HIKVISION DS-K1T809MWX Quick Start Manual

Access Control Terminal
Quick Start Guide
UD39491B
Scan the QR code to get the user manual for more details.
Quick Guide
1 Installation and Wiring
Check the environment, install the device and wire the devices.
1
Installation and Wiring
1.1 Check Environment
• The minimum bearing weight of the wall or other places should be
3 times heavier than the device weight.
• Please prepare the following tools and accessories: screwdriver
(self purchased), screws, cables, and adapters
1.2 Installation
1 Attach the installation sticker to 2
the wall about 1.45 m from the
ground or the location where
the device needs to be installed,
and punch the hole according to
the hole location (hole 1 and
hole 2) on the sticker and wall.
40.20 mm
4
Secure the
3
Make sure the cables are
the gang box with two supplied
threaded through the hole.
screws
1.3 Wiring
Electric Dropbolt
Door Lock
Power Interface
Red 12VOUT
Black GND
i
• Use a DC 12 V power supply. Do not connect the device directly to
the 220 V mains.
• The suggested external power supply for door lock is 12 V, 1 A.
Activate the device and perform relevant operations according
to the commands.
(self purchased).
Insert the plastic sleeve of
the provided expansion
screw into the punched hole.
5
mounting plate on Complete the wiring. See
the wiring diagram below
(PA4X25-SUS).
(1.3) for details.
Insulating Tape
+ -
(Self Purchased)
Electric
+ -
Strike
（NC）
（COM）
Door Contact
Exit Button
+
-
Power
Door Bell
Power Adaptor
(Self Purchased)
2 Activation and Settings
Appearance
21.5
48
20
Keypad
Door Bell
Card
Presenting
Area
Unit: mm
6
Hang the device into the plate
from top to bottom. Secure
the device on the mounting
plate with 1 supplied screw
(SC-KM3X8-T10-SUS-NL).
Power Supply, Door Lock,
Green W0 Wiegand,
Contact, Exit Button,
and Door Bell Interface
White
W1
Black GND(Reusable Connection)
White/Purple NC
White/Yellow COM
White/Red NO
Yellow/Green
SENSOR
Yellow/Grey
BUTTON
Black
GND
Yellow BELL+
Blue BELL-
Red 12VDC
GND
Black
Door
