Viewline Voltmeter
Technical Data
Installation depth
Installation diameter
Deflection angle
Operating Voltage
Accuracy
Current consumption
Operating temperature
Storage temperature
Temperature shock
Climatic test
EMC in conformity with
Standards
Vibration
Mechanical shock
Chemical resistance against - preservative agent
Nominal position
Protection class
Reverse polarity protection yes, 5 minute
Over voltage protection
Technische Änderungen vorbehalten
The reproduction, distribution and utilization of this document as well as the communication of its contents to others without express
authorization is prohibited. Offenders will be held liable for the payment of damages. All right reserved in the event of the grant of a patent,
.
utility model or design
50mm
52mm
90°
8 – 16 Volt, (18-32V)
< 3,6 angular degrees
< 140 mA, including Warning LED
-30°C to +80°C; plated bezels (chrome) -30°C to +70°C
-40°C to +80°C for 48h; plated bezels (chrome) -40°C to +70°C
+90°C for 1h
Range
Transformation time
Retention time
Range
Rel. Humidity
DIN_EN 61000-6-3
DIN_EN 61000-6-1
DIN_EN 61000-6-4
DIN_EN 61000-6-2
EN 60945
GL, Category C, F (under preparation)
Sinus 2g; 10-500Hz; duration 16h
Noise 3g; 10-1000Hz, duration 8h
continuous
Single shock
Free fall
- preservative agent remover
- cold cleaner
- methylated spirit
- interior cleaner
- drinks containing caffeine and tannin
NL 0 to NL 85 (DIN16257)
according to IEC 60529
Front: IP67 (in Nominal position)
Rear: IP52 (in Nominal position)
yes, 24V for1 minute (12V Gauges)
-40°C to +85°C; plated bezels (chrome) -40°C to +70°C
10 seconds
2h
+25°C to +55°C
95%
25g; 6ms; 1Hz
100g; 11ms
1m; 3 times
12/09
Technical details subject to change
2 - 3
