ROSE DISPLAYS ANOQUICK WITH PEG Instruction Sheet

AnoQuick™ with Peg

Parts

Instructions for Hanging

Instructions for Hanging

Step 1

When using AnoQuick to hang 1/8" Sintra or an
equally heavy substrate, have your printer punch
two 1/4" holes along the top and bottom edges of
print — or only the top if no bottom holder is
being used. Fig. 1
Note: Each hole must be centered 1/4" in from the
edge of the substrate.

Step 2

Push both parts of the peg together through each
of the punched holes. Fig. 2

Step 3

Slide AnoQuick onto substrate. The pegs should
slide into the side rails. Fig. 3
Note: This is the easiest way to safely hang
heavier substrates.
The AnoQuick is a trademark of Rose Displays, Ltd. Neither
the manufacturer nor any sales agent may be held liable for injury, loss or
damage resulting from the use of these products.
Part # 02INSAnoQuickPeg
Incept-9.9.02
AnoQuick
12A300
06-1920
Instruction Sheet
Pegs
Figure 1
Figure 2
Figure 3
35 Congress Street, Salem, MA 01945
Tel# 1-800-631-9707 Fax# 1-800-560-2890
e-mail:signware@rosedisplays.com
