Compaq 166207-B21 - Smart Array 5302/32 RAID Controller Technology Brief page 7

TC020604TB
T B
ECHNOLOGY RIEF
. .
R A I D A D G
. .
I S A
. .
. .
The cost effectiveness of each RAID solution is a balance between the total cost of the array and
. .
its usable capacity. While the total cost includes all the drives in the array, the usable capacity
. .
. .
includes only the drives that store non-redundant (not parity or mirrored) data. One way to
. .
evaluate cost effectiveness is to compare the cost per gigabyte of usable capacity of various RAID
. .
. .
levels. Another useful way to evaluate cost effectiveness is to compare storage efficiency—the
. .
usable capacity divided by the total of capacity of all the drives.
. .
. .
. .
An important factor to note is that the usable capacity of any RAID array is limited by the size of
. .
the smallest hard drive in the array; the extra capacity on larger drives goes unused. For example,
. .
. .
an array with four drives (40 GB, 60 GB, 60 GB, and 60 GB) would have a usable capacity of 4 x
. .
40 GB, or 160 GB. To maximize storage efficiency, all RAID array drives should have the same
. .
. .
capacity. If drives with different capacities are attached to the same controller, it is possible to
. .
create multiple arrays that contain only drives of the same capacity.
. .
. .
Table 2 lists the storage efficiencies of the various RAID levels. The storage efficiency of RAID 1
. .
. .
and RAID 1+0 is constant, but the storage efficiency of RAID 5 and RAID ADG varies with the
. .
number of drives. The number of parity drives in RAID 5 and RAID ADG schemes is fixed (one
. .
. .
parity drive for RAID 5 and two parity drives for RAID ADG), so their storage efficiency
. .
increases with the number of drives.
. .
. .
. .
As shown in Table 2, RAID 1 and 1+0 have the lowest storage efficiency at 50 percent; therefore,
. .
they are less cost-effective solutions for large arrays. A comparison of the storage efficiencies of
. .
. . RAID 5 and RAID ADG requires closer scrutiny. For a given number of drives, RAID 5 will have
. .
higher storage efficiency than RAID ADG, although this difference shrinks as the number of
. .
. . drives increases. The storage efficiency of a RAID 5 array varies from 67 percent for three drives
. .
to 93 percent for 14 drives (the maximum recommended by Compaq). The storage efficiency of
. .
. . RAID ADG varies from 50 percent for four drives to 96 percent for a maximum of 56 drives. A
. .
maximum of 56 drives can be physically connected to a four-channel controller using four external
. .
. . Compaq storage systems.
. .
. .
The bottom line is that RAID 1 and 1+0 have very low storage efficiency. RAID 5 and RAID
. .
ADG have much higher storage efficiencies, but the level of efficiency depends on the number of
. .
. .
drives in the array.
. .
. .
Table 2. Summary of RAID Array Storage Efficiency
. .
. .
. .
. .
. .
. .
. .
Usable Capacity
. .
(C= capacity of smallest
. .
. .
drive; n= number of drives)
. .
. .
Minimum number of drives
. .
. .
Maximum recommended
. .
. .
number of drives*
. .
. .
Storage efficiency from
. .
. .
minimum to maximum
. .
recommended no. of drives**
. .
. .
*Compaq recommends not exceeding these maximum figures (excluding any allowable online spares) when configuring
. .
a drive array, due to the increased likelihood of drive array failure if more hard drives are added.
. .
. .
**The value for storage efficiency is calculated assuming all drives in the array have the same capacity with no online
. .
spares.
. .
. .
7
Compaq RAID Advanced Data Guarding
C - E
O S T F F E C T I V E
RAID 1 RAID 1+0
C * (n/2) C * (n/2)
2 4
N/A N/A
50% 50%
S
O L U T I O N
*
RAID 5 Advanced Data
Guarding
C * (n-1)
3
14
67% to %93 50% to 96%
C * (n-2)
4
N/A
