Summarization of Contents
Safety Information
CAUTION: Electric Shock Risk
Do not remove covers or access internal parts. Refer servicing to qualified personnel.
CAUTION: Standby/On Power
Unplug unit from AC outlet for full power shutdown; unplug when unused for long periods.
CAUTION: General Household Use
Product for household use; repairs for other uses may be charged.
WARNING: Waterproof
Unit not waterproof; keep liquids away to prevent fire or shock.
VENTILATION CAUTION
Ensure 10cm ventilation space around unit for heat radiation.
WARNING: Ventilation Blockage
Do not block openings to prevent fire hazards from overheating.
CAUTION: Laser Product Safety
Class 1 laser product with higher diode; refer servicing to qualified personnel.
WARNING: Naked Flame Hazard
Do not place naked flames on equipment to prevent fire hazards.
POWER-CORD CAUTION
Handle cord by plug; avoid pulling cord, wet hands, or pinching.
3D Viewing Cautions
3D Viewing Cautions
Extended 3D viewing without rest periods may cause fatigue or discomfort.
Copyright and TV Notices
Notes on Copyrights
Mentions AACS, BD-ROM, BD+ content protection systems and restrictions.
TV Colour System Notice
Explains color system compatibility with TV and output signals.
Before You Start
Introduction
Read operating instructions for proper use and keep for reference.
Supplied Accessories
Lists items included with the player: remote, batteries, antenna, cables.
Speaker Box Accessories
Details specific speaker box accessories for MCS-838/MCS-737, MCS-636/MCS-535, MCS-434/MCS-333 models.
Remote Control Battery Installation
Step-by-step for opening cover, inserting batteries, and closing cover.
Software Update Information
Check Pioneer website for software updates and service information.
Mobile Device Control (iPod/iPhone/iPad)
Control player via mobile device by installing a special application.
Playable Disc and File Types
Lists playable disc types (BD, DVD, CD) and their compatibility formats.
Unplayable Discs
Lists disc types like HD DVDs and DVD-RAM discs that are not playable.
8cm Disc Playback Note
Instructions for playing 8 cm discs; 8 cm BD-ROMs not playable.
Unauthorized Copy Playback (Cinavia)
Explains Cinavia technology restricting unauthorized copies of commercial content.
Copyright Protection
Discusses copyright protection for Blu-ray Discs, DVDs, and Internet content.
Supported Audio Formats
Lists supported audio formats like Dolby TrueHD, DTS-HD Master Audio, etc.
Playing BD Discs
Specifies the BD formats (BDMV, BDAV) compatible with the player.
BONUSVIEW Functionality
Explains BONUSVIEW functions like secondary video and audio playback.
BD-LIVE Functionality
Describes BD-LIVE functions like downloading content and online games from the Internet.
Playing DVDs
Explains DVD-RW playback compatibility and AVCHD format.
Disc Region Numbers
Details Blu-ray Disc and DVD-Video region numbers assigned by region.
Playing CDs
Discusses compatibility with Audio CD format and copy-protected CDs.
DualDisc Playback
Explains only the DVD side of a DualDisc can be played; the audio side is not compatible.
Discs from Computers/Recorders
Notes potential playback issues with discs created on computers or recorders.
Media File and Folder Structure
Details requirements for folder structure and file naming for playing media files.
Playable Media File Formats
Lists playable video, image, and audio file formats.
Supported Video File Formats
Lists supported video file formats: Real RMVB, DivX Plus HD.
DivX VOD Registration Note
Important note about DivX VOD content requiring device registration.
Playable Files Table
Table detailing playable files (extensions), media support, and specifications.
Playable File Formats
Lists playable file formats and their media support (BD/DVD, USB, Network).
File Playback Notes
Notes that file playback may vary due to file structure, server capacity, or network environment.
Trademarks and Licenses
Lists various trademarks and licenses: HDMI, Dolby, DTS, DLNA, Wi-Fi.
Apple Device Compatibility (iPod/iPhone/iPad)
Explains USB compatibility with Apple devices and certification standards.
Remote Control Overview
Details remote control buttons: STANDBY/ON, FUNCTION, OPEN/CLOSE, and others.
Remote Control Functions
Details remote functions: HOME MENU, REPLAY, TOOLS, SKIP SEARCH, etc.
Front Panel Layout
Describes front panel controls: Disc tray, Operation buttons, Display Window.
Rear Panel Layout
Details rear panel connections: AC IN, SPEAKERS, Antenna, AUX, USB, LAN, HDMI, OPTICAL.
Connecting
Assemble Speakers
Connect speaker wires and attach non-skid pads.
Speaker Setup (MCS-838, MCS-737)
Connect speaker wires, attach non-skid pads.
Wall Mounting Speakers (MCS-838, MCS-737)
Instructions and precautions for wall mounting the center speaker.
Additional Speaker Notes (MCS-838, MCS-737)
Placement precautions: avoid magnetic fields, do not mount on walls/ceilings.
System Positioning (MCS-838, MCS-737)
Illustrates optimal speaker placement for surround sound.
Speaker Setup (MCS-636, MCS-535)
Connect speaker wires, attach non-skid pads.
Wall Mounting Speakers (MCS-636, MCS-535)
Instructions and precautions for wall mounting surround and center speakers.
Additional Speaker Notes (MCS-636, MCS-535)
Placement precautions: avoid magnetic fields, do not mount on walls/ceilings.
System Positioning (MCS-636, MCS-535)
Illustrates optimal speaker placement for surround sound.
Speaker Setup (MCS-434, MCS-333)
Connect speaker wires, attach non-skid pads.
Wall Mounting Speakers (MCS-434, MCS-333)
Instructions and precautions for wall mounting speakers.
Additional Speaker Notes (MCS-434, MCS-333)
Placement precautions: avoid magnetic fields, do not mount on walls/ceilings.
System Positioning (MCS-434, MCS-333)
Illustrates optimal speaker placement for surround sound.
Connecting to Your TV
Connect player to TV using HDMI cable or antenna.
HDMI Connection
Connect player to TV using HDMI cable.
DVI Device Connection
Notes on connecting to DVI devices, HDCP compatibility, and audio output.
Antenna Connection
Connect antenna for FM radio listening.
External Device Connections
Connect external components via AUX and PORTABLE IN.
AUX Connection
Connect external components via AUX L/R input for sound.
PORTABLE IN Connection
Connect portable audio players to the PORTABLE IN socket.
OPTICAL IN Connection
Connect components via digital optical for sound.
HDMI IN 1/2/3/4 Connection
Connect components via HDMI IN for picture and sound.
Home Network Connection
Connect player to LAN for BD-LIVE and online services.
Wired Network Connection
Connect to modem/router via Ethernet cable for wired network.
Wireless Network Connection (MCS-838/MCS-636/MCS-434 only)
Use Access Point or wireless router for network connection (IEEE 802.11n).
Wireless Network Setup (MCS-838/MCS-636/MCS-434 only)
Steps for setting up player for network communication via wireless settings.
WPS Setup (Wi-Fi Protected Setup) (MCS-838/MCS-636/MCS-434 only)
WPS connection using push-button or PIN code configuration.
Notes on Network Connection
Troubleshooting tips and notes for network setup and connectivity.
USB Device Connection
Connect USB devices for playback, copying, and recording.
About USB Devices
USB device requirements: file system, capacity.
Connecting the USB Device
Step-by-step guide for connecting a USB device.
Getting Started
Setup Navigator Menu Settings
Guide for initial setup: language, resolution, aspect ratio.
TV Operation with Player Remote
How to set up and use player remote to control TV.
TV Preset Code List
List of manufacturer codes for TV control via player remote.
Playback
Playing Discs or Files
Basic operations: loading and starting playback of discs/files.
Resume Playback Function
How resume playback works and when it is cancelled.
Playback with Other Functions
Playback when other functions are selected (e.g., Home Media Gallery).
Forward and Reverse Scanning
Scan discs/files forward and reverse during playback.
Play Specific Chapters, Tracks, or Files
Select and play specific content by number.
Skipping Content
Skip to next/previous chapter, track, or file.
Playing in Slow Motion
Play content in slow motion by pausing and holding buttons.
Step Forward and Reverse
Step through content frame-by-frame forward or reverse while paused.
A-B Repeat Play
Repeatedly play a specific section of a title or track.
Repeat Play
Play discs, titles, chapters, tracks, or files repeatedly.
Programmed Play
Play content in programmed order by selecting titles and chapters.
Making Bookmarks
Create and play back bookmarked scenes from video.
Zoom Function
Zoom in and out of content during playback.
Playing Photos as Slideshows
Play photos automatically, including rotating/inverting.
Switching Camera Angles
Switch camera angles on BD-ROM/DVD-Video discs.
Switching Subtitles
Switch between multiple subtitles on discs or files.
Switching Audio Tracks
Switch between multiple audio streams or channels on discs or files.
Convert 2D to 3D Image
Convert 2D images to pseudo 3D for output.
CD/SACD Playback Area
Select playback area for CD/SACD discs.
Displaying Disc Information
Display disc information on the TV screen.
Enjoying BONUSVIEW or BD-LIVE
Use BONUSVIEW (PiP) and BD-LIVE (downloadable content) functions.
Playback Functions Overview
Table showing available playback functions for different disc/file types.
Using the TOOLS Menu
Access and use TOOLS menu for various playback functions.
Time Search Playback
Start playback from a specific time within a title or chapter.
Title/Chapter/Track/File Search
Search for and play a specific title, chapter, track, or file.
Random Order Playback
Play specified ranges in random or shuffle order.
Continued Viewing Playback
Set playback position to continue later, even after power off.
Playback from Home Media Gallery
About Home Media Gallery
Introduces Home Media Gallery for displaying input sources and starting playback.
Network Playback Technologies
Explains network playback using Windows Media Player and DLNA.
Network Playback Behavior
Notes on network playback issues: stalling, interference, security blocking.
Network File Playback
Steps to play files from network servers via Home Media Gallery.
Disc/USB Playback
Steps to play files from discs or USB devices via Home Media Gallery.
Image File Playback
Information on playing image files and slideshow feature.
Switch Play Mode
Select playback modes: All Play or Folder Play.
Playlist Creation and Playback
Add tracks/files to create and play a playlist.
Deleting Playlist Items
Remove tracks or files from a playlist.
Copy Files to USB
Copy single files/folders or all files to a USB device.
Wi-Fi Direct™ Function (MCS-838/MCS-636/MCS-434 only)
Wi-Fi Direct for direct connection to mobile devices for media playback.
Display Wi-Fi Direct Mode Screen
Access and display Wi-Fi Direct mode screen on TV.
Connect to Mobile Device
Connect mobile device via Wi-Fi Direct using device name and password.
WPS Connection Setup
Connect via Wi-Fi using WPS (PBC method) if supported.
Connect Using Mobile Wi-Fi Direct
Connect using mobile's Wi-Fi Direct by searching and selecting the unit.
Play Media Files from Mobile Device
Send and play media files from mobile device to unit.
Ending Wi-Fi Direct Connection
Terminate Wi-Fi Direct connection and return to previous settings.
Change SSID and Password
Change SSID and password for unit-mobile device connection.
Playing Web Contents
Available Web Contents
Lists available web services: YouTube, vTuner, Picasa.
YouTube Service
Supports YouTube Leanback service; mobile videos may not play.
vTuner Internet Radio
vTuner is internet radio service; station lists subject to change.
Picasa Photo Service
Picasa available in English; requires user registration on computer.
Web Content Playback Notes
Web content playback may be unreliable; requires broadband connection.
Playing Web Content Items
Steps to select and play web content items after internet connection.
Enjoying YouTube
Display YouTube screen and select videos for playback.
Other Operating
Record Audio CD to USB Device
Record Audio CDs to rear USB device: select songs, set recording speed.
iPod/iPhone/iPad Playback (MCS-838/MCS-636/MCS-434 only)
Supported iPod/iPhone/iPad models and system compatibility.
Connecting iPod/iPhone/iPad
Connect iPod/iPhone/iPad to unit's front USB port.
Playing iPod/iPhone/iPad
Select iPod as input source and use remote for playback.
Radio Operations
Listening to radio, preset stations, delete stations, improve reception.
FM Recording
Record FM broadcasts to rear USB device using USB REC.
Karaoke Enjoyment
Turn on Karaoke, adjust mic volume, echo, key control, and vocal cancel.
Karaoke Settings
Table detailing Karaoke settings: Switch, Mic Setup, Key Control, Vocal Cancel, Score.
Sound Settings
Access sound menu: Sound Retriever, Equalizer, Surround, Bass Boost, Audio Sync.
Advanced Settings
Initial Setup Screen Operation
Guide for initial setup: language, resolution, aspect ratio.
Video Adjustment Settings
Adjust video settings: Brightness, Saturation, Hue, Contrast, Sharpness, CTI.
Speaker Adjustment Settings
Adjust speaker settings for Trim or Delay, including listening to sound.
IP Address Setting
Set player's IP address: DHCP automatic or manual settings.
Proxy Server Setting
Configure proxy server settings if instructed by Internet service provider.
Network Connection Test
Perform network connection test to check connectivity.
Changing Language Settings
Change language for OSD, Audio, Subtitle, and Menu.
Erasing BD Data and Application Data
Erase BD-LIVE, BONUSVIEW data, and application data from BDs.
Password Registration or Change
Register or change password for Parental Lock settings.
Parental Lock Level Adjustment
Set Parental Lock level to restrict viewing of discs with adult content.
Country/Area Code Change
Change the player's country/area code.
Software Updating
Update player software via Internet or USB flash drive.
Restore Factory Default Settings
Restore all player settings to their original factory defaults.
Language and Country Code Tables
Tables listing language codes and country/area codes for settings.
Troubleshooting
Picture Issues
Checks and remedies for no picture or improper picture display.
Picture Stretching
Checks and remedies for stretched picture, related to aspect ratio.
Picture Cropping
Checks and remedies for cropped picture, related to aspect ratio.
Aspect Ratio Cannot Be Switched
Checks and remedies for inability to switch aspect ratio, related to TV screen settings.
Interrupted Picture
Checks and remedies for interrupted picture, related to resolution settings.
3D Blu-ray Playback Issues
Checks and remedies for 3D playback issues, related to HDMI cable and TV support.
Sound Output Issues
Checks and remedies for no sound output or improper sound.
Multi-Channel Sound Issues
Checks and remedies for missing multi-channel sound, related to audio output settings.
Surround/Center Speaker Sound Issues
Checks and remedies for no sound from specific speakers, related to connection and volume.
Subwoofer Sound Issues
Checks and remedies for no subwoofer sound, related to bass component and volume.
Radio Reception Noise
Checks and remedies for noise during radio reception, related to antenna and interference.
HDMI Audio Output Issues
Checks and remedies for HDMI audio output issues, related to HDMI In Audio Through setting.
Disc Playback Issues
Checks and remedies for discs not playing, related to disc compatibility and condition.
Automatic Disc Tray Opening
Checks and remedies for automatic disc tray opening, related to disc condition.
Frozen Controls
Steps to resolve frozen picture and unresponsive controls, including rebooting.
Subtitle Switching Issues
Notes that subtitles cannot be switched for discs recorded by a DVD/BD recorder.
Disc Loading Delay
Checks and remedies for discs that stay on 'Loading' and do not start playback.
Undisplayable File Characters
Explains the meaning of '()' displayed for characters that cannot be displayed.
BD-ROM Low Memory Message
Connect USB or erase BUDA data to resolve low memory messages.
Network Connectivity Issues
Checks and remedies for BD-LIVE, proxy server, and Internet connection problems.
Software Update Errors
Checks and remedies for software update errors, related to Internet connection and proxy settings.
Slow Software Updating
Notes that software updating can take time depending on Internet connection.
Connection Test Errors
Checks and remedies for 'Network is FAILED' messages, related to Ethernet hub, IP address, DHCP.
Ethernet Hub/Router Issues
Checks and remedies for Ethernet hub or router issues, including settings and rebooting.
Network Component Access Issues
Checks and remedies for inability to access network components, related to security software and settings.
Audio Component Network Status
Notes that the audio component must be switched on before the player.
Improperly Set Network Components
Checks and remedies for improperly set network components, related to authorization and connection status.
No Playable Network Audio Files
Checks and remedies for missing playable audio files on network components.
Playback Not Starting
Checks and remedies for playback not starting, related to component connection and power supply.
Computer Operation Issues
Checks and remedies for computer operation issues, related to IP address settings and automatic configuration.
Unplayable Network Audio Files
Checks and remedies for unplayable audio files from network components.
Network Folder Issues
Check network component folder for deletion or damage.
Restricted Network Connections
Check computer's network and security settings to resolve restricted connections.
Windows Media Player Access Issues
Steps to log onto local machine instead of domain for WMP access.
Disturbed Audio Playback
Checks and remedies for disturbed audio playback, related to file format and network traffic.
Disconnected LAN Cable
Ensure the LAN cable is properly connected.
Network Traffic and Interference
Use 100BASE-T for network access and avoid devices emitting electromagnetic waves.
Wireless LAN Access Issues
Checks and remedies for wireless LAN access issues: distance, interference, IP settings.
SSID Concealment
Notes that if SSID is concealed, manual wireless LAN settings may be needed.
WEP Security Limitations
States that WEP 152-bit key or shared key authentication is not supported.
Wi-Fi Direct Connection Issues
Resolve Wi-Fi Direct connection issues by closing screens and re-performing controls.
iPod/iPhone/iPad Operation Issues
Checks and remedies for iPod/iPhone/iPad operation issues: connection and device support.
Unit Power Issues
Checks and remedies for unit not turning on, related to power cord and outlet.
Automatic Power Off
Explains that Auto Power Off setting causes automatic power off after inactivity.
Remote Control Issues
Checks and remedies for remote control issues: operating distance and batteries.
Cleared Settings
Checks and remedies for cleared settings, related to power cord disconnection or power failure.
USB Device Malfunction
Checks and remedies for USB device issues: connection, extension cables, partitions, write-protection, file system.
USB Recording Failure
Checks and remedies for inability to record to USB, related to USB device connection and memory.
Dark Display Window
Adjust display brightness using the DIMMER button.
'OC ERROR' Message
Instructs to unplug unit and contact customer support for OC ERROR messages.
Appendix
Specifications
General specifications: power, dimensions, operating temp, inputs/outputs.
Speaker Specifications (MCS-838/MCS-737)
Specs for MCS-838/MCS-737 speakers: type, impedance, dimensions, weight.
Speaker Specifications (MCS-636/MCS-535)
Specs for MCS-636/MCS-535 speakers: type, impedance, dimensions, weight.
Speaker Specifications (MCS-434/MCS-333)
Specs for MCS-434/MCS-333 speakers: type, impedance, dimensions, weight.
Maintenance
Guidance on handling, cleaning, and maintaining the unit.
Unit Handling
Instructions for packing the unit for shipping and cleaning exterior surfaces.
Disc Handling and Cleaning
Instructions on handling discs: avoid touching surface, store properly, and clean discs.
Important Information Relating to Network Services
Disclaimer regarding third-party content and services provided through the player.
Need help?
Do you have a question about the MCS-636 and is the answer not in the manual?
Questions and answers
