  • Page 1 IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233 User’s Guide...
  • Page 3 IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233 User’s Guide...
  • Page 4 Note: Before using this information and the product it supports, read the information in “Notices,” on page 79, the Warranty Information document, and the IBM Safety Information and Environmental Notices and User Guide documents on the Documentation CD. Fifth Edition (October 2009) ©...

  • Page 5: Table Of Contents

    Reliability, availability, and serviceability ....8 IBM Director ......9 The UpdateXpress program .
  • Page 6 Using the LSI Logic MegaRAID Storage Manager program..75 Chapter 4. Updating IBM Director ....77 Appendix. Notices ..... . . 79 Trademarks .

  • Page 7: Safety

    Vor der Installation dieses Produkts die Sicherheitshinweise lesen. Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza. Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet. Antes de instalar este produto, leia as Informações sobre Segurança. © Copyright IBM Corp. 2009...
  • Page 8 Be sure to read all caution and danger statements in this document before you perform the procedures. Read any additional safety information that comes with the server or optional device before you install the device. IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...
  • Page 9 Statement 1: DANGER Electrical current from power, telephone, and communication cables is hazardous. To avoid a shock hazard: v Do not connect or disconnect any cables or perform installation, maintenance, or reconfiguration of this product during an electrical storm. v Connect all power cords to a properly wired and grounded electrical outlet.
  • Page 10 Note the following. Laser radiation when open. Do not stare into the beam, do not view directly with optical instruments, and avoid direct exposure to the beam. viii IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...
  • Page 11 Statement 4: ≥ 18 kg (39.7 lb) ≥ 32 kg (70.5 lb) ≥ 55 kg (121.2 lb) CAUTION: Use safe practices when lifting. Statement 5: CAUTION: The power control button on the device and the power switch on the power supply do not turn off the electrical current supplied to the device.
  • Page 12 If you suspect a problem with one of these parts, contact a service technician. Statement 26: CAUTION: Do not place any object on top of rack-mounted devices. Statement 27: CAUTION: Hazardous moving parts are nearby. IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...

  • Page 13: Chapter 1. The System X3850 M2 And System X3950 M2 Server

    This printed document contains information about the terms of the warranty. v Safety Information This document is in PDF on the IBM Documentation CD. It contains translated caution and danger statements. Each caution and danger statement that appears in the documentation has a number that you can use to locate the corresponding statement in your language in the Safety Information document.

  • Page 14: Notices And Statements In This Document

    IBM License Agreement for Machine code for your product. v IBM MCP Linux License Information and Attributions This document is in PDF on the IBM Document CD. It provides information about the open-source notices. Depending on the server model, additional documentation might be included on the IBM Documentation CD.
  • Page 15 v Danger: These statements indicate situations that can be potentially lethal or extremely hazardous to you. A danger statement is placed just before the description of a potentially lethal or extremely hazardous procedure step or situation. Chapter 1. The System x3850 M2 and System x3950 M2 server...

  • Page 16: Features And Specifications

    The declared sound-power levels indicate an upper limit, below which a large number of computers will operate. IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...
  • Page 17 “Particulate v Baseboard management controller v Maximum: Four memory cards, each contamination” on page 81. v IBM EXA-4 chip set with integrated card containing four pairs of PC2-5300 memory and I/O controller DDR II DIMMs Heat output:...

  • Page 18: What Your Server Offers

    The ServerGuide Setup and Installation CD that comes with the server provides programs to help you set up the server and install a Windows operating system. IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...
  • Page 19 IBM Director. For more information, including the required levels of IBM Director and Active Energy Manager, see the IBM Director documentation on the IBM Director CD, or go to http://www.ibm.com/servers/eserver/xseries/systems_management/ ibm_director /extensions/.

  • Page 20: Reliability, Availability, And Serviceability

    Error correcting code (ECC) L2 cache and system memory v Fault-resistant startup v Hot-swap hard disk drives v IBM Director workgroup-hardware-management tool v Information and light path diagnostics LED panels IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...

  • Page 21: Ibm Director

    SAS (hot-swap-drive) backplane v Wake on LAN capability IBM Director With IBM Director, a network administrator can perform the following tasks: v View the hardware configuration of remote systems, in detail v Monitor the usage and performance of critical components, such as...

  • Page 22: The Updatexpress Program

    CD, go to http://www.ibm.com/systems/ management/xpress.html. Additional information about UpdateXpress is available from the System x and xSeries Tools Center at http://publib.boulder.ibm.com/ infocenter/toolsctr/v1r0/index.jsp. IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...

  • Page 23: Server Controls, Connectors, Leds, And Power

    Server controls, connectors, LEDs, and power This section describes the controls, connectors, and light-emitting diodes (LEDs) and how to turn the server on and off. Front view The following illustration shows the controls, LEDs, and connectors on the front of the server.
  • Page 24 Locator LED: Use this LED to visually locate the server among other servers. You can use IBM Director to light this LED remotely or press the locator button to light the LED manually. This LED is also lit during startup.

  • Page 25: Rear View

    Locator LED: Use this LED to visually locate the server among other servers. You can use IBM Director to light this LED remotely or press the locator button to light the LED manually. This LED is also lit during startup.
  • Page 26 Remote Supervisor Adapter II. v ASM connector: This connector is not supported. Power supply 1 connector: Connect the power cord to this connector. IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...

  • Page 27: Server Power Features

    Power-supply error LED: When this amber LED is lit, it indicates that there is an error condition within the power supply. For more information, see the Problem Determination and Service Guide on the IBM System x Documentation CD. Power supply 2 connector: Connect the power cord to this connector.

  • Page 28: Turning Off The Server

    You can press the power-control button to start an orderly shutdown of the operating system and turn off the server, if your operating system supports this feature. IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...
  • Page 29 v If the operating system stops functioning, you can press and hold the power-control button for more than 4 seconds to turn off the server. v If the server is installed in a static partition, pressing the power-control button on the primary node in the partition will start an orderly shutdown of the operating system and turn off the server.
  • Page 30 IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...

  • Page 31: Chapter 2. Installing Optional Devices

    This chapter provides detailed instructions for installing optional hardware devices in the server. Server components The following illustrations show the major components in the server. The illustrations in this document might differ slightly from your hardware. © Copyright IBM Corp. 2009...
  • Page 32 Top cover Remote Supervisor Adapter II PCI divider with battery holder Adapter-retention bracket ServeRAID-MR10k controller PCI divider PCI switch-card assembly Hot-swap power supply I/O board shuttle assembly IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...

  • Page 33: Memory-Card Dimm Connectors

    Memory-card DIMM connectors The following illustration shows the DIMM connectors on the memory card. DIMM 1 DIMM 2 DIMM 3 DIMM 4 DIMM 5 DIMM 6 DIMM 7 DIMM 8 Memory-card LEDs The following illustration shows the LEDs on the memory card. Memory hot-swap enabled LED Visible from top of Memory-card/DIMM error LED...

  • Page 34: Microprocessor-Board Connectors

    VRM 3 VRM 4 Microprocessor 1 Microprocessor 2 Memory card 1 Memory card 4 Memory card 3 Memory card 2 VRM 2 VRM 1 Scalability key IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...

  • Page 35: Microprocessor-Board Leds

    Microprocessor-board LEDs The following illustration shows the LEDs on the microprocessor board. FPGA heartbeat BMC heartbeat Board fault LED Microprocessor 3 Microprocessor 4 error LED error LED VRM 3 error LED VRM 4 error LED Microprocessor 1 Microprocessor 2 error LED error LED VRM 1 error LED VRM 2 error LED...

  • Page 36: Microprocessor-Board Jumpers

    Note: Only use the force BMC update jumper if the normal firmware update procedure fails and the operational firmware image is corrupted. Use of the force BMC update jumper disables normal baseboard management controller operation. IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...

  • Page 37: I/O-Board Connectors

    I/O-board connectors The following illustration shows the connectors on the I/O board. Remote Supervisor Adapter II Internal USB ServeRAID-MR10k Hot-plug switch card backplane PCI Express x8 signal (x8 lanes) slot 1 PCI Express x8 (x8 lanes) slot 2 Remote Supervisor PCI Express x8 Adapter II (x8 lanes) slot 3...

  • Page 38: I/O-Board Jumpers

    The default position is pins 1 and 2. Move the jumper to pins 2 and 3 to prevent a Wake on LAN packet from waking the system when the system is in the powered-off state. IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...

  • Page 39: Sas-Backplane Connectors

    SAS-backplane connectors The following illustration shows the connectors on the SAS backplane. SAS hard disk drive connectors SAS signal connector SAS power connector Chapter 2. Installing optional devices...

  • Page 40: Installation Guidelines

    2. Under Product support, click System x. 3. Under Popular links, click Software and device drivers. 4. Click IBM System x3850 M2 or IBM System x3950 M2 to display the matrix of downloadable files for the server. For additional information about tools for updating, managing, and deploying firmware, see the System x and xSeries Tools Center at http:// publib.boulder.ibm.com/infocenter/toolsctr/v1r0/index.jsp.

  • Page 41: Limitations In A Single-Power-Supply Server Operating At 110 V Ac Installation

    When you are finished working on the server, reinstall all safety shields, guards, labels, and ground wires. v For a list of supported optional devices for the server, see http://www.ibm.com/ servers/eserver/serverproven/compat/us/. Limitations in a single-power-supply server operating at 110 V ac...

  • Page 42: Handling Static-Sensitive Devices

    Disconnect all power cords; then, disconnect all external signal cables from the server. 3. Slide the server out of the rack until the slide rails lock into place. IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...

  • Page 43: Installing A Serveraid-Mr10K Sas Controller

    Top cover Cover release latch Bezel 4. Lift the cover-release latch. The cover slides to the rear approximately 13 mm (0.5 inch). Lift the cover off the server. Attention: For proper cooling and airflow, replace the top cover before you turn on the server.
  • Page 44 12. Install the divider that contains the battery holder in the server. 13. Route the battery cable through the cable routing guides on the divider to the controller. IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...

  • Page 45: Installing An Adapter

    If you have other devices to install or remove, do so now. Otherwise, go to “Completing the installation” on page 55. Installing an adapter The following notes describe the types of adapters that the server supports and other information that you must consider when you install an adapter: v Locate the documentation that comes with the adapter and follow those instructions in addition to the instructions in this section.
  • Page 46 14. If you are installing a low-profile adapter, install a ratchet pin in the adapter-retention bracket to secure the adapter. Press the ratchet pin until it touches the top edge of the adapter. IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...

  • Page 47: Installing A Hot-Swap Power Supply

    Retention pin Adapter-retention bracket Removal button Note: Press the removal button and pull up on the ratchet pin to remove the ratchet pin from the adapter-retention bracket. 15. Connect any required cables to the adapter. If you have other devices to install or remove, do so now. Otherwise, go to “Completing the installation”...

  • Page 48: Installing A Hot-Swap Hard Disk Drive

    For a list of supported optional devices for the server, see http://www.ibm.com/ servers/eserver/serverproven/compat/us/. v Inspect the drive tray for signs of damage. v Make sure that the drive is correctly installed in the tray. IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...
  • Page 49 v If the server will be configured for RAID operation, see the documentation that comes with the controller for instructions for installing a hard disk drive. v All hot-swap drives in the server should have the same throughput speed rating; using drives with different speed ratings might cause all drives to operate at the lowest throughput speed.

  • Page 50: Installing A Dvd Drive

    I/O board. You do not have to turn off the server to install an internal removable flash drive. To install an internal removable flash drive, complete the following steps. IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...

  • Page 51: Memory Module

    (ECC) DIMMs. These DIMMs must be compatible with the latest PC2-5300 SDRAM Registered DIMM specifications. For a list of the supported optional devices for the server, see http://www.ibm.com/servers/eserver/ serverproven/compat/us/. v The server supports up to four memory cards. Each memory card holds up to eight DIMMs.
  • Page 52 Table 5. Low-cost memory-card installation sequence DIMM pair installation order Memory card Connector numbers First 1 and 5 Second 1 and 5 Third 2 and 6 Fourth 2 and 6 IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...
  • Page 53 Table 5. Low-cost memory-card installation sequence (continued) DIMM pair installation order Memory card Connector numbers Fifth 3 and 7 Sixth 3 and 7 Seventh 4 and 8 Eighth 4 and 8 Ninth 1 and 5 Tenth 1 and 5 Eleventh 2 and 6 Twelfth 2 and 6...
  • Page 54 DIMM. When this occurs, first identify the defective DIMM; then, remove and replace the DIMM. The following illustration shows the LEDs that are visible on top of the memory card. IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...

  • Page 55: Active Memory

    DIMM. This LED also turns off when the release levers are opened. Active Memory Active Memory is an IBM technology that improves the reliability of the DIMMs ™ through the memory mirroring, memory scrubbing, and Memory ProteXion features.

  • Page 56: Adding And Replacing A Memory Card

    Place the memory card on a flat, static-protective surface, with the DIMM connectors facing up. IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...
  • Page 57 c. Install DIMMs in the memory card (see “Installing DIMMs” on page 46). 5. Add the memory card. Attention: When you move the memory card, do not allow it to touch any components or structures inside the server. a. Grasp the memory card by the retention levers and turn the memory card so that the connector aligns with the connector on the microprocessor board and the guides on the chassis.

  • Page 58: Installing Dimms

    When you move the memory card, do not allow it to touch any components or structures inside the server. Release latch 4. Remove the memory card: a. Slide the orange release latch to the unlocked position. IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...
  • Page 59 Attention: To avoid loss of data, make sure that the memory port power LED is off before you remove the memory card. b. Open the retention levers on the top of the memory card. c. While you hold the retention levers open, lift the memory card out of the server.
  • Page 60 DIMM from the package. 8. Turn the DIMM so that the DIMM keys align correctly with the slot. IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...
  • Page 61 9. Insert the DIMM into the connector by aligning the edges of the DIMM with the slots at the ends of the DIMM connector. Firmly press the DIMM straight down into the connector by applying pressure on both ends of the DIMM simultaneously.

  • Page 62: Installing A Microprocessor

    Installing a microprocessor The following notes describe the type of microprocessor that the server supports and other information that you must consider when you install a microprocessor: IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...
  • Page 63 2. Under Product support, click System x. 3. Under Popular links, click Software and device drivers. 4. Click IBM System x3850 M2 or IBM System x3950 M2 to display the matrix of downloadable files for the server. v Obtain an SMP-capable operating system. For a list of supported operating systems, see http://www.ibm.com/servers/eserver/serverproven/compat/us/.
  • Page 64 For details about handling these devices, see “Handling static-sensitive devices” on page 30. 4. Loosen the captive screws and rotate the media hood to the fully open position. IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...
  • Page 65 Captive screws 5. If necessary, remove the microprocessor air baffle from between socket 1 and socket 2. 6. If you are installing a microprocessor in microprocessor socket 2 and it contains a heat-sink blank, remove the heat-sink blank and store it for future use.
  • Page 66 14. Position the heat sink above the microprocessor and align the heat sink with the alignment posts; then, press on the top of the heat sink, rotate the heat-sink release lever, and move the lever to the locked position. IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...

  • Page 67: Completing The Installation

    Alignment indicator VRM cradle 15. Install a VRM in the connector next to the microprocessor socket: a. Turn the VRM so that the keys align with the slot. b. Insert the VRM into the connector by aligning the edges of the VRM with the slots at the end of the VRM connector.

  • Page 68: Connecting The Cables

    The following illustrations show the locations of the input and output connectors on the server. Detailed cabling instructions are in the Rack Installation Instructions that come with the server. IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...

  • Page 69: Updating The Server Configuration

    Rear view Remote Supervisor Adapter II System serial Power-supply 1 Power-supply 2 SMP expansion port 1 Gigabit Ethernet 1 SMP expansion port 2 SMP expansion port 3 Gigabit Ethernet 2 Front view Power-control button/power-on LED Information LED Ethernet icon LED System-error LED Locator button/locator LED Ethernet port activity LEDs...
  • Page 70 IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...

  • Page 71: Chapter 3. Configuring The Server

    II User’s Guide on the IBM System x Documentation CD. v IBM Electronic Service Agent IBM Electronic Service Agent is a software tool that monitors the server for hardware error events and automatically submits electronic service requests to the IBM Support Center. Also, it can collect and transmit system configuration information on a scheduled basis so that the information is available to you and your support representative.

  • Page 72: Using The Configuration/Setup Utility Program

    Select this choice to view the machine type and model of the server, the serial number, the revision level or issue date of the BIOS and diagnostics code IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...
  • Page 73 stored in electrically erasable programmable ROM (EEPROM), and the revision level of the firmware on the Remote Supervisor Adapter II. – System Card Data Select this choice to view vital product data (VPD) for some server components. v Devices and I/O Ports Select this choice to view or change assignments for devices and input/output (I/O) ports.
  • Page 74 Disable is the default value. - Processor Hardware Prefetcher Select this choice to enable or disable the hardware prefetcher. Enable is the default value. - Processor Execute Disable Bit IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...
  • Page 75 Enable is the default value. – TPM Menu Select this choice to set the trusted platform module (TPM) feature. For more information, see http://www.ibm.com/systems/support/supportsite.wss/ docdisplay?lndocid=MIGR-5072502&brandind=5000008. – Partition Chassis Options Select this choice to set the partition configuration options for use in a multi-node configuration.
  • Page 76 Host Name Select this choice to set the BMC host name. The default value is the lower 4 bytes of the MAC address. v DHCP Control IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...
  • Page 77 Determination and Service Guide on the IBM System x Documentation CD for instructions. Select Clear error logs to clear the BMC system event log. Note: Use the IBM Remote Supervisor Adapter II system event log or run the diagnostic programs for more information about the error codes.

  • Page 78: Passwords

    If a power-on password is set, you can enable the Unattended Start mode, in which the keyboard and mouse remain locked but the operating system can start. You can unlock the keyboard and mouse by typing the power-on password. IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...

  • Page 79: Administrator Password

    If you forget the power-on password, you can regain access to the server in any of the following ways: v If an administrator password is set, type the administrator password at the password prompt. Start the Configuration/Setup Utility program and reset the power-on password.

  • Page 80: Using The Serverguide Setup And Installation Cd

    When you use the ServerGuide Setup and Installation CD, you do not need setup diskettes. You can use the CD to configure any supported IBM server model. The setup program provides a list of tasks that are required to set up your server model.

  • Page 81: Typical Operating-System Installation

    3. From the menu on the left side of the page, click System x support search. 4. From the Task menu, select Install. 5. From the Product family menu, select IBM System x3850 M2 or IBM System x3950 M2. 6. From the Operating system menu, select your operating system, and then click Search to display the available installation documents.

  • Page 82: Using The Boot Menu Program

    CD. You can access the configuration utility after the firmware update is started and completed or stopped before completing. IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...

  • Page 83: Using The Firmware Update Utility Program

    2. Under Product support, click System x. 3. Under Popular links, click Software and device drivers. 4. Click IBM System x3850 M2 or IBM System x3950 M2 to display the matrix of downloadable files for the server. 5. From the BMC software section, download the file for the operating system and for the DOS firmware update utility from which you will perform the configuration and create a firmware update diskette or CD.
  • Page 84 Note: Only use the force BMC update jumper if the normal firmware update procedure fails and the operational firmware image is corrupted. Use of the force BMC update jumper disables normal baseboard management controller operation. IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...

  • Page 85: Using The Management Utility Program

    2. Under Product support, click System x. 3. Under Popular links, click Software and device drivers. 4. Click IBM System x3850 M2 or IBM System x3950 M2 to display the matrix of downloadable files for the server. 5. From the BMC software section, download the management utility (SMBRIDGE).

  • Page 86: Using The Lsi Logic Configuration Utility Program

    Global properties v Cylinder head sector (CHS) mapping v Advanced device properties, such as I/O timeouts and LUNs to scan v Spin-up properties v PHY properties IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...

  • Page 87: Using The Lsi Logic Megaraid Storage Manager Program

    Using the LSI Logic MegaRAID Storage Manager program Use the LSI Logic MegaRAID Storage Manager program to monitor and manage the disk-array subsystem connected to the integrated SAS controller with RAID capabilities and the ServeRAID-MR10k controller option. The LSI Logic MegaRAID Storage Manager program, device drivers, and information come with the ServeRAID-MR10k controller option.
  • Page 88 IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...

  • Page 89: Chapter 4. Updating Ibm Director

    Chapter 4. Updating IBM Director If you plan to use IBM Director to manage the server, you must check for the latest applicable IBM Director updates and interim fixes. To install the IBM Director updates and any other applicable updates and interim fixes, complete the following steps: 1.
  • Page 90 IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...

  • Page 91: Appendix. Notices

    Web sites. The materials at those Web sites are not part of the materials for this IBM product, and use of those Web sites is at your own risk. IBM may use or distribute any of the information you supply in any way it believes appropriate without incurring any obligation to you.

  • Page 92: Important Notes

    IBM makes no representations or warranties with respect to non-IBM products. Support (if any) for the non-IBM products is provided by the third party, not IBM. IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...

  • Page 93: Particulate Contamination

    If IBM determines that the levels of particulates or gases in your environment have caused damage to the server, IBM may condition provision of repair or replacement of servers or parts on implementation of appropriate remedial measures to mitigate such environmental contamination.

  • Page 94: Electronic Emission Notices

    In the request, be sure to include the publication part number and title. When you send information to IBM, you grant IBM a nonexclusive right to use or distribute the information in any way it believes appropriate without incurring any obligation to you.

  • Page 95: European Union Emc Directive Conformance Statement

    EU-Mitgliedsstaaten und hält die Grenzwerte der EN 55022 Klasse A ein. Um dieses sicherzustellen, sind die Geräte wie in den Handbüchern beschrieben zu installieren und zu betreiben. Des Weiteren dürfen auch nur von der IBM empfohlene Kabel angeschlossen werden. IBM übernimmt keine Verantwortung für die Einhaltung der Schutzanforderungen, wenn das Produkt ohne Zustimmung der Appendix.

  • Page 96: People's Republic Of China Class A Warning Statement

    Das Gerät erfüllt die Schutzanforderungen nach EN 55024 und EN 55022 Klasse A. People's Republic of China Class A warning statement Japanese Voluntary Control Council for Interference (VCCI) statement Korean Class A warning statement IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...

  • Page 97: Index

    15 front USB connector 11 USB, front 11 USB, rear 15 connectors memory card 21 gaseous contamination 5, 81 microprocessor-board 22 Gigabit Ethernet contamination, particulate and gaseous 5, 81 activity LED 13 cooling 8 © Copyright IBM Corp. 2009...
  • Page 98 LED 43 functions 5 Memory ProteXion 6, 44 network support 7 microprocessor 5, 8 internal removable flash drive 38 board illustration 22, 23 installation 50 IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...
  • Page 99 ServerGuide features 68 noise emissions 5 NOS installation 69 NOS installation Setup and Installation CD 6, 59 with ServerGuide 69 using 68 without ServerGuide 69 serviceability 8 notes 2 setup notes, important 80 with ServerGuide 68 notices 79 size 5 electronic emission 82 slots 5 FCC, Class A 82...
  • Page 100 X-Architecture technology 6 IBM System x3850 M2 and System x3950 M2 Types 7141 and 7233: User’s Guide...
  • Page 102 Part Number: 59Y7199 Printed in USA (1P) P/N: 59Y7199...
