean the filter, see Section 8.3.2.
- Page 43 Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 43 of 46...
- Page 44 KD823 Std./Prem. KD940 Std. KD940 Prem.hh □ □ □ KD940 Food Std./Prem. KD623 UK Std./Prem. Test report EHRLE HIGH-PRESSURE-CLEANER KD823 UK Std./Prem. Name der Prüfperson: Name of the Test-Engineer: □ □ Prüfspannung KD623/823: AC 230V-50Hz KD940/KD940 F: 3AC 400V-50Hz □...
- Page 45 Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 Certificate Page 2 of 2 Zulässige Aufnahmeleistung Motor in A.: KD623 Std/Prem: BG90 2,2kW AC230 14,5 A KD823 Std/Prem: BG100 2,6kW AC230 15,5 A KD940 Std/Prem: 9,1 A BG100 4kW AC400 Max.
- Page 46 Operating Instruction High Pressure Cleaner cold water, mobile Series 4x4 Proof of customer service Device type: Manufacture no.: Commissioning on: Inspection carried out on: Findings: Signature Inspection carried out on: Findings: Signature Inspection carried out on: Findings: Signature Inspection carried out on: Findings: Signature 46 of 46...
