TP43E XE/TP43E HP/TP45E HP BIOS Manual
BIOS Setup .................................................................................................1
1 Main Menu...............................................................................................3
2 Advanced Menu.......................................................................................8
3 PCIPnP Menu........................................................................................19
4 Boot Menu..............................................................................................22
5 Chipset Menu.........................................................................................25
6 O.N.E Menu...........................................................................................29
7 Exit Menu...............................................................................................39
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TP43E HP - BIOS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Biostar TP43E HP - BIOS

Summary of Contents for Biostar TP43E HP - BIOS

  • Page 1 TP43E XE/TP43E HP/TP45E HP BIOS Manual BIOS Setup ....................1 1 Main Menu....................3 2 Advanced Menu..................8 3 PCIPnP Menu..................19 4 Boot Menu....................22 5 Chipset Menu..................25 6 O.N.E Menu...................29 7 Exit Menu....................39...

  • Page 2: Bios Setup

    TP43E XE/TP43E HP/TP45E HP BIOS Manual BIOS Setup Introduction T he purpose of this manual is to describe the settings in the AMI BIOS Setup program on this motherboard. The Setup program allows users to modify the basic system configuration and save these settings to CMOS RAM. T he power of CMOS RAM is supplied by a battery so that it retains the Setup information when the power is turned off.

  • Page 3: Pci Bus Support

    TP43E XE/TP43E HP/TP45E HP BIOS Manual PCI Bus Support T his AMI BIOS also supports Version 2.3 of the Intel PCI (Peripheral Component Interconn ect) local bus speci fication. DRAM S upport DDR2 SDRAM (Double Data Rate II Synchronous DRAM) is supported. Supported CP Us T his AMI BIOS supports the Intel CPU.
  • Page 4 TP43E XE/TP43E HP/TP45E HP BIOS Manual 1 Main Menu Once you enter AMI BIOS Setup Utility, the Main Menu will appear on the screen providing an overview of the basic system information. BIOS SETU P U TILITY Main Advan ced PCIPnP Boot Chipset...

  • Page 5: Ide/S Ata Configuration

    TP43E XE/TP43E HP/TP45E HP BIOS Manual IDE/S ATA Configuration T he BIOS will automatically detect the presence of ID E/SAT A devices. There is a sub-menu fo r each IDE/SAT A device. Select a device and press <Enter> to enter the sub-menu of detailed options.

  • Page 6: Ahci Configuration

    TP43E XE/TP43E HP/TP45E HP BIOS Manual AHCI Configuration BIOS SETU P U TILITY Main AHCI Settings Enables for supporting AHCI BIOS Supp ort [Ena bled] AHCI CD\DVD Bo ot Time out [35] > AHCI Port0 > AHCI Port1 > AHCI Port2 >...
  • Page 7 TP43E XE/TP43E HP/TP45E HP BIOS Manual Device This area shows the detected connected device. SATA Port0/1/2/3/4/5 This item allows you to select the connected device type. Options: Auto (Default) S.M.A.R.T. This item allows you to control the device S.M.A.R.T function. Options: Enabled (Default) / Disabled SATA 1/2/3/4/5/6 Device;...

  • Page 8: Hard Disk Write Protect

    TP43E XE/TP43E HP/TP45E HP BIOS Manual PIO Mode Select the PIO mode. Options: Auto (Default) / 0 / 1 / 2 / 3 / 4 DMA Mode Select the DMA mode. Options: Auto (Default) / SWDMA0 ~ 2 / MWDMA0 ~ 2 / UDMA0 ~ 5 S.M.A.R.T Set the Smart Monitoring, Analysis, and Reporting T echnology.

  • Page 9: Advanced Menu

    TP43E XE/TP43E HP/TP45E HP BIOS Manual 2 Advanced Menu T he Advanced Menu allows you to configu re the settings of CPU, Super I/O, Power Management, and other system devices. Notice Beware of that setting inappropriate values in items of this menu may cause system to malfunction.
  • Page 10 TP43E XE/TP43E HP/TP45E HP BIOS Manual C1E Support C1E is “Enhanced Halt State” function, this f unction helps to save power and decrease heat by lowering CPU frequen cy while the processor is not working. Options: Enabled (Default) / Disabled Hardware Prefetcher T he processor has a hardw are prefetch er that automatically analy zes its requirements and prefetches dat a and instructions from the memory into the Level 2 cache that are...

  • Page 11: Super Io Configuration

    TP43E XE/TP43E HP/TP45E HP BIOS Manual Execute-Disable Bit Capability T his item allows you to configure th e Execut e Disabled Bit function, which protects your system from buffer overflow attacks. Options: Disabled (Default) / Enabled Core Multi-Processing T his item allows multi-processing fun ction for multi-core processors. Options: Enabled (Default) / Disabled SuperIO Configuration...

  • Page 12: Hardware Health Configuration

    TP43E XE/TP43E HP/TP45E HP BIOS Manual Specific Key Enter T his item will show only when Keyboard PowerOn is set “Specific Key.” Stroke Keys Selected T his item will show only when Keyboard PowerOn is set “Stroke Key.” Options: Ctrl+F1 (Default) / Wake Key / Power Key / Ctrl+F2 / Ctrl+F3 / Ctrl +F4 / Ctrl+F5 / Ctrl+F6 Mouse PowerOn T his item allows you to control the mouse power on function.

  • Page 13: Smart Fan Configuration

    TP43E XE/TP43E HP/TP45E HP BIOS Manual H/W Health Function If you computer contains a monitoring system, it will show PC health status during POST stage. Options: Enabled (Default) / Disabled Shutdow n Temperature T his item allows you to set up the CPU shutdown T emperature. This item is only effective under Windows 98 ACPI mode.
  • Page 14 TP43E XE/TP43E HP/TP45E HP BIOS Manual Fan Ctrl OFF(℃ ) If the CPU/System T emperature is lower than the set value, FAN will turn off. 0~127 (℃) (Interval: 1℃) Options: Fan Ctrl On(℃ ) CPU/System f an starts to work under smart fan function when arrive this set value. 0~127 (℃) (Interval: 1℃) Options: Fan Ctrl Start Value...
  • Page 15 TP43E XE/TP43E HP/TP45E HP BIOS Manual USB Dev ice Wakeup from S3/S4 T his item allows you to enable or disabled the USB resume from S3/S4 function. Options: Disabled (Default) / Enabled High Performance Event Timer T his item allows you to enable or disabled the HPET. Options: Disabled (Default) / Enabled HPET Memory Address...
  • Page 16 TP43E XE/TP43E HP/TP45E HP BIOS Manual Suspend mode T he item allows you to select the suspend type under the ACPI operating system. Options: S1 (POS) (Default) Power on Suspend S3 (ST R) Suspend to RAM Auto POS+STR ACPI Version Features T he item allows you to select the version of ACPI.

  • Page 17: Usb Configuration

    TP43E XE/TP43E HP/TP45E HP BIOS Manual USB Configuration T his item shows the USB controller and using USB device information. BIOS S ETUP UTILITY Advanced USB C onfiguration Enab les support for lega cy USB. AUTO Modul e Version - 2 .24.3-13.4 opti on disables lega cy support i f USB D evices Enable d:...
  • Page 18 TP43E XE/TP43E HP/TP45E HP BIOS Manual USB Mass Storage Dev ice Configuration BIOS SETUP UTILITY Advanced USB Mass Storage Device Configuration Number of seconds POST waits for the USB Mass Storage Reset Delay [20 Sec] USB mass storage device after start Device # unit command.
  • Page 19 TP43E XE/TP43E HP/TP45E HP BIOS Manual Config Onboard PCI/P CI-E Devices BIOS SETU P U TILITY Advan ced Onboard PCI/PC I-E Devices Configu ration Options Onboard PCIE P ATA Cntlr [A uto] Auto Onboard PCIE G iga LAN [A uto] Enabled Onboard LAN Bo ot ROM [D isabled]...

  • Page 20: Pcipnp Menu

    TP43E XE/TP43E HP/TP45E HP BIOS Manual 3 PCIPnP Menu T his section describes con figuring the PCI bus system. PCI, or Personal Computer Interconn ect, is a system which allows I/O devices to operate at speeds nearing the speed o f the CPU itself uses when communicating with its own special components. Notice Beware of that setting inappropriate values in items of this menu may cause system to malfunction.
  • Page 21 TP43E XE/TP43E HP/TP45E HP BIOS Manual PCI Latency Timer T his item controls how long a PCI device can hold the PCI bus bef ore another takes over. T he longer the latency, the longer the PCI device can retain control of the bus before handing it over to another PCI device.

  • Page 22: Reserved Memory Size

    TP43E XE/TP43E HP/TP45E HP BIOS Manual Reserved Memory Size T his item allows BIOS to reserve cert ain memory size for speci fic PCI device. Options: Disabled (Default) / 16K / 32K / 64K...

  • Page 23: Boot Settings Configuration

    TP43E XE/TP43E HP/TP45E HP BIOS Manual 4 Boot Menu T his menu allows you to setup the system boot options. BIOS SETU P U TILITY Main Advan ced PCIPnP Boot Chipset O.N.E Exit Boot Settings Configure Settings during System Boot. >...
  • Page 24 TP43E XE/TP43E HP/TP45E HP BIOS Manual Full Screen LOGO Disaply T his item allows you to enable/disable Full Screen LOGO Show function. Options: Enabled (Default) / Disabled AddOn ROM Display Mode T his item sets the display mode for option ROM. Options: Force BIOS (Default) / Keep Current Bootup Num-L ock...

  • Page 25: Boot Device Priority

    TP43E XE/TP43E HP/TP45E HP BIOS Manual Boot De vice Priority Items in this sub-menu specify the boot device priority sequence from the available devices. T he number of device items that appears on the screen depends on the number of devi ces installed in the system. Hard Disk Drives T he BIOS will attempt to arrange the hard disk boot sequence automatically.

  • Page 26: Chipset Menu

    TP43E XE/TP43E HP/TP45E HP BIOS Manual 5 Chipset Menu T his submenu allows you to configure the speci fic features of the chipset installed on your system. T his chipset manage bus speeds and access to system memory resources, such as DRAM. It also coordinates communications with the PCI bus. Notice Beware of that setting inappropriate values in items of this menu may cause system to malfunction.

  • Page 27: North Bridge Configuration

    TP43E XE/TP43E HP/TP45E HP BIOS Manual North Bridge Configuration BIOS SETU P U TILITY Chipset North Bridge C hipset Configuratio n ENABLE: Allow remapping of Memory Remap F eature [En abled] overlapped PCI memory PCI MMIO All ocation: above the total Memory Hole [Disabled] phisical memory.

  • Page 28: South Bridge Configuration

    TP43E XE/TP43E HP/TP45E HP BIOS Manual South Bridge Configuration BIOS S ETUP UTILITY Chips et South Bridge Chips et Configura tion Options USB F unctions [12 USB Por ts] Disa bled USB P ort Configura tion [6X6 USB Po rts] 2 US B Ports USB 2 .0 Controller [Enabled]...

  • Page 29: Smbus Controller

    TP43E XE/TP43E HP/TP45E HP BIOS Manual SMBUS Controller T his BIOS feature controls the I/O buffers fo r the SMBus. Options: Enabled (Default) / Disabled SLP_S4# Min. Assertion Width Options: 4 to 5 seconds (Default) / 3 to 4 seconds / 2 to 3 seconds / 1 to 2 seconds...

  • Page 30: Overclock Navigator

    OverClock Navigator OverClock .Navigator is designed for beginners in overclock field. Based on many test and experiments from Biostar Engineer Team, OverClock Navigator provid es 3 default overclo ck con figurations that are able to raise the system perfo rmance.
  • Page 31 TP43E XE/TP43E HP/TP45E HP BIOS Manual Auto OverClock S ystem BIOS S ETUP UTILITY Main Advanced PCIPnP Boot Chips et O.N.E Exit Over- Clocking Navi gator settin g Options WARNI NG: Setting w rong values in below sec tions Norm al may cause system to m alfunction.
  • Page 32 TP43E XE/TP43E HP/TP45E HP BIOS Manual Manual Overclock System (M.O.S.) BIOS S ETUP UTILITY Main Advanced PCIPnP Boot Chips et O.N.E Exit Over- Clocking Navi gator settin g Options WARNI NG: Setting w rong values in below sec tions Norm al may cause system to m alfunction.

  • Page 33: Dram Frequency

    TP43E XE/TP43E HP/TP45E HP BIOS Manual FS B(Bsel) To NorthBridge Latch T his item allows you to select the FSB Frequency. Options: Auto (Default) / FSB 800 / FSB 1066 / FSB 1333 / FSB 1600 DRAM Frequency T his item allows you to control the Memory Clock. Options: Auto (Default) / DDR2 533Mhz / DDR2 638Mhz / DDR2 667Mhz / DDR2 710Mhz / DDR2 800Mhz / DDR2 851MHz / DDR2 886 MHz /...
  • Page 34 TP43E XE/TP43E HP/TP45E HP BIOS Manual Static tREAD Value (PL) T his item allows you to select the tREAD control. Options: Auto (Default) / 1T ~ 31T Configure DRAM Timing by SPD Options: Enabled (Default) / Disabled DRAM tCL Options: 5 (Default) / 3 ~ 7 DRAM tRP Options:...
  • Page 35 TP43E XE/TP43E HP/TP45E HP BIOS Manual DRAM tRTP Options: 3 (Default) / 2 ~ 15 Extra DRAM Timing Setting Options: Auto (Default) / Manual Write to Precharge Delay Options: 14 (Default) / 10 ~ 31 Read to Precharge Delay Options: 5 (Default) / 2 ~ 15 PrechargeAll to Act Delay Options:...

  • Page 36: Clock Gen Configuration

    TP43E XE/TP43E HP/TP45E HP BIOS Manual R-to-R Delay (Diff Rank) Options: 6 (Default) / 2 ~ 15 W-to-R Delay (Diff Rank) Options: 5 (Default) / 2 ~ 15 W-to-W Delay (Diff Rank) Options: 6 (Default) / 2 ~ 15 Refresh Counter Options: Auto (Default) / 2600T / 3120T / 4171T / 5200T Clock Gen Configuration...

  • Page 37: Voltage Configuration

    TP43E XE/TP43E HP/TP45E HP BIOS Manual CPU Clock Skew Control Options: Auto (Default) / 100ps ~ 1500ps (Interval: 100ps) (G)MCH Clock Skew Control Options: Auto (Default) / 100ps ~ 1500ps (Interval: 100ps) CPU Clock Driving Control Options: Auto (Default) / 700mV ~ 1000mV (Interval: 100mV) Voltage Configuration BIOS S ETUP UTILITY O.N.E...
  • Page 38 TP43E XE/TP43E HP/TP45E HP BIOS Manual Chipset Voltage T his item allows you to select Chipset Voltage Control. Options: Auto (Default) / +0.025V ~ +0.700V Vtt Voltage T his item allows you to select Vtt Voltage Control. Options: Auto (Default) / +0.10V / +0.20V / +0.30V CPU Core1 GTL Ref Voltage T his item allows you to select CPU Core1 GT L Ref Voltage Control.
  • Page 39 TP43E XE/TP43E HP/TP45E HP BIOS Manual Integrated Memory Test Integrat ed Memory T est allows users to test memory module compatibilities without additional device or sof tw are. Step 1: T his item is disabled on default; change it to “ Enable” to precede memory test. BIOS S ETUP UTILITY Main Advanced...

  • Page 40: Save Changes And Exit

    TP43E XE/TP43E HP/TP45E HP BIOS Manual 7 Exit Menu T his menu allows you to load the optimal default settings, and save or discard the changes to the BIOS items. BIOS SETU P U TILITY Main Advan ced PCIPnP Boot Chipset O.N.E Exit...

  • Page 41: Change Supervisor Password

    TP43E XE/TP43E HP/TP45E HP BIOS Manual Security T his sub-menu allows you to provide/revise supervisor and user password. BIOS SETU P U TILITY Exit Security Setti ngs Install or Change the password. Supervisor Pas sword :Not Installe d User Password :Not Installe d Change Supervi sor Password User Access Le vel...

  • Page 42: Password Check

    TP43E XE/TP43E HP/TP45E HP BIOS Manual Passw ord Check T his item is for setting the timing that checking password. Options: Setup (Default) / Always Boot Sector Virus Protection T his option allows you to choose the VIRUS Warning feature that is used to protect the IDE H ard Disk boot sector.
