Either operation saves the machine's logical volume structure to the /etc/Acronis directory. Make
sure that the volume with this directory is selected for backup.
2.8.4

Selecting logical volumes and MD devices in command line

Let's assume that the system has four physical disks: Disk 1, Disk 2, Disk 3 and Disk 4.

A RAID-1 volume is configured on two basic volumes: sdb1, sdd1
 A logical volume is configured on two basic volumes: sdb2, sdd2

Disk 1 includes Acronis Secure Zone, which normally is not backed up.
A list of a volumes can be obtained with the following command:
trueimagecmd --list
Num Partition
---- -------------------- ----------- ---------- ---------- -----------
Disk 1 (sda):
1-1 sda1
1-2 sda2
1-3 sda3
Unallocated
1-4 Acronis Secure Zone
Unallocated
Disk 2 (sdb):
2-1 sdb1
2-2 sdb2
Unallocated
Disk 3 (sdc):
Table
Unallocated
Disk 4 (sdd):
4-1 sdd1
4-2 sdd2
Unallocated
Dynamic & GPT Volumes:
DYN1 VolGroup00-LogVol00
DYN2 md0
The logical volume, DYN1, occupies basic volumes 2-2 and 4-2. The RAID-1 volume, DYN2, occupies
basic volumes 2-1 and 4-1.
To back up the logical DYN1 volume, run the following command (here, the name of the backup is
assumed to be /home/backup.tib):
trueimagecmd --partition:dyn1 --filename:/home/backup.tib --create
To back up the RAID-1 volume DYN2, run the following command:
trueimagecmd --partition:dyn2 --filename:/home/backup.tib --create
To back up all three hard disks with volumes, select the volumes 1-1, 1-2, 1-3, DYN1 and DYN2:
34
Flags Start
Pri,Act 63
Pri 417690
Pri 24997140
27101655
Pri 32499495
33543720
Pri 62
Pri 250001
500001
0
1
Pri 62
Pri 250001
500001
Disk: 3 250385
Disk: 5 250385
Disk: 5 62
Disk: 3 62
Size Type
208813 Ext2
12289725 ReiserFS
1052257 Linux Swap
2698920 Unallocated
522112 FAT32
5356 Unallocated
124969 Ext2
125000 None
8138607 Unallocated
Table
1048575 Unallocated
124969 Ext2
125000 None
798575 Unallocated
245760 Ext3
245760
245760
124864 Ext2
249728
249728
