HCC474M
MINIATURE, HIGH RESOLUTION COLOR CAMERA
The HCC474M is the next step in camera evolution. It boasts a wide range of
advanced features within its ultra-miniature frame. Don't let its size fool you; it
may be smaller, but the HCC474M outperforms cameras four times its size.
Using a 1/3", low-light CCD sensor, the HCC474M provides excellent color
performance in extremely low light, down to 0.4 lux (F1.2). Being a quarter of the
size of traditional cameras, it's also perfect for tight spaces and small housings.
What sets the HCC474M apart from the competition is its feature set. With an
on-screen display for setup and adjustment, you get the perfect shot on every
installation. Unlike other small-sized cameras, the HCC474M includes a switching
12 VDC or 24 VAC power supply with line lock and digital phase adjustment, as
well as 6-zone backlight compensation, 24-character text display, adjustable
white balance modes and more.
Market Opportunities
The Honeywell HCC474M is designed for unobtrusive, high resolution surveillance
applications that require a small camera where high quality video in low light
conditions are needed. This includes general indoor surveillance applications in
retail, financial, gaming, and other commercial markets.
Features
• High performance 1/3" CCD with DSP
• On-screen display menu and
adjustment
• 470 TV lines of resolution
• High sensitivity
(0.4 lux at F1.2, contrast "on")
• Digital backlight compensation with 6
sensing zones
• Small footprint,
1.6" (W) x 1.6" (H) x 2.8" (D)
• Auto electronic shutter modes from
1/60 to 1/100,000 second
• Three mode white balance,
ATW/AWC/Manual
• Text display, 24 alphanumeric
characters
• Variable gamma, brightness,
and color control
• 12 VDC/24 VAC with line lock
• Digital phase adjustment
• C/CS lens mount
• DC, Video and Manual Iris
lens support
