CVP-409/407/405/403/401, CGP-1000 Installation Procedure
Caution:
Do not turn off the power or remove the USB media during this operation.
1
Downloading the firmware
1)
Download the Zip file.
2)
Extract the six files included in the Zip file.
3)
Insert the USB device into your computer.
4)
Copy the extracted files into the root directory of the USB device.
2
Connecting the USB device
Connect the USB device containing the appropriate upgrade data
to the USB TO DEVICE terminal on the instrument.
Caution:
Make sure that the USB device is connected properly to the
terminal. Do not try to force an incorrect connection; doing so
may damage the terminal.
3
Installing the upgrade program
Simultaneously hold down the
the power.
Keep holding down the [START/STOP] button until the following display is shown.
After a few moments, the following display appears.
4
Executing the installation
Press
[START/STOP] button
installation.
[START/STOP] button
Press the [START/STOP] button to start installation.
Go on to
step
Press the [BREAK] button to delete the data the upgrade
data in the USB device.
Go on to
step
to start the
in the STYLE CONTROL section and turn on
4. (Executing the installation).
When the installation is completed, the
following display appears.
Turn off the power switch on the instrument.
Advertisement
Table of Contents
Related Manuals for Yamaha Clavinova CVP-407
Summarization of Contents
Downloading the Firmware
Prepare Firmware Files
Download, extract six files, and copy them to the USB device's root directory.
Connecting the USB Device
Connect USB to Instrument
Connect the USB device with upgrade data to the USB TO DEVICE terminal. Ensure proper connection.
Installing the Upgrade Program
Initiate Installation Mode
Hold [START/STOP] and turn on power until display shows 'PROGRAM INSTALLER'.
Start or Delete Program
Press [START/STOP] to install, or [BREAK] to delete upgrade data.
Executing the Installation
Installation Process
Press [START/STOP] to begin installation. Wait for completion message.
Completion and Power Off
Upon completion, turn off the instrument's power switch.
Deleting the Upgrade Data
Initiate Data Deletion
Press [BREAK] to display deletion options. Confirm deletion with [START/STOP].
Deletion Confirmation
Wait for deletion completion message, then turn off the instrument and remove USB.
Confirming the Version Number
Check Installed Version
Turn on instrument, navigate to UTILITY > OWNER, and press VERSION buttons.
Troubleshooting
Installation Interruption
If power cut or USB removed, reinstall from the beginning.
Installation Errors
Check USB insertion, cleanliness, and data integrity. Try a different USB device.
