Goodnal STP ST041 Disinfection & Outfall (KSB Service Water Pumps Pu-1030-010/020/030 OM Instructions) Vendor Manual
Cust. Doc. No.:GDSTP-24090-MAN-0004-P2
Client
Project
P.O. No.
Equipment / Tag No. :
Sales and Service
Phone
Fax
Email
Spares
Q-Pulse Id VM404
K S B A u s t r a l i a P t y L t d
A B N 2 9 0 0 6 4 1 4 6 4 2
A Q u a l i t y E n d o r s e d C o m p a n y A S / N Z I S O 9 0 0 1 : 2 0 0 8
OPERATING AND
MAINTENANCE
INSTRUCTIONS
KSB Doc. No.:KSB-88980-055
KSB REF No: 88980/ 41
:
Thiess Pty Ltd
:
Goodna Sewerage Treatment Plant Upgrage [Stage 4A]
:
GDSTP-24090-CON-0000
Service Water Pumps Pu-1030-010/020/030
:
(07) 3436 8600
:
(07) 3436 8699
:
ksbqldsales@ksb.com.au
:
1300 KSB SPARES ( 1300 572 772 )
Active 29/10/2013
Issue Date: 13/12/2011
Page 1 of 42
