VDO DTCO 1381 Brief Instructions Driver

Insert paper roll
Press the unlocking surface on the printer panel, the printer drawer
opens.
Pull the printer drawer out of the DTCO.
1
Insert new paper roll according to the illustration and guide it via the
pulley (1).
Make sure that the paper roll does not become jammed in the
printer drawer and the start of the paper (1) extends beyond the
edge of the printer drawer!
Push printer drawer into the printer compartment until it engages.
The printer is ready for operation.
You can start a printout.
Messages
1 x1 internal
2
fault xx
(1) Pictogram and plain text of the message
! = Event, example [ ! driving without card ]
x = Fault, example [ x sensor fault ]
 = Driving time warning [ 1 break! ]
Operational note, example [ o no paper ]
(2) Error code
For further messages and measures refer to the operating instructions.
Acknowledge message:
Press key 2 times, the message disappears.
Times of the driver card(s)
".
(1) Driving time "  " since a valid break
1 2
time.
(2) Valid break time "  ", in accordance
103h46 00h15 with regulation (EU) no. 561/2006.
125h57 00h21 (3) Driving time over two weeks "  ".
(4) Duration of the set activity.
3 4
These brief instructions shall not, under any circumstances, be regarded as a substitute for the exhaustive operating instructions
for the DTCO 1381 prescribed by EU Regulation (EEC) no. 3821/85, Annex I B.
Calling up menu functions
Possible only when the vehicle is stationary!
2 12:40 
 123456.7km 
103h46
125h57
201h10
215h00
VDO 
11h00
VDOi
∆|19h58
UTC 29.09.2017
10:40
select
language?
call main menu?
Use the buttons
Use button to call up the main menu.
Use / to select the listed functions step by step.
Print daily value:
[ printout  driver 1 ] ... [ 24h day ] ... [ 25.10.2017 ] ...
[ printout in UTC yes/no]
Enter "Out of scope" beginning / end:
[ entry  vehicle ] ... [ OUT begin ] or [ OUT end ]
Enter Beginning of ferry / train:
[ entry  vehicle ] ... [  ferry/train ]
Set the current activity.
Set Local time:
[ entry  vehicle ] ... [  local time ] ...
Set Local time in steps of ± 30 minutes.
1. Main menu
0km/h
printout
 driver 1
00h15
00h21
... others see operating
00h36
instructions
00h21
00h44
03h23
Option: VDO Counter, for
 9h 2
details see operating
10h 1 instructions.
+02h00
 language
english
/ to select the desired display.
Brief instructions Driver
®
DTCO 1381 – Release 3.0
A2C13870700 / 41024284 OPM 000 AA
BA00.1381.30 500 102
Operational elements
a 1 9
2 3 4 5
(1) Display (5) Combination key Driver 2
(2) Menu buttons Setting of activities and ejection
/ Select function / selection of the driver card
Confirm function / selection (6) Card slot 2
Exit, abort menu (7) Cutting edge
(3) Card slot 1 (8) Printer drawer
(4) Combination key Driver 1 (9) Download interface
Setting of activities and ejection
(a) Symbol for ADR variant
of the driver card
Standard display(s) during trip
Press any menu key, change to the desired display.
(1) Time (with "  " = set local time)
1 2 3
(a)
(2) "Operational mode"
(3) Speed
12:50  75km/h
(4) Activity, driver 1
 123456.7km 
(5) Card symbol, driver 1
(6) Total odometer
4 5 6 7 8
(7) Card symbol, driver 2
(8) Activity, driver 2
1 2
(b)
(1) Driving time "  " Driver 1 since a valid
break time.
101h21 00h15
(2) Valid break time "  ", in accordance with
202h05
regulation (EU) no. 561/2006.
(3) Time of driver 2; availability time "  ".
3
The option "VDO Counter" allows another standard display; for details
refer to the operating instructions.
© 05.2017 Continental Automotive GmbH
www.fleet.vdo.com
