Rolls MX410 Specifications

MX410
FEATURES
- Four balanced XLR Inputs
- Two transformer-balanced XLR Outputs
- Switchable Output Level ( Line level, or Mic level)
- 1/8" TRS Stereo Auxiliary Input
- Switchable Phantom Power for each input
- Switchable 100 Hz Low Cut filters for each input
- Dual 9V easy access Battery compartment
- Level controls for each channel
- 1/8" (3.5mm) Headphone Output - Level control
- 18 hour battery life
phones attached, constant use).
- Rolls PS27 external power supply included
ROLLS ROLLS
4 CHANNEL 4 CHANNEL
ENG/ ENG/
FIELD MIXER FIELD MIXER
BALANCED XLR INPUTS
BALANCED XLR OUTPUTS
HEADPHONE OUT
3.5mm CAMERA OUTPUT
ROLLS
5968 SOUTH 350 WEST S.L.C.,UT 84107
PHONE: 801-263-9053
FAX: 801-236-9068
DATA SHEET FOR MX410
-
+
LEVEL
1
The MX410 is a professional 4 channel ENG/Field Mixer, designed with ease of use in mind. The MX410 is
constructed from a powder coated steel chassis. Locking XLR's and a recessed power switch make the
MX410 a great choice for professional sound applications. The MX410 is designed to operate with two 9 volt
batteries or can be poweded with the included Rolls PS27 adapter. Every high end field mixer should be
supplied with a bag and sholder strap the MX410 has both included. The bag is designed specifically for the
MX410 for a professional fit.
SPECIFICATIONS
Input Impedance:
Output Attenuator:
Self Noise:
Max Gain:
S/N Ratio:
THD:
Frequency Response:
Low Cut:
Max Input:
Current Draw:
Phantom Power:
Typical Battery Life:
Connectors:
Power Adapter:
Size:
Weight:
