Summary of Contents for HIKVISION DS-K1T804BMF

  • Page 1 DS-K1T804B Series Fingerprint Access Control Terminal User Manual...
  • Page 2 WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,...
  • Page 3 During the use of device, personal data will be collected, stored and processed. To protect data, the development of Hikvision devices incorporates privacy by design principles. For example, for device with facial recognition features, biometrics data is stored in your device with encryption method;...
  • Page 4 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Indicates a hazardous situation which, if not avoided, will or could Danger result in death or serious injury.
  • Page 5 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 6 DS-K1T804B Series Fingerprint Access Control Terminal User Manual EU Conformity Statement This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the EMC Directive 2014/30/EU, the RoHS Directive 2011/65/EU 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union.
  • Page 7 DS-K1T804B Series Fingerprint Access Control Terminal User Manual This equipment should be installed and operated with a minimum distance 20cm between the radiator and your body. Cet équipement doit être installé et utilisé à une distance minimale de 20 cm entre le radiateur et...
  • Page 8 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into Dangers and Cautions: Dangers: Neglecting any of the warnings may cause serious injury or death.
  • Page 9 • Improper use or replacement of the battery may result in hazard of explosion. Replace with the same or equivalent type only. Dispose of used batteries according to the instructions provided by the battery manufacturer. • You can view the device License via the website: http://opensource.hikvision.com/Home/List? id=46. viii...
  • Page 10 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Available Models The fingerprint access control terminal contains the following models: Product Name Model Fingerprint Access Control Terminal DS-K1T804BF DS-K1T804BMF DS-K1T804BEF Use only power supplies listed in the user instructions: Model Manufacturer...

  • Page 11: Table Of Contents

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Contents Chapter 1 Overview ........................1 Chapter 2 Features ........................2 Chapter 3 Appearance Description ..................... 3 Chapter 4 Device Wiring ......................6 4.1 Terminal Description ......................6 4.2 External Device Wiring ......................9 Chapter 5 Installation .......................
  • Page 12 DS-K1T804B Series Fingerprint Access Control Terminal User Manual 7.6.2 Set Access Control Parameters ................... 26 7.6.3 Set Holiday Group ....................... 28 7.6.4 Set Week Plan ......................31 7.6.5 Set Schedule Template ....................33 7.7 Attendance Status ........................ 34 7.7.1 Set Auto Attendance ....................34 7.7.2 Set Manual Attendance ....................
  • Page 13 DS-K1T804B Series Fingerprint Access Control Terminal User Manual 8.1.2 Add Device by IP Address or Domain Name ............... 57 8.1.3 Add Devices by IP Segment ..................59 8.1.4 Add Device by EHome Account ................... 60 8.1.5 Import Devices in a Batch ................... 61 8.2 Person Management ......................
  • Page 14 DS-K1T804B Series Fingerprint Access Control Terminal User Manual 8.5.3 Configure Custom Wiegand Rule ................82 8.5.4 Configure Card Reader Authentication Mode and Schedule ........83 8.5.5 Configure Other Parameters ..................85 8.6 Configure Linkage Actions for Access Control ..............88 8.6.1 Configure Client Actions for Access Event ..............
  • Page 15 DS-K1T804B Series Fingerprint Access Control Terminal User Manual 9.4 System Maintenance ......................122 9.5 Configure RS-485 Parameters .................... 123 9.6 Security Mode Settings ...................... 123 9.7 Network Parameters Settings .................... 124 9.8 Report Strategy Settings ....................124 9.9 Network Center Parameters Settings ................. 124 9.10 Configure Wi-Fi ........................

  • Page 16: Chapter 1 Overview

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Chapter 1 Overview DS-K1T804B series fingerprint access control terminal is designed with a 2.4-inch LCD display screen. Offline operation, wired network (TCP/IP) and wireless network transmission modes are supported as well. (The models with -1 do not support the wireless network function.)

  • Page 17: Chapter 2 Features

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Chapter 2 Features • Physical doorbell button design, supports connecting external doorbell • Integrated management of access control and the attendance • 2.4-inch LCD screen to display the time, the date and swiping/fingerprint authentication results •...

  • Page 18: Chapter 3 Appearance Description

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Chapter 3 Appearance Description View the device appearance and the keypad's description. Figure 3-1 Device Appearance Note The pictures here are for reference only. Some models do not support card swiping function. For details, refer to the actual product.
  • Page 19 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Figure 3-2 Keypad Description Table 3-2 Keypad Description Description Exiting Key: Press the button to exit the menu. Note If you enable the attendance status function, the exiting key can be the shortcut key of the attendance status.
  • Page 20 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Description Note If you enable the attendance status function, the OK key can be the shortcut key of the attendance status. Deleting Key: Press the key to delete the letters or numbers one by one in the textbox.

  • Page 21: Chapter 4 Device Wiring

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Chapter 4 Device Wiring 4.1 Terminal Description The terminal diagram are as follows.
  • Page 22 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Figure 4-1 Terminal Diagram...
  • Page 23 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Table 4-1 Wiring with Secure Door Control Unit Description Cable Group Function Color Terminal Description Name Group A Power Input +12 V 12 VDC Power Supply Black Group B Alarm Input Yellow/Blue...

  • Page 24: External Device Wiring

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Cable Group Function Color Terminal Description Name Yellow/Grey BUTTON Exit Door Wiring Doorbell White/Brown BELL+ Doorbell Wiring White/Blue BELL- 4.2 External Device Wiring Wire the external device. The wiring diagram is as follows.

  • Page 25: Chapter 5 Installation

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Chapter 5 Installation Before You Start • Make sure that the device in the package is in good condition and all the assembly parts are included. • Make sure that the wall is strong enough to withstand three times the weight of the device.
  • Page 26 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Figure 5-3 Install Device 6. Fix the device with one screw on the mounting plate and complete the installation. Figure 5-4 Secure Note The pictures in this documentation are for references only, refer to the actual product.

  • Page 27: Chapter 6 Activation

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Chapter 6 Activation You should activate the device before the first login. After powering on the device, the system will switch to Device Activation page. Activation via the device, SADP tool and the client software are supported.
  • Page 28 • Get the SADP software from the supplied disk or the official website http:// www.hikvision.com/en/ , and install the SADP according to the prompts. • The device and the PC that runs the SADP tool should be within the same subnet.

  • Page 29: Activate Device Via Client Software

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 6.3 Activate Device via Client Software For some devices, you are required to create the password to activate them before they can be added to the software and work properly. Steps Note This function should be supported by the device.

  • Page 30: Chapter 7 Local Settings

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Chapter 7 Local Settings 7.1 Select Language You can select a language for the device system. After the device activation, you can select a language for the device system. By default, the system language is English.
  • Page 31 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Figure 7-1 Add Administrator 2. Enter the new user's parameters. ID (Employee ID) By default, the ID No. will be increased in sequence. You can edit the ID according to your preference.
  • Page 32 DS-K1T804B Series Fingerprint Access Control Terminal User Manual View Info.: View the user's added card information. Note • The card No. is required. • Up to 20 digits can be contained in the card No. • The card No. can be 0.

  • Page 33: Local Login

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual according to the configured authentication mode. By default, the authentication mode is Controller. This mode is applicable to edit users' authentication modes in batch. • If an user needs to use a special authentication mode, which is different from the authentication mode configured in Set Access Control Parameters , he can use card/ fingerprint, card, etc.

  • Page 34: Set Network

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 7.4.1 Set Network You can set the device network parameters, including the IP address, the subnet mask, the gateway address, and the DHCP. Steps 1. Move the cursor and select Comm. → Network .

  • Page 35: Change Verification Code

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 4. Select a Wi-Fi from the list and set the Wi-Fi parameters, including the Wi-Fi password and DHCP. - Enable DHCP, and the system will automatically assign IP address for the Wi-Fi.
  • Page 36 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Figure 7-3 EHome Settings 2. Enable the EHome function and set the EHome server parameters. Center Group 1 Enable center group 1 and the data will be uploaded to the center group.

  • Page 37: Set Wiegand Parameters

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 7.4.5 Set Wiegand Parameters You are able to set the Wiegand direction (send/receive) and the Wiegand mode (Wiegand 26/ Wiegand 34). Steps 1. Move the cursor and select Comm. → Wiegand .
  • Page 38 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Figure 7-4 New Page 2. Enter the new user's parameters. ID (Employee ID) By default, the ID No. will be increased in sequence. You can edit the ID according to your preference.
  • Page 39 DS-K1T804B Series Fingerprint Access Control Terminal User Manual View Info.: View the user's added card information. Note • The card No. is required. • Up to 20 digits can be contained in the card No. • The card No. can be 0.

  • Page 40: Manage Person (Search/Edit/Delete)

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual the configured authentication mode. By default, the authentication mode is Controller. This mode is applicable to edit users' authentication modes in batch. • If an user needs to use a special authentication mode, which is different from the authentication mode configured in Set System Parameters , he can use card/fingerprint, card, etc.

  • Page 41: Access Control

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Clear Card Delete all added cards of the selected user. 7.6 Access Control Configure the access control permission, including the access control parameters, the holiday group, the week plan and the schedule template.
  • Page 42 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Figure 7-6 Access Control Parameters The available parameters descriptions are as follows: Table 7-1 Access Control Parameters Descriptions Parameter Description Terminal Auth Select the face recognition terminal's authentication mode. You can also customize the authentication mode.

  • Page 43: Set Holiday Group

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Parameter Description Door-Open Timeout Alarm Configure the maximum time duration for door opening. If the door-open time has exceeded the configured value, it will trigger an alarm. Auth Times Exceeded Alarm Configure the maximum times for authentication.
  • Page 44 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Figure 7-8 Add Holiday Group 3. Add new holiday. 1) Select New ACS Holiday.
  • Page 45 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Figure 7-9 Add New Holiday 2) Set the holiday name, start and end time. 3) Set the holiday period for access. Note Up to 8 periods can be edited. During the holiday time, the attendance will be invalid and the person cannot control the door status.

  • Page 46: Set Week Plan

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 7.6.4 Set Week Plan Configure the week plan for the access control function. The door can be controlled during the configured time. Steps 1. Tap ACS → WK. Plan . Figure 7-10 Week Plan List...
  • Page 47 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Figure 7-11 Add New Week Plan 3. Set the week plan's parameters, including the week plan name, the week plan time,a the periods. Note The person can take attendance or control the door status according to the configured week plan.

  • Page 48: Set Schedule Template

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 7.6.5 Set Schedule Template Set the configured week plan and the holiday group. The door can be controlled in the configured time duration. Steps 1. Tap ACS → Template . Figure 7-12 Template List 2.

  • Page 49: Attendance Status

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 7.7 Attendance Status Set attendance mode and choose attendance status. You can set the attendance status as check in, check out, break out, break in, overtime in, and overtime out according to your actual situation.

  • Page 50: Set Manual Attendance

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 08:00, and check out's schedule as Monday 17:00, the valid person's authentication before 17:00 on Monday will be marked as check in. And the valid person's authentication after 17:00 on Monday will be marked as check out.

  • Page 51: Set Manual And Auto Attendance

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Result Press a key on the keypad to select an attendance status and authenticate. The authentication will be marked as the configured attendance status according to the defined shortcut key. Or when you authenticate on the initial page, you will enter the Select Status page. Select a status to take attendance.

  • Page 52: Disable Attendance Mode

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 4. Move the cursor and select Shortcut Key and define the shortcut key's attendance status and schedule. Note The attendance status will be valid within the configured schedule. For example, if set the Up...

  • Page 53: Time And Attendance Management

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 7.8 Time and Attendance Management Manage department, shift, holiday, schedule, and report. You can add, edit, delete department/shift/holiday/schedule. You can also export the attendance report. Move the cursor and select Attendance to enter the Attendance page.

  • Page 54: Shift Management

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual • You can configure the shift in the Shift Management. For detailed information, see Shift Management . • By default, the system contains 32 departments. • Press the up or down key on the keypad to change the input method.
  • Page 55 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Figure 7-20 Attendance Rule Page Set the attendance rule. On-work Advanced Time The allowable early duration to go to work. Latest On-Work Check Time The allowable late duration to go to work.
  • Page 56 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Steps 1. Move the cursor and select Shift → Normal to enter the Normal page. Figure 7-21 Normal Shift Page 2. Select a shift and press OK. Note By default, the normal shift type includes 2/Day (2 times per day), 4/Day (4 times per day), and 30 custom types.

  • Page 57: Manage Holiday (Add/Search/Edit/Delete)

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Figure 7-22 Man-Hour Shift Page 2. Select a shift from the list, and press OK . 3. Select Edit to enter the Edit Shift page. Note By default, the man-hour shift type includes 6H/Day (6 hours per day), 8H/Day (8 hours per day), and 30 custom types.

  • Page 58: Shift Schedule

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Figure 7-24 Add Holiday Page Search Holiday Move the cursor and select Holiday → Holiday to enter the holiday list. Enter a holiday name and press OK to start search. Edit Holiday Move the cursor and select Holiday →...
  • Page 59 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Steps 1. Move the cursor and select Schedule → Dept. Shift to enter the Dept. Shift page. 2. Select a department from the list and press OK to enter the Edit Shift Schedule by Dept. page.
  • Page 60 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Before You Start • Add user before setting schedule shift by individual. For details, see Add Person . • Set the normal shift or the man-hour shift. For details, see Set Normal Shift and Set Man-Hour Shift .

  • Page 61: Export Attendance Report

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 7.8.6 Export Attendance Report Export the attendance record, the attendance report, the abnormal attendance record and the attendance management schedule. Steps 1. Plug in a USB flash drive in the USB interface.

  • Page 62: Data Transfer

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 7.9 Data Transfer You can export the access control parameters (fingerprint and user information) and the attendance data (data after attendance, card swiping data for instance). You can also import the access control parameters from the USB flash drive.

  • Page 63: Basic Settings

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 7.10 Basic Settings 7.10.1 Set Time Set the device time and DST. Steps 1. Move the cursor and select Time in the main page and press OK to enter the Time page.

  • Page 64: Manage System Data

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual • DST Bias: You can select 30min, 60min, 90min and 120min. • Start: Set the start time of the DST. • End: Set the end time of the DST. 3. Press ESC and select Yes to save the settings and exit the page.

  • Page 65: Set System Parameters

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 7.10.3 Set System Parameters Set the system parameters, including the device time format, the keypad sound, the voice prompt, the volume, the sleeping mode, the attendance record prompt the authentication mode, record delete function, and the language.

  • Page 66: System Upgrade

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Sleeping Set the device sleeping waiting time (minute). When you are on the initial page and if you set the sleeping time to 30 min, the device will sleep after 30 min without any operation.

  • Page 67: Restore Settings

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Note • The upgrading file should be in the root directory. • The upgrading file name in the USB flash drive should be digicap.dav. • Do not power off during the device upgrading.

  • Page 68: View System Information

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Figure 7-33 Log Query Page 2. Enter the employee ID, the user name, the card No., the start time, and the end time. 3. Press OKto start searching. The result will be displayed on the page.
  • Page 69 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Figure 7-34 Capacity Page View Device Information Move the cursor and select Info. → Device to enter the Device page. You can view the device name, the serial No., the MAC address, the firmware, and the production date.

  • Page 70: Chapter 8 Client Software Configuration

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Chapter 8 Client Software Configuration 8.1 Add Device The client provides three device adding modes including by IP/domain, IP segment, and ISUP protocol. The client also supports importing multiple devices in a batch when there are large amount of devices to be added.
  • Page 71 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Password Enter the device password. Caution The password strength of the device can be automatically checked. We highly recommend you change the password of your own choosing (using a minimum of 8 characters, including at least three kinds of following categories: upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.

  • Page 72: Add Device By Ip Address Or Domain Name

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual By default, the user name is admin. Password Enter the device password. Caution The password strength of the device can be automatically checked. We highly recommend you change the password of your own choosing (using a minimum of 8 characters, including at least three kinds of following categories: upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 73 DS-K1T804B Series Fingerprint Access Control Terminal User Manual The IP address or domain name of the device. Port The devices to add have the same port No. The default value is 8000. User Name Enter the device user name. By default, the user name is admin.

  • Page 74: Add Devices By Ip Segment

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 8.1.3 Add Devices by IP Segment If you want to add devices of which the IP addresses are within an IP segment, you can specify the start IP address and end IP address, user name, password, and other parameters to add them.

  • Page 75: Add Device By Ehome Account

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual - Click Add to add the device and back to the device list page. - Click Add and New to save the settings and continue to add other device. 9. Optional: Click on Operation column to view device status.

  • Page 76: Import Devices In A Batch

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Check Online User Click on Operation column to check the online users who access the device, such as user name, user type, user's IP address, and login time. Refresh Click on Operation column to get the latest device information.

  • Page 77: Person Management

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual you change your password regularly, especially in the high security system, changing the password monthly or weekly can better protect your product. Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user.

  • Page 78: Configure Basic Information

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 4. Optional: Perform the following operation(s). Edit Organization Hover the mouse on an added organization and click to edit its name. Delete Hover the mouse on an added organization and click to delete it.
  • Page 79 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Steps 1. Enter Person module. 2. Select an organization in the organization list to add the person and click Add to enter Add Person panel. Note Enter the person's basic information first. For details about configuring person's basic information, refer to Configure Basic Information .

  • Page 80: Collect Fingerprint Via Client

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Note Currently, the supported card enrollment station models include DS-K1F100-D8, DS-K1F100- M, DS-K1F100-D8E, and DS-K1F180-D8E. Card Type This field is only available when the model is DS-K1F100-D8E or DS-K1F180-D8E. Select the card type as EM card or Mifare card according to the actual card type.

  • Page 81: Collect Fingerprint Via Access Control Device

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Note If the fingerprint recorder is DS-K1F800-F, you can click Settings to select the COM the fingerprint recorder connects to. 6. Collect the fingerprint. 1) Click Start. 2) Place and lift your fingerprint on the fingerprint recorder to collect the fingerprint.

  • Page 82: Configure Access Control Information

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual - Click Add and New to add the person and continue to add other persons . Note Once the fingerprint is added, the fingerprint type cannot be changed. 8.2.6 Configure Access Control Information When adding a person, you can set her/his access control properties, such as setting the person as visitor or as blocklist person, or as super user who has super authorization.

  • Page 83: Configure Additional Information

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Steps 1. Enter Person module. 2. Set the fields of custom information. 1) Click Custom Property. 2) Click Add to add a new property. 3) Enter the property name. 4) Click OK.

  • Page 84: Import Person Information

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 8.2.10 Import Person Information You can enter the information of multiple persons in a predefined template (a CSV file) to import the information to the client in a batch. Steps 1. Enter the Person module.

  • Page 85: Get Person Information From Access Control Device

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 8.2.12 Get Person Information from Access Control Device If the added access control device has been configured with person information (including person details, fingerprint, and issued card information), you can get the person information from the device and import them to the client for further operations.

  • Page 86: Issue Cards To Persons In Batch

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 8.2.14 Issue Cards to Persons in Batch The client provides a convenient way to issue cards to multiple persons in a batch. Steps 1. Enter Person module. 2. Click Batch Issue Cards.

  • Page 87: Configure Schedule And Template

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual PC running the client by USB interface or COM, and place the card on the card enrollment to read the card number. If not, you can also swipe the card on the card reader of the added access control device to get the card number.

  • Page 88: Add Holiday

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 8.3.1 Add Holiday You can create holidays and set the days in the holidays, including start date, end date, and holiday duration in one day. Steps Note You can add up to 64 holidays in the software system.
  • Page 89 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Steps Note You can add up to 255 templates in the software system. 1. Click Access Control → Schedule → Template to enter the Template page. Note There are two default templates: All-Day Authorized and All-Day Denied, and they cannot be edited or deleted.

  • Page 90: Set Access Group To Assign Access Authorization To Persons

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 4) Optional: Select a selected holiday in the right list and click to remove the selected one, or click Clear to clear all the selected holiday(s) in the right list. 7. Click Save to save the settings and finish adding the template.

  • Page 91: Configure Advanced Functions

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Caution • Be careful to click Apply All to Devices, since this operation will clear all the access groups of the selected devices and then apply the new access group, which may brings risk to the devices.
  • Page 92 DS-K1T804B Series Fingerprint Access Control Terminal User Manual 3. Turn the switch to ON to enable the corresponding functions. Note • The displayed parameters may vary for different access control devices. • Some of the following parameters are not listed in the Basic Information page, click More to edit the parameters.
  • Page 93 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Note • The displayed parameters may vary for different access control devices. • Some of the following parameters are not listed in the Basic Information page, click More to edit the parameters.
  • Page 94 DS-K1T804B Series Fingerprint Access Control Terminal User Manual 6. Optional: Click Copy to , and then select the door to copy the parameters in the page to the selected doors. Note The door's status duration settings will be copied to the selected door as well.
  • Page 95 DS-K1T804B Series Fingerprint Access Control Terminal User Manual 4. Click Advanced and you can configure more parameters. Enable Card Reader Enable the function and you can operate the functions below on the card reader. OK LED Polarity/Error LED Polarity/Buzzer Polarity Set OK LED Polarity/Error LED Polarity/Buzzer LED Polarity of main board according to the card reader parameters.

  • Page 96: Configure Remaining Open/Closed

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 8.5.2 Configure Remaining Open/Closed You can set the status of the door as open or closed. For example, you can set the door remaining closed in the holiday, and set the door remaining open in the specified period of the work day.

  • Page 97: Configure Custom Wiegand Rule

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Note Up to 8 time durations can be set to one holiday period. 5) Perform the following operations to edit the time durations. • Move the cursor to the time duration and drag the time duration on the timeline bar to the desired position when the cursor turns to •...

  • Page 98: Configure Card Reader Authentication Mode And Schedule

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Note • Up to 80 bits are allowed in the total length. • The odd parity start bit, the odd parity length, the even parity start bit and the even parity length range from 1 to 80 bit.
  • Page 99 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Steps 1. Click Access Control → Advanced Function → Authentication to enter the authentication mode configuration page. 2. Select a card reader on the left to configure. 3. Set card reader authentication mode.

  • Page 100: Configure Other Parameters

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Figure 8-4 Set Authentication Modes for Card Readers 6. Optional: Select a configured day and click Copy to Week to copy the same settings to the whole week. 7. Optional: Click Copy to to copy the settings to other card readers.
  • Page 101 DS-K1T804B Series Fingerprint Access Control Terminal User Manual 5. Check Enable to enable to set the uploading mode. 6. Select the uploading mode from the drop-down list. - Enable N1 or G1 for the main channel and the backup channel.
  • Page 102 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Enable M1 Card Encryption M1 card encryption can improve the security level of authentication. Steps Note The function should be supported by the access control device and the card reader. 1. Enter the Access Control module.

  • Page 103: Configure Linkage Actions For Access Control

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual • The configured parameters will be applied to the device automatically. • When you change the working mode or connection mode, the device will reboot automatically. Set Wiegand Parameters You can set the access control device's Wiegand channel and the communication mode. After setting the Wiegand parameters, the device can connect to Wiegand card reader via Wiegand communication.

  • Page 104: Configure Client Actions For Access Event

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 8.6.1 Configure Client Actions for Access Event Even if you are far away from an access point, you can still know what happens and how urgent the event is by configuring linked actions of access event on the client. You will be notified on the client once an event is triggered, so that you can response to the event instantly.

  • Page 105: Configure Device Actions For Access Event

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 8.6.2 Configure Device Actions for Access Event You can set the access control device's linkage actions for the access control device's triggered event. When the event is triggered, it can trigger the alarm output, host buzzer, and other actions on the same device.

  • Page 106: Configure Device Actions For Person Id

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 7. In the Linkage Target area, set the property target to enable this action. Buzzer on Controller The audible warning of access control device will be triggered. Buzzer on Reader The audible warning of card reader will be triggered.

  • Page 107: Door Control

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Edit Linkage Select the configured linkage settings in the device list and you can edit Settings its event source parameters, including event source and linkage target. 8.7 Door Control In Monitoring module, you can view the real-time status of the doors managed by the added access control device.

  • Page 108: Check Real-Time Access Records

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Remain Closed The door will be closed and locked. No person can access the door even if he/she has the authorized credentials, except the super users. Capture Capture a picture manually. Note The Capture button is available when the device supports capture function.

  • Page 109: Event Center

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 8.8 Event Center You can configure the event of the added resources and set the linkage actions so that when the event is triggered, the software client can notify the security personnel and record the event details for checking afterwards.

  • Page 110: View Real-Time Events

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 8.8.2 View Real-Time Events In the Real-time Event module of the event center page, you can view the real-time event information, including event source, event time, priority, event key words, etc. Before You Start Enable receiving events from devices before the client can receive event information from the device, see Enable Receiving Events from Devices for details.
  • Page 111 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Figure 8-7 Customize Event Related Items to be Displayed 4. View the event information details. 1) Select an event in the event list. 2) Click Expand in the right-lower corner of the page.

  • Page 112: Search Historical Events

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Note You should configure the email parameters first, see Set Email Parameters in the user manual of client software for details. 8.8.3 Search Historical Events In the Event Search module of the event center page, you can search the historical events via time, device type, and other conditions according to the specified device type, and then process the events.
  • Page 113 DS-K1T804B Series Fingerprint Access Control Terminal User Manual All the device types, and you can set the following filter conditions: group, priority, and status. Video Intercom For the events of video intercom, you need to select searching scope: All Record and Only Unlocking.
  • Page 114 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Figure 8-9 Customize Event Related Items to be Displayed 5. Optional: Handle the event(s). - Handle single event: Select one event that need to be processed, and then click Handle in the event information details page, and enter the processing suggestion.

  • Page 115: Time And Attendance

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 8.9 Time and Attendance The Time and Attendance module provides multiple functionalities to track and monitor when employees start and stop work, and full control of employees working hours such as late arrivals, early departures, time taken on breaks and absenteeism.
  • Page 116 DS-K1T804B Series Fingerprint Access Control Terminal User Manual When you work for a certain period after end-work time on workday, you will reach different overtime level: overtime level 1, overtime level 2 and overtime level 3. You can set different work hour rate for three overtime levels, respectively.
  • Page 117 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Add Regular Holiday You can configure a holiday which will take effect annually on regular days during the effective period, such as New Year's Day, Independence Day, Christmas Day, etc. Steps 1. Enter the Time & Attendance module.
  • Page 118 DS-K1T804B Series Fingerprint Access Control Terminal User Manual The added holiday will display in the holiday list and calendar. If the date is selected as different holidays, it will be recorded as the first-added holiday. 11. Optional: After adding the holiday, perform one of the following operations.
  • Page 119 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Note If you select MySql, you should import the configuration file (libmysql.dll) from local PC. 5. Set the other required parameters of the third-party database, including server IP address, database name, user name and password.

  • Page 120: Add General Timetable

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual The fixed break duration will be excluded from work hours. Must Check The break duration will be calculated and excluded from work hours according to actual check-in and check-out time. Note If you select Must Check as calculation method, you need to set attendance status for late or early returning from break.
  • Page 121 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Figure 8-10 Add Timetable 3. Create a name for the timetable. Note You can click the color icon beside the name to customize the color for the valid timetable on the time bar in the Configuration Result area.

  • Page 122: Add Shift

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Note This function should be supported by the device. 7. Set the related attendance time parameters as the following: Start/End-Work Time Set the start-work time and end-work-time. Valid Check-in/out Time On the time bar, adjust the yellow bar to set the timetable during which the check-in or check-out is valid.
  • Page 123 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Before You Start Add a timetable first. See Add General Timetable for details. Steps 1. Click Time & Attendance → Shift to enter shift settings page. 2. Click Add to enter Add Shift page.
  • Page 124 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Figure 8-12 Add Multiple Timetables 6. Click Save. The added shift lists on the left panel of the page. At most 64 shifts can be added. 7. Optional: Assign the shift to organization or person for a quick shift schedule.

  • Page 125: Manage Shift Schedule

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 8.9.4 Manage Shift Schedule Shift work is an employment practice designed to make use of all 24 hours of the clock each day of the week. The practice typically sees the day divided into shifts, set periods of time during which different shifts perform their duties.
  • Page 126 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Persons in this schedule do not need to check-in when they come to work. Check-out Not Required Persons in this schedule do not need to check-out when they end work. Scheduled on Holidays On the holidays, this schedule is still effective and the persons needs to go to work according to the schedule.
  • Page 127 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Check-in Not Required Persons in this schedule do not need to check-in when they come to work. Check-out Not Required Persons in this schedule do not need to check-out when they end work.

  • Page 128: Manually Correct Check-In/Out Record

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual effective in any of the three timetables. If the person checks in at 07:50, it will apply the nearest timetable 08:00 to 15:00 to the person's attendance. Rule Set other rule for the schedule, such as Check-in Not Required, andCheck-out Not Required.

  • Page 129: Add Leave And Business Trip

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Note You can click to add multiple check in/out items. At most 8 check-in/out items can be supported. 6. Optional: Enter the remark information as desired. 7. Click Save. 8. Optional: After adding the check-in/out correction, perform one of the following operations.

  • Page 130: Calculate Attendance Data

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 6. Set the time for leave. 7. Optional: Enter the remark information as desired. 8. Click Save. 9. Optional: After adding the leave and business trip, perform one of the following operations.

  • Page 131: Attendance Statistics

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual The client will calculate the attendance data of the previous day from the time you have configured. Manually Calculate Attendance Data You can calculate the attendance data manually by setting the data range.
  • Page 132 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Note • The client will automatically calculate the previous day's attendance data at 1:00 am on the next day. • Keep the client running at 1:00 am or it cannot calculate the previous day's attendance data automatically.
  • Page 133 DS-K1T804B Series Fingerprint Access Control Terminal User Manual 5. Set the start time and end time during which the attendance data will be displayed in the report. 6. Click Report to generate the statistics report and open it. Custom Attendance Report The client supports multiple report types and you can pre-define the report content and it can send the report automatically to the email address you configured.
  • Page 134 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Note Make sure the attendance records are calculated before the sending time. You can calculate the attendance data manually, or set the schedule so that the client can calculate the data automatically every day. For details, refer to Calculate Attendance Data .

  • Page 135: Chapter 9 Remote Configuration (Web)

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Chapter 9 Remote Configuration (Web) Configure device parameters remotely. 9.1 View Device Information View and set device name, view device type, serial No., version, relay number, and lock number. Select a device from the Device for Management tab and click →...

  • Page 136: Change Device Password

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 9.2 Change Device Password You can change the device password. Before You Start Make sure the device is activated. For details, see Activation. Steps 1. On the Device for Management page, click →...

  • Page 137: System Maintenance

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Manual Time Synchronization After you enable Manual Time Synchronization, you can manually set the device time. If you check Synchronize with Computer Time, the Set Time will display the current computer's time. At this time, uncheck Synchronize with Computer Time, and click , you can edit the device time manually.

  • Page 138: Configure Rs-485 Parameters

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Note • If you select Card reader as the device type, you should also select a card reader No. from the drop-down list. • The upgrade will lasts for about 2 min. Do not power off during the upgrading. After upgrading, the device will reboot automatically.

  • Page 139: Network Parameters Settings

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 9.7 Network Parameters Settings Set device network parameters, including the NIC type, DHCP, and HTTP. On the Device for Management page, click → Network → Network Parameters to enter the Network Parameters Settings tab.

  • Page 140: Configure Wi-Fi

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual After enabling the function, you can set the center's address type, IP address/domain name, and port No., create EHome user name, etc. Note If set the EHome type as EHome5.0, you should create an EHome key as well.

  • Page 141: Configure Volume Input Or Output

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 9.13 Configure Volume Input or Output Steps 1. On the Device for Management page, click → Image → Audio Input or Output to enter Audio Input or Output tab. 2. Move the block to adjust the device input and output volume.

  • Page 142: Chapter 10 Mobile Client Configuration

    • Visit https://appstore.hikvision.com to download the application according to your mobile phone system. • Visit the official website of our company. Then go to Support → Tool → Hikvision App Store to download the application according to your mobile phone system.

  • Page 143: Set Door Open Duration

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual 2. Control the door status. Remain Open Keep the door open. Open Door Open the door for a configurable time period. When the time period expires, the door will close. Note For details about configuring the time period, see Set Door Open Duration .

  • Page 144: Change Super Password

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Note For details about how to enter the Live View page, see Start and Stop Live View on the user manual of Hik-Connect mobile client. For details about how to enter the Live View page, see Start and Stop Live View on the user manual of Guarding Vision mobile client.

  • Page 145: View Access Control Logs

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Note If it is the first time to set the super password, skip this step. 4. Create a new password and then tap Finish. Note The password should contain 6 numbers. 10.4 View Access Control Logs You can view the access control device's logs including the access control events and alarm information.

  • Page 146: Appendix A. Tips For Scanning Fingerprint

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Appendix A. Tips for Scanning Fingerprint Recommended Finger Forefinger, middle finger or the third finger. Correct Scanning The figure displayed below is the correct way to scan your finger: You should press your finger on the scanner horizontally. The center of your scanned finger should align with the scanner center.
  • Page 147 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Others If your fingerprint is shallow, or it is hard to scan your fingerprint, we recommend you to use other authentication methods. If you have injuries on the scanned finger, the scanner may not recognize. You can change another...

  • Page 148: Appendix B. Access Control Capacity

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Appendix B. Access Control Capacity View the access control data's capacity, including the card permission, door status, card reader authentication mode, and attendance data. Table B-1 Card Permission Content Maximum Configurable Parameters...
  • Page 149 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Table B-4 Attendance Content Maximum Configurable Parameters Department Normal Shift Man-Hour Shift Holiday Holiday Group Schedule by Department Schedule by Individual...

  • Page 150: Appendix C. Attendance Record Deleting Rule

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Appendix C. Attendance Record Deleting Rule Enable Record Delete Set the percentage of the attendance record over threshold prompt. 1. When the record reaches the threshold, an alarm of the attendance record over limit value will be displayed on device screen.

  • Page 151: Appendix D. Attendance Report Table

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Appendix D. Attendance Report Table Enter a short description of your concept here (optional). This is the start of your concept. Description of Attendance Report File Name File Name Rule: Device No. + Report Type.xls Device No.: A serial of numbers from 0 to 8.
  • Page 152 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Normal Shift Table Normal Shift Create Time: 2017-04-26 10:12:20 Shift Shift Period 1 Period 2 Period 3 Period 4 Name Start Stop Start Stop Start Stop Start Stop Normal Shift Table: Up to 4 periods can be configured in normal shift configuration. You are able to take attendance according to the configured period.
  • Page 153 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Duration (min) Abnormal Attendance Record Table: Calculate the abnormal attendance according to the attendance records and the shift schedule configuration. • Employee ID: The user's ID No. • Card No.: The user's card No.
  • Page 154 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Card Name Depart Late Late Early Absence Absence Attenda Employ ee ID ment Times Duratio Leave Times Time nce/ n (min) Duratio Duratio Total n (min) n (min) Work Days Attendance Summary Table: Enter the start time and the end time to calculate the user attendance information via the shift information and the holiday information according to the shift schedule configuration.

  • Page 155: Appendix E. Custom Wiegand Rule Descriptions

    DS-K1T804B Series Fingerprint Access Control Terminal User Manual Appendix E. Custom Wiegand Rule Descriptions Take Wiegand 44 as an example, the setting values in the Custom Wiegand tab are as follows: Custom Wiegand Wiegand 44 Name Total Length Transformation Rule...
  • Page 156 DS-K1T804B Series Fingerprint Access Control Terminal User Manual Even Parity Start Bit, and Length If you select Even Parity, these items are available. If the even parity start bit is 12, and the length is 12, then the system will start even parity calculation from bit 12. It will calculate 12 bits. The result will be in the last bit.

  • Page 157: Appendix F. Communication Matrix And Device Command

    Device Command Scan the following QR code to get the device common serial port commands. Note that the command list contains all commonly used serial ports commands for all Hikvision access control and video intercom devices. Figure F-2 Device Command...
  • Page 158 UD22717B...

Table of Contents

Save PDF
