Page 3
Control Locations Telescopic Antenna Display (L.C.D) Display illuminated button (LIGHT) Power on/off button Sleep (auto shut off) button Display button Standby button (ALARM) Alarm by radio or buzzer selection Manual/auto scan tuning buttons 10. Enter command button for frequency and time. 11.
Page 4
Choosing a power supply This radio can be operated using 4 Alkaline UM-3 (LR6) (AA size) batteries Household AC adaptor (not supplied) Installing batteries 1.Position the radio face down. 2.Press the catch marked "OPEN" and side in the direction shown 3.Insert the 4 UM-3 (LR6) (AA size) batteries 4.Replace the battery cover Battery replacement...
Page 5
Setting the dual time In addition to real time, a dual time can be programmed into the radio. 1.Press MEMO SCAN (DUAL TIME) button, display will flash “ ” 2.Press ENTER button within 7 seconds, the display “ ” will stop flashing. 3.Press ENTER button again, the “...
Page 6
Manual tuning 1.Press the POWER on/off button to turn on the radio. 2.Select a waveband by pressing BAND button. 3.A single press on the either the TUNING UP “ ” or DOWN “ ”buttons will change the frequency up or down. Note: Each press of the up or down button will change the frequency in increment of 100kHz 9kHz/10KHz...
Page 7
3.Press the numbered button corresponding to the preset memory location for the required station .The radio will instantly tune to the station and the display will show its frequency and memory location. Select Short Wave Meter band 1.Turn on the radio by pressing the POWER on/off button. 2.Press BAND button to select the SW waveband .
Page 8
ALARM button again to cancel the alarm, The alarm symbol will flash for 7 seconds and disappear. Note: 1.When the alarm is sounding, press POWER button to turn off the alarm for 24 hours. 2.The radio alarm will last for one hour if not turned off by pushing the POWER button. 3.Tune the radio to the required station before setting the alarm.
Page 9
removed form the display. Light Pressing the light button located on the top of the radio will turn on the light and illuminate the display for approximately 7 seconds. MW step switch 1.This switch located on the bottom side of the radio provides a means of changing the MW step from 9kHz to 10 kHz.
Page 10
Circuit features Semiconductors 1 LSI,5IC'S, 2 FET ,39 transistors ,34 diodes,1 LED Aerial system MW Built in ferrite aerial SW Telescopic aerial FM Telescopic aerial Output Power 180 m W Sockets Headphones socket 3.5 mm dia stereo DC in 6 volts centre pin negative Accessories Carrying pouch and stereo earphones (Accessories may be different from each market)
