Hardware Specifications and Features
RAID firmware limits the controller to a maximum of 30 host drives (RAID volumes) per
controller. There is a minimum of at least one host drive per array drive. A host drive can
only be associated with (or reside on) a single array drive. Like array drives, host drives
can reside on hard disk drives that are isolated to a single channel or span both of the
channels of the RAID controller.
Table 3-5. RAID Controller Drive Maximum Limitations (SRCZCR)
Drive Type
Physical Disk Drives
RAID Array Drives
RAID Host Drives
22
Maximum Maximum
Per Channel Per Controller
15 30
7 15
30
Maximum
Per Array Drive Per Host Drive
30
(2 minimum)
2
Hardware Installation and User's Guide
Maximum
30
1
