Rev-A-Shelf 5CW2-2122-CR Installation Instructions Manual

CO AND 5CW2 SERIES
Note 1: Be sure to measure cabinet opening and basket width to make sure basket will clearly pull out of the cabinet without interference.
Note 2: All cabinets are built and constructed differently, some have a built-in shelf that is not easily removeable. This organizer can still be
installed with the shelf in place, but note some taller items could hit the shelf when opening and closing.
TOOLS REQUIRED:
#2 #2 #2
ESTIMATED ASSEMBLY TIME:
20 MIN
CARE AND MAINTENANCE:
Clean with a damp cloth and wipe
parts dry.
WATCH TUTORIALS OF OUR
PRODUCTS BEING INSTALLED
WWW.REV-A-SHELF.COM/VIDEOS
PARTS LIST
No. Description
A Dividers*
B Handle Bar*
C U-Shaped Support Brackets
D Upper Slide Shelf
E Lower Slide Shelf
F #8 X 3/4" Truss Head Screws
G M4 X 8 Flat Head Machine Screws
H #8 x 1/2" Pan Head Wood Screws
* CO-15 and 5CW2-1222 Series come with 7 Dividers and 1 Handle Bar.
CO-21 and 5CW2-2122 Series come with 14 Dividers and 2 Handle Bars
**Extra screws are provided in case one is lost or misplaced.
D
C
H
G
INSTALLATION INSTRUCTIONS: COOKWARE ORGANIZER
12400 Earl Jones Way
Louisville, KY 40299
rev-a-shelf.com
Customer Service: 800-626-1126
A
Qty.
7 14
1 2
2
1
B
1
4
16
5
E
F
I-CO5CW2-0521
