Adaptec RAID 1220SA
Why to buy
Customer needs
Environment
Device support
Data transfer rates
RAID levels
Bus type
System requirements
Operating system support
Kit includes
Physical dimensions
Operating temperature
Power requirements
Warranty
Adaptec, Inc.
Literature Requests:
691 South Milpitas Boulevard
US and Canada: 1 (800) 442-7274 or (408) 957-7274
Milpitas, California 95035
World Wide Web: www.adaptec.com
Tel: (408) 945-8600
Pre-Sales Support: US and Canada: 1 (800) 442-7274 or (408) 957-7274
Fax: (408) 262-2533
Pre-Sales Support: Europe: Tel: (44) 1276-854-500 or Fax: (44) 1276-854-505
Copyright 2006 Adaptec, Inc. All rights reserved. Adaptec, the Adaptec logo, Storage Manager, and Storage Manager Pro are trademarks of Adaptec, Inc., which may be registered in some jurisdictions.
Microsoft, Windows, Windows NT, and Windows 2000, are registered trademarks of Microsoft Corporation, used under license. All other trademarks used are owned by their respective owners.
Information supplied by Adaptec Inc., is believed to be accurate and reliable at the time of printing, but Adaptec Inc., assumes no responsibility for any errors that may appear in this document.
Adaptec, Inc., reserves the right, without notice, to make changes in product design or specifications. Information is subject to change without notice.
Part Number: 986964-011 Printed in U.S.A. 11/06
Adaptec RAID 1220SA RoHS kit
Ordering Part Number: 2232100-R
Low-cost Serial ATA RAID card for data protection and
increased performance
Ideal for desktop and workstations as well as entry-level servers
requiring RAID mirroring or striping
Small office and home office as a boot device for print, file, and
storage servers. Enhanced performance for video editing,
video/audio streaming, and gaming applications
Up to two Serial ATA disk drives
48-bit LBA supports drives larger than 137 GB
SATA tape drives
Up to 3.0 Gb/s
0, 1, and JBOD
PCI Express x1
Intel or AMD architecture with available PCI Express x1 slot
Windows 2000, Windows Server 2003, Windows XP, Netware 6.5,
RedHat and SuSE Linux (for latest supported kernels, visit
www.adaptec.com)
Adaptec 1220SA controller with full-size bracket
Two 1-meter Serial ATA cables
Low-profile replacement bracket
Quick Install Guide
Bootable Installation CD containing:
-Operating system drivers
-Complete user documentation (pdf)
Adaptec Storage Manager CD containing:
-Adaptec Storage Manager GUI software
-Complete user documentation (pdf)
2.5 inch H x 3.5 inch L
6.4 cm H x 8.5 cm L
0 to 55 degrees C
0.9 amps @ 3.3V
3 years
1220SA
