USER GUIDE
ADVANCED 2/4/8-PORT
DISPLAYPORT SECURE
KVM SWITCH
USM-2S0-MM7
CONSOLE
12VDC
MODELS:
• KVS4-1002V
• KVS4-2002V
• KVS4-2002VX
• KVS4-1004V
• KVS4-2004V
• KVS4-2004VX
• KVS4-4004VX
• KVS4-1008V
• KVS4-1008VX
• KVS4-2008VX
REV: 3.0A
DP OUT B
DP OUT A
K/M
AUDIO
CAC
2-Port SH Secure Pro DP KVM w/audio, NO CAC
2-Port DH Secure Pro DP KVM w/audio, NO CAC
2-Port DH Secure Pro DP KVM w/audio and CAC
4-Port SH Secure Pro DP KVM w/audio, NO CAC
4-Port DH Secure Pro DP KVM w/audio, NO CAC
4-Port DH Secure Pro DP KVM w/audio and CAC
4-Port QH Secure Pro DP KVM w/audio and CAC
8-Port SH Secure Pro DP KVM w/audio, NO CAC
8-Port SH Secure Pro DP KVM w/audio and CAC
8-Port DH Secure Pro DP KVM w/audio and CAC
ST1
ST2
1
2
DP IN2 B
DP IN1 B
DP IN2 A
DP IN1 A
IN-2
IN-1
K/M
CAC
AUDIO
AUDIO
05/19/2022
KVS4-2002VX
K/M
CAC
1
