TP35D2-A7 Setup Manual
FCC Information and Copyright
This equipment has been tested and found to comply with the limits of a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. There is no guarantee
that interference will not occur in a particular installation.
The vendor makes no representations or warranties with respect to the
contents here and specially disclaims any implied warranties of merchantability
or fitness for any purpose. Further the vendor reserves the right to revise this
publication and to make changes to the contents here without obligation to
notify any party beforehand.
Duplication of this publication, in part or in whole, is not allowed without first
obtaining the vendor's approval in writing.
The content of this user's manual is subject to be changed without notice and
we will not be responsible for any mistakes found in this user's manual. All the
brand and product names are trademarks of their respective companies.

Advertisement

Table of Contents
loading

Summary of Contents for Biostar TP35D2-A7

  • Page 1 TP35D2-A7 Setup Manual FCC Information and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 2: Table Of Contents

    Table of Contents Chapter 1: Introduction ........1 Before You Start..................1 Package Checklist ..................1 Motherboard Features................2 Rear Panel Connectors (for Ver 5.x)............4 Rear Panel Connectors (for Ver 6.x)............4 Motherboard Layout................. 5 Chapter 2: Hardware Installation ......6 Installing Central Processing Unit (CPU) ..........
  • Page 3: Chapter 1: Introduction

    TP35D2-A7 CHAPTER 1: INTRODUCTION EFORE TART Thank you for choosing our product. Before you start installing the motherboard, please make sure you follow the instructions below: Prepare a dry and stable working environment with sufficient lighting. Always disconnect the computer from power outlet before operation.
  • Page 4: Motherboard Features

    Motherboard Manual OTHERBOARD EATURES Ver 5.x Ver 6.x LGA 775 LGA 775 Intel Core2Duo / Core2Quad / Celeron 4xx / Intel Core2Duo / Core2Quad / Celeron 4xx / Pentium D / Pentium 4 / Celeron D processor Pentium D / Pentium 4 / Celeron D processor Supports Hyper-Threading / Execute Disable Bit / Supports Hyper-Threading / Execute Disable Bit / Enhanced Intel SpeedStep®...
  • Page 5 Windows 2000 / XP / VISTA Windows 2000 / XP / VISTA OS Support Biostar Reserves the right to add or remove Biostar Reserves the right to add or remove support for any OS with or without notice support for any OS with or without notice...
  • Page 6: Rear Panel Connectors (For Ver 5.X)

    Motherboard Manual ANEL ONNECTORS PS/2 Audio Jack Mouse PS/ 2 COM1 USBX2 USBX2 USBX2 Keyboard Center Line In Rear Line Out Side Mic In ANEL ONNECTORS PS/2 Mouse Line In/ Surround Line Out Mic I n 1/ Bass/ Center PS/ 2 COM1 USBX2 USBX2...
  • Page 7: Motherboard Layout

    TP35D2-A7 OTHERBOARD AYOUT JCFAN1 JKBMS1 LGA775 JPRNT1 CPU1 JUSB2 JUSB1 Intel JRJ45USB1 JATXPWR1 JAUDIO1 (for Ver 5.x) JAUDIO2 JNFAN1 (for Ver 6.x) JATXPWR2 PEX16_1 Super Intel PEX4_1 ICH9 JCMOS1 BAT1 PEX1_1 JSFAN1 PCI1 SATA3 SATA1 BIOS PCI2 SATA4 SATA2 CODEC...
  • Page 8: Chapter 2: Hardware Installation

    Motherboard Manual CHAPTER 2: HARDWARE INSTALLATION (CPU) NSTALLING ENTRAL ROCESSING Special Notice: Remove Pin Cap before installation, and make good preservation for future use. When the CPU is removed, cover the Pin Cap on the empty socket to ensure pin legs won’t be damaged. Pin Cap Step 1: Pull the socket locking lever out from the socket and then raise the lever up to a 90-degree angle.
  • Page 9 TP35D2-A7 Step 2: Look for the triangular cut edge on socket, and the golden dot on CPU should point forwards this triangular cut edge. The CPU will fit only in the correct orientation. Step 2-1: Step 2-2: Step 3: Hold the CPU down firmly, and then lower the lever to locked position to complete the installation.
  • Page 10: Fan Headers

    Motherboard Manual FAN H EADERS These fan headers support cooling-fans built in the computer. The fan cable and connector may be different according to the fan manufacturer. Connect the fan cable to the connector while matching the black wire to pin#1.
  • Page 11: Installing System Memory

    TP35D2-A7 NSTALLING YSTEM EMORY A. Memory Modules Unlock a DIMM slot by pressing the retaining clips outward. Align a DIMM on the slot such that the notch on the DIMM matches the break on the Slot. Insert the DIMM vertically and firmly into the slot until the retaining chip snap back in place and the DIMM is properly seated.
  • Page 12 Motherboard Manual C. Dual Channel Memory installation To trigger the Dual Channel function of the motherboard, the memory module must meet the following requirements: Install memory module of the same density in pairs, shown in the following table. Dual Channel Status DDR2_A1 DDR2_A2 DDR2_B1 DDR2_B2 Enabled Enabled Enabled...
  • Page 13: Connectors And Slots

    TP35D2-A7 ONNECTORS AND LOTS FDD1: Floppy Disk Connector The motherboard provides a standard floppy disk connector that supports 360K, 720K, 1.2M, 1.44M and 2.88M floppy disk types. This connector supports the provided floppy drive ribbon cables. IDE1: Hard Disk Connector The motherboard has a 32-bit Enhanced PCI IDE Controller that provides PIO Mode 0~4, Bus Master, and Ultra DMA 33/66/100/133 functionality.
  • Page 14 Motherboard Manual PEX16_1: PCI-Express x16 Slot PCI-Express 1.0a compliant. Maximum theoretical realized bandwidth of 4GB/s simultaneously per direction, for an aggregate of 8GB/s totally. PEX4_1: PCI-Express x4 Slot PCI-Express 1.0a compliant. Maximum theoretical realized bandwidth of 1GB/s simultaneously per direction, for an aggregate of 2GB/s totally. PEX1_1: PCI-Express Slot PCI-Express 1.0a compliant.
  • Page 15: Chapter 3: Headers & Jumpers Setup

    TP35D2-A7 CHAPTER 3: HEADERS & JUMPERS SETUP OW TO ETUP UMPERS The illustration shows how to set up jumpers. When the jumper cap is placed on pins, the jumper is “close”, if not, that means the jumper is “open”. Pin opened...
  • Page 16 Motherboard Manual JATXPWR2: ATX Power Source Connector JATXPW2 allows user to connect 24-pin power connector on the ATX power supply. Assignment Assignment +3.3V +3.3V -12V +3.3V Ground Ground PS_ON Ground Ground Ground Ground Ground PW_OK Standby Voltage+5V +12V +12V Ground +3.3V JATXPWR1: ATX Power Source Connector By connecting this connector, it will provide +12V to CPU power circuit.
  • Page 17: Cd-Rom Audio-In Connector

    TP35D2-A7 JUSB3/JUSB4/JUSB5: Headers for USB 2.0 Ports at Front Panel This header allows user to connect additional USB cable on the PC front panel, and also can be connected with internal USB devices, like USB card reader. Assignment +5V (fused)
  • Page 18: Clear Cmos Procedures

    Motherboard Manual JCMOS1: Clear CMOS Header By placing the jumper on pin2-3, it allows user to restore the BIOS safe setting and the CMOS data, please carefully follow the procedures to avoid damaging the motherboard. Pin 1-2 Close: Normal Operation (default). Pin 2-3 Close: Clear CMOS data.
  • Page 19 TP35D2-A7 JSPDIF_OUT1: Digital Audio-out Connector This connector allows user to connect the PCI bracket SPDIF output header. Assignment SPDIF_OUT Ground JSPDIF_IN1: Digital Audio-in Connector (Optional) This connector allows user to connect the PCI bracket SPDIF input header. Assignment SPDIF_IN Ground...
  • Page 20 Motherboard Manual On-Board LED Indicators There are 2 LED indicators on the motherboard to show system status. LED2 LED1 LED1 and LED2: These 2 LED indicate system power on diagnostics. Please refer to the table below for different messages: LED1 LED2 Message Normal...
  • Page 21 TP35D2-A7 JPRNT1: Printer Port Connector This header allows you to connector printer on the PC. Assignment Assignment -Strobe Ground -ALF Data 6 Data 0 Ground -Error Data 7 Data 1 Ground -Init -ACK Data 2 Ground -Scltin Busy Data 3...
  • Page 22: Chapter 4: Overclock Quick Guide

    CHAPTER 4: OVERCLOCK QUICK GUIDE OWER NTRODUCTION Biostar T-Power is a whole new utility that is designed for overclock users. Based on many precise tests, Biostar Engineering Team (BET) has developed this ultimate overclock engine to raise system performance. No matter whether under BIOS or Windows interface, T-Power is able to present the best system state according to users’...
  • Page 23 TP35D2-A7 BIOS F OWER EATURE A. Overclocking Navigator Engine (O.N.E.): ONE provides two powerful overclocking engines: MOS and AOS for both Elite and Casual overclockers. Manual Overclock System (M.O.S.) MOS is designed for experienced overclock users. It allows users to customize personal overclock settings.
  • Page 24 Motherboard Manual CPU Clock Ratio & CPU Clock: CPU Clock Ratio x CPU Clock = CPU Frequency. CPU Frequency is directly in proportion to system performance. To maintain the system stability, CPU voltage needs to be increased also when raising CPU frequency.
  • Page 25 TP35D2-A7 V6 Tech Engine: This setting will raise about 10%~15% of whole system performance. V8 Tech Engine: This setting will raise about 15%~25% of whole system performance. V12 Tech Engine: This setting will raise about 25%~30% of whole system performance.
  • Page 26 Motherboard Manual B. CMOS Reloading Program (C.R.P.): It allows users to save different CMOS settings into BIOS-ROM. Users are able to reload any saved CMOS setting for customizing system configurations. Moreover, users are able to save an ideal overclock setting during overclock operation.
  • Page 27 TP35D2-A7 C. Memory Integration Test (M.I.T.): This function is under “Overclocking Navigator Engine” item. MIT allows users to test memory compatibilities, and no extra devices or software are needed. Step 1: The default setting under this item is “Disabled”; the condition parameter should be changed to “Enable”...
  • Page 28 E. Integrated Flash Program (I.F.P.): IFP is a safe and quick way to upgrade BIOS. Step 1: Go to Biostar website (http://www.biostar.com.tw) to download the latest BIOS file. Then, save the file into a floppy disk. Step 2: Insert the floppy disk and reboot the system to get into CMOS screen.
  • Page 29: T-Power Windows Feature

    TP35D2-A7 OWER INDOWS EATURE 1. Desktop Icon After the T-Utility has been installed, a T-Utility icon will appear on the desktop, just like the icon shown below. Now you can launch the T-Utility simply by double-clicking the desktop icon. 2. Main Panel If you double-click the desktop icon, T-Utility will be launched.
  • Page 30 Motherboard Manual 3. Overclock/Overvoltage Panel Click the Overclock/Overvoltage button in the Main Panel, the button will be highlighted and the Overclock/Overvoltage Panel will show up as the following figure. As you can see, the Overclock Panel is on the upper side, and the Overvoltage Panel is on the lower side.
  • Page 31 TP35D2-A7 Overclock Panel contains these features: a. “Auto-Overclock”: User can click this button and T-Utility will set the best and stable performance and frequency automatically. A warning dialog as below will show up to notify you that the system may become unstable, click on “OK”...
  • Page 32 Motherboard Manual e. “Save / Open Setting”: Click Save button to save current setting to a file, and click Open button to load a previously saved setting. “Panel Color”: Click this button to change the color of the panel. Overvoltage Panel contains these features: a.
  • Page 33 TP35D2-A7 5. About Panel Click the “about” button in Main Panel, the button will be highlighted and the About Panel will show up as the following figure. In this panel, you can get model name and detail information in hints of all the chipset that are related to overclocking.
  • Page 34: Chapter 5: Useful Help

    Motherboard Manual CHAPTER 5: USEFUL HELP RIVER NSTALLATION After you installed your operating system, please insert the Fully Setup Driver CD into your optical drive and install the driver for better system performance. You will see the following window after you insert the CD The setup guide will auto detect your motherboard and operating system.
  • Page 35: Award Bios Beep Code

    BIOS contents are corrupted. In this Case, please follow the procedure below to restore the BIOS: 1. Make a bootable floppy disk. 2. Download the Flash Utility “AWDFLASH.exe” from the Biostar website: www.biostar.com.tw 3. Confirm motherboard model and download the respectively BIOS from Biostar website.
  • Page 36 Motherboard Manual B. CPU Overheated If the system shutdown automatically after power on system for seconds, that means the CPU protection function has been activated. When the CPU is over heated, the motherboard will shutdown automatically to avoid a damage of the CPU, and the system may not power on again.
  • Page 37: Troubleshooting

    TP35D2-A7 ROUBLESHOOTING Probable Solution No power to the system at all Make sure power cable is Power light don’t illuminate, fan securely plugged in. inside power supply does not turn Replace cable. Contact technical support. Indicator light on keyboard does not turn on.
  • Page 38: Appendencies: Spec In Other Language

    Motherboard Manual APPENDENCIES: SPEC IN OTHER LANGUAGE ERMAN Ver 5.x Ver 6.x LGA 775 LGA 775 Intel Core2Duo / Core2Quad / Celeron 4xx / Intel Core2Duo / Core2Quad / Celeron 4xx / Pentium 4 / Pentium D / Celeron D Prozessoren Pentium 4 / Pentium D / Celeron D Prozessoren Unterstützt Hyper-Threading / Execute Disable Unterstützt Hyper-Threading / Execute Disable...
  • Page 39 220 mm (B) X 305 mm (L) Windows 2000 / XP / VISTA Windows 2000 / XP / VISTA Biostar behält sich das Recht vor , ohne Biostar behält sich das Recht vor , ohne OS-Unterstüt Ankündigung die Unterstützung für ein Ankündigung die Unterstützung für ein...
  • Page 40: France

    Motherboard Manual RANCE Ver 5.x Ver 6.x LGA 775 LGA 775 Processeurs Intel Core2Duo / Core2Quad / Processeurs Intel Core2Duo / Core2Quad / Celeron 4xx / Pentium 4 / Pentium D / Celeron D Celeron 4xx / Pentium 4 / Pentium D / Celeron D Prend en charge les technologies Prend en charge les technologies Hyper-Threading / d'exécution de bit de...
  • Page 41 Windows 2000 / XP / VISTA Windows 2000 / XP /VISTA Support SE Biostar se réserve le droit d'ajouter ou de Biostar se réserve le droit d'ajouter ou de supprimer le support de SE avec ou sans préavis. supprimer le support de SE avec ou sans préavis.
  • Page 42: Italian

    Motherboard Manual TALIAN Ver 5.x Ver 6.x LGA 775 LGA 775 Processore Intel Core2Duo / Core2Quad / Processore Intel Core2Duo / Core2Quad / Celeron 4xx / Pentium 4 / Pentium D / Celeron 4xx / Pentium 4 / Pentium D / Celeron D Celeron D Supporto di Hyper-Threading / Execute...
  • Page 43 Windows 2000 / XP / VISTA Windows 2000 / XP / VISTA Sistemi Biostar si riserva il diritto di aggiungere o Biostar si riserva il diritto di aggiungere o operativi rimuovere il supporto di qualsiasi sistema rimuovere il supporto di qualsiasi sistema supportati operativo senza preavviso.
  • Page 44: Spanish

    Motherboard Manual PANISH Ver 5.x Ver 6.x LGA 775 LGA 775 Procesador Intel Core2Duo / Core2Quad / Procesador Intel Core2Duo / Core2Quad / Celeron 4xx / Pentium 4 / Pentium D / Celeron D Celeron 4xx / Pentium 4 / Pentium D / Celeron D Admite Hyper-Threading / Bit de deshabilitación Admite Hyper-Threading / Bit de deshabilitación de ejecución / Intel SpeedStep®...
  • Page 45 Windows 2000 / XP / VISTA Windows 2000 / XP / VISTA sistema Biostar se reserva el derecho de añadir o retirar Biostar se reserva el derecho de añadir o retirar operativo el soporte de cualquier SO con o sin aviso previo.
  • Page 46: Portuguese

    Motherboard Manual ORTUGUESE Ver 5.x Ver 6.x LGA 775 LGA 775 Processador Intel Core2Duo / Core2Quad / Processador Intel Core2Duo / Core2Quad / Celeron 4xx / Pentium 4 / Pentium D / Celeron D Celeron 4xx / Pentium 4 / Pentium D / Celeron D Suporta as tecnologias Hyper-Threading / Suporta as tecnologias Hyper-Threading / Execute Disable Bit / Enhanced Intel...
  • Page 47 Windows 2000 / XP / VISTA Windows 2000 / XP / VISTA Sistemas A Biostar reserva-se o direito de adicionar ou A Biostar reserva-se o direito de adicionar ou operativos remover suporte para qualquer sistema remover suporte para qualquer sistema suportados operativo com ou sem aviso prévio.
  • Page 48: Polish

    Motherboard Manual OLISH Ver 5.x Ver 6.x LGA 775 LGA 775 Procesor Intel Core2Duo / Core2Quad / Procesor Intel Core2Duo / Core2Quad / Celeron 4xx / Pentium 4 / Pentium D / Celeron D Celeron 4xx / Pentium 4 / Pentium D / Celeron D Procesor Obsługa Hyper-Threading / Execute Disable Bit / Obsługa Hyper-Threading / Execute Disable Bit /...
  • Page 49 220 mm (S) X 305 mm (W) płyty Obsluga Windows 2000 / XP / VISTA Windows 2000 / XP / VISTA systemu Biostar zastrzega sobie prawo dodawania lub Biostar zastrzega sobie prawo dodawania lub operacyjne odwoływania obsługi dowolnego systemu odwoływania obsługi dowolnego systemu operacyjnego bez powiadomienia.
  • Page 50: Russian

    Motherboard Manual USSIAN Ver 5.x Ver 6.x LGA 775 LGA 775 Процессор Intel Core2Duo / Core2Quad / Процессор Intel Core2Duo / Core2Quad / Celeron 4xx / Pentium 4 / Pentium D / Celeron D Celeron 4xx / Pentium 4 / Pentium D / Celeron D (центральн...
  • Page 51 панели Windows 2000 / XP / VISTA Windows 2000 / XP / VISTA Поддержка Biostar сохраняет за собой право добавлять Biostar сохраняет за собой право добавлять или удалять средства обеспечения для OS с или удалять средства обеспечения для OS с...
  • Page 52: Arabic

    Motherboard Manual RABIC Ver 6.x Ver 5.x LGA 775 LGA 775 ‫ﻣﻌﺎﻟﺠﺎت‬Intel Core2Duo / Core2Quad / Celeron 4xx ‫ﻣﻌﺎﻟﺠﺎت‬Intel Core2Duo / Core2Quad / Celeron 4xx / Pentium 4 / Pentium D / Celeron D / Pentium 4 / Pentium D / Celeron D ‫ﻞ...
  • Page 53 TP35D2-A7 Ver 6.x Ver 5.x ‫اﻟﻨﻄﺎق اﻟﺘﺮددي ﻟﻠﺠﻴﺠﺎﺑﺖ ﻣﻘﺼﻮر ﻓﻘﻂ ﻋﻠﻰ‬RTL 8110SC ‫اﻟﻨﻄﺎق اﻟﺘﺮددي ﻟﻠﺠﻴﺠﺎﺑﺖ ﻣﻘﺼﻮر ﻓﻘﻂ ﻋﻠﻰ‬RTL 8110SC ‫اﻟﻨﺼﻔﻲ‬ ‫إﻣﻜﺎﻥﻴﺔ اﻟﻨﻘﻞ اﻟﻤﺰدوج اﻟﻜﺎﻣﻞ‬ ‫اﻟﻨﺼﻔﻲ‬ ‫إﻣﻜﺎﻥﻴﺔ اﻟﻨﻘﻞ اﻟﻤﺰدوج اﻟﻜﺎﻣﻞ‬ ALC861VD ALC888 ‫ﻋﺎﻝﻲ‬ ‫اﻝﺼﻮت‬ ‫دﻋﻢ‬ ‫ﺕﺪﻋﻢ ﺕﻘﻨﻴﺔ اﻟﺼﻮت ﻋﺎﻟﻲ اﻟﺘﻌﺮﻳﻒ ﻣﻦ‬Intel ‫ﺕﺪﻋﻢ...
  • Page 54: Japanese

    Motherboard Manual APANESE Ver 5.x Ver 6.x LGA 775 LGA 775 Intel Core2Duo / Core2Quad / Celeron 4xx / Intel Core2Duo / Core2Quad / Celeron 4xx / Pentium 4 / Pentium D / Celeron D processor Pentium 4 / Pentium D / Celeron D processor Hyper-Threading / Execute Disable Bit / Hyper-Threading / Execute Disable Bit / Enhanced Intel SpeedStep®...
  • Page 55 TP35D2-A7 Ver 5.x Ver 6.x 半/全二重機能 半/全二重機能 ALC888 ALC861VD HDオーディ ハイデフィニションオーディオのサポート ハイデフィニションオーディオのサポート オのサポート 7.1 チャンネルオーディオアウト 5.1 チャンネルオーディオアウト PCIスロット PCIスロット PCI Express x16スロット PCI Express x16スロット スロット PCI Express x 4スロット PCI Express x 4スロット PCI Express x 1スロット PCI Express x 1スロット...
  • Page 56 TP35D2-A7 BIOS Setup BIOS Setup ....................1 1 Main Menu ..................... 3 2 Standard CMOS Features..............7 3 Advanced BIOS Features ..............9 4 Advanced Chipset Features..............16 5 Integrated Peripherals................. 18 6 Power Management Setup..............24 7 PnP/PCI Configurations..............30 8 PC Health Status ..................
  • Page 57: Bios Setup

    TP35D2-A7 BIOS Setup Introduction The purpose of this manual is to describe the settings in the Phoenix-Award™ BIOS Setup program on this motherboard. The Setup program allows users to modify the basic system configuration and save these settings to CMOS RAM.
  • Page 58: Acpi Support

    TP35D2-A7 ACPI Support Phoenix-Award ACPI BIOS support Version 1.0b of Advanced Configuration and Power interface specification (ACPI). It provides ASL code for power management and device configuration capabilities as defined in the ACPI specification, developed by Microsoft, Intel and Toshiba.
  • Page 59: Main Menu

    TP35D2-A7 1 Main Menu Once you enter Phoenix-Award BIOS™ CMOS Setup Utility, the Main Menu will appear on the screen. The Main Menu allows you to select from several setup functions. Use the arrow keys to select among the items and press <Enter>...
  • Page 60 TP35D2-A7 Advanced BIOS Features This submenu allows you to configure advanced features of the BIOS. Advanced Chipset Features This submenu allows you to configure special chipset features. Integrated Peripherals This submenu allows you to configure certain IDE hard drive options and Programmed Input/ Output features.
  • Page 61: Load Optimized Defaults

    TP35D2-A7 Load Optimized Defaults This selection allows you to reload the BIOS when problem occurs during system booting sequence. These configurations are factory settings optimized for this system. A confirmation message will be displayed before defaults are set. Set Supervisor Password Setting the supervisor password will prohibit everyone except the supervisor from making changes using the CMOS Setup Utility.
  • Page 62: Exit Without Saving

    TP35D2-A7 Exit Without Saving Abandon all changes made during the current session and exit setup. Confirmation message will be displayed before proceeding. Integrate Flashing Program This submenu allows you to upgrade bios.
  • Page 63: Standard Cmos Features

    TP35D2-A7 2 Standard CMOS Features The items in Standard CMOS Setup Menu are divided into several categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the<PgUp> or <PgDn> keys to select the value you want in each item.
  • Page 64 TP35D2-A7 Item Options Description Press <Enter> to enter the IDE Channel 1 Options are in its sub sub menu of detailed Master / Slave menu. options. 360K, 5.25 in 1.2M, 5.25 in Select the type of floppy Drive A 720K, 3.5 in disk drive installed in your 1.44M, 3.5 in...
  • Page 65: Advanced Bios Features

    TP35D2-A7 3 Advanced BIOS Features Figure 3: Advanced BIOS Setup...
  • Page 66: Cpu Feature

    TP35D2-A7 CPU Feature Delay Prior to Thermal Set this item to enable the CPU Thermal function to engage after the specified time. The Choices: 4 Min, 8 Min, 16Min (default), 32 Min. Thermal Management This option allows you to select the way to control the “Thermal Management.”...
  • Page 67 TP35D2-A7 Limit CPUID MaxVal Set Limit CPUID MaxVal to 3, it should be “Disabled” for Windows XP. The Choices: Disabled (default), Enabled. C1E Function This item allows you to configure the Enhanced Halt State (C1E) function, which may reduce the power consumption of your system when the system is idle.
  • Page 68: Hard Disk Boot Priority

    TP35D2-A7 Boot Seq & Floppy Setup This item allows you to setup boot sequence & Floppy. Hard Disk Boot Priority The BIOS will attempt to arrange the Hard Disk boot sequence automatically. You can change the Hard Disk booting sequence here.
  • Page 69: Virus Warning

    TP35D2-A7 First/Second/Third Boot Device The BIOS will attempt to load the operating system in this order. The Choices: Floppy, LS120, Hard Disk, CDROM, ZIP100, USB-FDD, USB-ZIP, USB-CDROM, LAN, Disabled. Boot Other Device When enabled, BIOS will try to load the operating system from other device when it failed to load from the three devices above.
  • Page 70: Boot Up Numlock Status

    TP35D2-A7 Boot Up NumLock Status Selects the NumLock State after the system switched on. The Choices: On (default) Numpad is number keys. Numpad is arrow keys. Gate A20 Option Select if chipset or keyboard controller should control Gate A20. Normal A pin in the keyboard controller controls GateA20.
  • Page 71: Apic Mode

    TP35D2-A7 APIC MODE Selecting Enabled enables APIC device mode reporting from the BIOS to the operating system. The Choices: Enabled (default), Disabled. MPS Version Control For OS The BIOS supports version 1.1 and 1.4 of the Intel multiprocessor specification. Select version supported by the operation system running on this computer.
  • Page 72: Advanced Chipset Features

    TP35D2-A7 4 Advanced Chipset Features This submenu allows you to configure the specific features of the chipset installed on your system. This chipset manage bus speeds and access to system memory resources, such as DRAM. It also coordinates communications with the PCI bus.
  • Page 73 TP35D2-A7 Memory Hole At 15M-16M You can reserve this area of system memory for ISA adapter ROM. When this area is reserved it cannot be cached. Check the user information of peripherals that need to use this area of system memory for the memory requirements.
  • Page 74: Integrated Peripherals

    TP35D2-A7 5 Integrated Peripherals Figure 5. Integrated Peripherals...
  • Page 75: Onchip Ide Device

    TP35D2-A7 OnChip IDE Device Highlight the “Press Enter” label next to the “OnChip IDE Device” label and press enter key will take you a submenu with the following options: IDE HDD Block Mode Block mode is also called block transfer, multiple commands, or multiple sectors read / write.
  • Page 76: Super Io Device

    TP35D2-A7 On-chip Secondary PCI IDE This item allows you to enable or disable the primary / secondary IDE Channel. The Choices: Enabled (default), Disabled. IDE Primary/Secondary/Master/Slave UDMA Ultra DMA function can be implemented if it is supported by the IDE hard drives in your system.
  • Page 77 TP35D2-A7 Onboard Serial Port 1 Select an address and corresponding interrupt for the first and second serial ports. The Choices: 3F8/IRQ4 (default), Disabled, 2F8/IRQ3, 3E8/IRQ4, 2E8/IRQ3, Auto. Onboard Parallel Port This item allows you to determine access onboard parallel port controller with which I/O Address.
  • Page 78: Usb Device Setting

    TP35D2-A7 USB Device Setting Highlight the “Press Enter” label next to the “Onboard Device” label and press the enter key will take you a submenu with the following options: USB 1.0/2.0 Controller If your system contains a Universal Serial Bus (USB) controller, This entry is to enable/disable Enhanced host controller .
  • Page 79: Onboard Lan

    TP35D2-A7 UFDDA/UFDDB The Choices: USB Floppy (default). No Device [Auto]: According to contents of USB MSD decide boot up type. [FDD Mode]: The USB MSD always boot up as floppy disk. [HDD Mode]: The USB MSD always boot up as hard disk.
  • Page 80: Power Management Setup

    TP35D2-A7 6 Power Management Setup The Power Management Setup Menu allows you to configure your system to utilize energy conservation and power up/power down features. Figure 6. Power Management Setup...
  • Page 81 TP35D2-A7 ACPI & Wake Up Events ACPI Function This item displays the status of the Advanced Configuration and Power Management (ACPI). The Choices: Enabled (default), Disabled. ACPI Suspend Type The item allows you to select the suspend type under the ACPI operating system.
  • Page 82 TP35D2-A7 Wake-Up by PCI card When you select “Enable”, a PME signal from PCI card returns the system to Full On state. The Choices: Disabled (default), Enabled. PCI Express PME The Choices: Disabled (default), Enabled. Power On by Ring An input signal on the serial Ring Indicator (RI) line (in other words, an incoming call on the modem) awakens the system from a soft off state.
  • Page 83 TP35D2-A7 PWRON After PWR-Fail This setting specifies how your system should behave after a power fail or interrupts occurs. By choosing off will leave the computer in the power off state. Choosing On will reboot the computer. Former-Sts will restore the system to the status before power failure or interrupt occurs.
  • Page 84: Power Management

    TP35D2-A7 Power Management This category allows you to select the power saving method and is directly related to the following modes: 1. HDD Power Down. 2. Suspend Mode. There are three options of Power Management, three of which have fixed mode settings Min.
  • Page 85: Suspend Type

    TP35D2-A7 Suspend Type Select the Suspend Type. The Choices: Stop Grant (default), PwrOn Suspend. Modem Use IRQ This determines the IRQ, which can be applied in MODEM use. The Choices: 3 (default), 4, 5, 7, 9, 10, 11, NA. Suspend Mode The item allows you to adjust the system idle time before suspend.
  • Page 86: Pnp/Pci Configurations

    TP35D2-A7 7 PnP/PCI Configurations This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed of the CPU itself uses when communicating with its own special components.
  • Page 87: Irq Resources

    TP35D2-A7 IRQ Resources This submenu will allow you to assign each system interrupt a type, depending on the type of device using the interrupt. When you press the “Press Enter” tag, you will be directed to a submenu that will allow you to configure the system interrupts.
  • Page 88: Pc Health Status

    TP35D2-A7 8 PC Health Status Figure 8: PC Health Status Shutdown Temperature This item allows you to set up the CPU shutdown Temperature. This item is only effective under Windows 98 ACPI mode. The Choices: 70 58℉ (default) , 60 / 1 40℉,65 / 1...
  • Page 89 TP35D2-A7 Temperature 2 This field displays the current temperature of system. Current SYS Temp This field displays the current temperature of the system. Current CPU Temp This field displays the current temperature of CPU. Current CPU FAN Speed This field displays the current speed of CPU fan.
  • Page 90: Overclock Navigator

    Figure 9: Over Clock Navigator OverClock Navigator OverClock .Navigator is designed for beginners in overclock field. Based on many test and experiments from Biostar Engineer Team, OverClock Navigator provides 3 default overclock configurations that are able to raise the system performance.
  • Page 91 TP35D2-A7 Auto OverClock System The Overclock Navigator provides 3 different engines helping you to overclock your system. These engines will boost your system performance to different level. The Choices: V6 Tech Engine This setting will raise about 5%~10% of whole system performance.
  • Page 92: Cpu Clock Ratio

    TP35D2-A7 Manual Overclock System (M.O.S.) MOS is designed for experienced overclock users. It allows users to customize personal overclock setting. Note: Based on our test results; the overclock function achieved the best performance on AMD 3000+ CPU CPU Clock Ratio The Choices: 8X (default).
  • Page 93: System Memory Frequency

    TP35D2-A7 System Memory Frequency The Choices: Auto (default), 533MHz, 677MHz, 800MHz. Memory Frequency This item shows the current memory frequency. CPU Voltage This item allows you to select CPU Voltage Control. The Choices: StartUp (default); Scope: +0.012V~+0.787V. (G)MCH Voltage The Choices: 1.300V (default); Scope: 1.300~1.650V, Interval: 0.025V.
  • Page 94 TP35D2-A7 Integrated Memory Test Integrated Memory Test allows users to test memory module compatibilities without additional device or software. Step 1: This item is disabled on default; change it to “Enable” to precede memory test. Step 2: When the process is done, change the setting back from “Enabled” to...
  • Page 95: Cmos Reload Program (C.r.p.)

    TP35D2-A7 10 CMOS Reload Program (C.R.P.) The CMOS Reload Program (CRP) allows you to save different CMOS settings into BIOS-ROM. You may reload any saved CMOS setting to change system configurations. Moreover, you may save your ideal overclock setting for easier overclocking.
