The following numbers correspond to the numbers in the drawing on the
previous page.
1 Operation mode switch
2 SCSI ID switch
3 Power connector
4 On/Off switch
5 SCSI connectors
Used to choose the operating mode. Refer to
"Setting the Operation Mode" in this section.
Used to set the SCSI ID.
Connection for power cord.
Used to switch power on or off.
Two connectors that allow SCSI devices to
be daisy-chained. If no other SCSI device ex-
ists on the chain after the optical drive, a ter-
minator must be connected to the unused
connector.
1-5
