Identifying Front Panel Features

The following list of features corresponds to the numbers in Figure 3-1:
1
Disk slot
2
Activity indicator
3
Power indicator
4
Eject tool opening
5
Eject button
A slot for inserting optical disks
Remains lit while the drive is loading or un-
loading a disk during the powerup selftest se-
quence, and any time the drive is being
accessed.
Remains lit while the power is on
An access hole for the eject tool. In an emer-
gency, such as a power outage, the disk can
be manually ejected by inserting the eject
tool into this opening. Read "Manually Eject-
ing Disks" on the next page.
Pressed to eject the disk from the drive. The
disk does not eject if a SCSI Prevent/Allow
Media Removal command has been issued, or
if power to the drive is off.
3-3
