VDO VIEWLINE TACHOMETER Product Information page 2

Viewline Tachometer
Technical Data
Measurement Range
Sensors:
LCD-Size
Alarm output
Illumination
Installation depth
Installation diameter
Deflection angle
Operating Voltage
Accuracy
Current consumption
Operating temperature
Storage temperature
Temperature shock
Climatic test
EMC in conformity with
ESD in conformity with
Vibration
Mechanical shock
Chemical resistance against - preservative agent
Nominal position
Protection class
Reverse polarity protection
Short circuit protection
Technische Änderungen vorbehalten
The reproduction, distribution and utilization of this document as well as the communication of its contents to others without express
authorization is prohibited. Offenders will be held liable for the payment of damages. All right reserved in the event of the grant of a patent,
.
utility model or design
see Table
Hall sensor
Inductive sensor
Blocking oscillator
37 x 11 mm
max 100mA
amber, dimmable
50mm
85mm, 110mm (see table)
240°
8,5 – 32 Volt
+/- 2,5% of full scale reading
< 175 mA, including Warning LED
-20°C to +85°C; plated bezels (chrome) -20°C to +70°C
-40°C to +85°C for 48h; plated bezels (chrome) -40°C to +70°C
+90°C for 1h
Range -40°C to +85°C; plated bezels (chrome) -40°C to +70°C
Transformation time 10 seconds
Retention time 2h
Range +25°C to +55°C
Rel. Humidity 80% to 100%
ISO 7637-1/2
ISO 7637-3
DIN_EN 61000-4-2
ISO/CD 10605
SAE J 551/15)
Sinus 2g; 8-500Hz; duration 16h
Noise 4,2g; 10-1000Hz, duration 8h
continuous 25g; 6ms; 1Hz
Single shock 100g; 11ms
Free fall 1m; 3 times
- preservative agent remover
- cold cleaner
- methylated spirit
- interior cleaner
- drinks containing caffeine and tannin
NL 0 to NL 85 (DIN16257)
according to IEC 60529
Front: IP67 (in Nominal position)
Rear: IP52 (in Nominal position)
yes, 1 minute
yes, 1 minute
12/09
Technical details subject to change
2 - 4
