Honeywell HCC484L Specifications

HCC484L/HCC484LX
HIGH RESOLUTION COLOR CAMERA
The Honeywell HCC484L color camera is ideally suited for use in day-to-day
surveillance applications. Designed for value, the HCC484L saves time and
money with easy installation and reliable performance. Its off-the-shelf feature set
is developed for high-picture quality in standard applications and requires little to
no adjustment once installed.
The HCC484L supports direct-drive and drive-style Auto Iris lenses to ensure
quality video even in fluctuating light conditions. Regardless of lens type,
attaching a lens to the camera is simple with a built-in C/CS mounting ring and
four-pin Auto Iris connector standard. A screw terminal block provides reliable
power connection, saving installation and maintenance time.
The HCC484L includes an automatic electronic shutter for changes in light level,
and an automatic backlight compensation option for viewing objects in the
foreground with bright light in the background. A manual exposure mode can be
used for applications, such as machine vision, that require a constant shutter
speed at all times. The HCC484L produces 480 TV lines of resolution to provide
reliable video quality even in low-light conditions down to 0.40 lux.
Market Opportunities
The Honeywell HCC484L is designed for general cost-effective, high-resolution
surveillance applications where a color image and object identification and
recognition are required. This includes general indoor surveillance applications
in retail, educational, financial, and other commercial markets. Combined with
the HHC12 environmental housing, the HCC484L can be used as a solution
for outdoor applications, such as parking lots, building entranceways,
and driveways.
Features
• 1/3" color CCD with DSP
• 480 TV lines of resolution
• Low-light performance 0.40 lux (F1.2)
• Automatic Electronic Shutter (AES)
• Manual Exposure Mode for setting
shutter speed
• Automatic Backlight Compensation
(BLC)
• 12 VDC/24 VAC with line lock
• C/CS lens mount
• DC, Video and Manual Iris
lens support
