Summarization of Contents
Regulatory compliance
EMC directive
Standards EN 60065, EN 61000-6-1, EN 61000-6-3 and EN 60118-4.
REACH (EU) Regulation no. 1907/2006
The product may contain traces of lead.
Connections
Connection terminal block
Lists terminals (1,2, FP, M) and their functions: bus, input, earth.
Connection
Connecting the indoor station in the in/out configuration
In/out wiring diagram showing termination to apply for device connection.
Connecting the indoor station in terminal configuration
Wiring diagram illustrating cable termination within the indoor station.
Variant for connecting the landing or alert button
Details on connecting the FP/M terminal for landing or alert button functionality.
Intercom
Selection of intercom type
Options to associate an indoor station, porter switchboard, or Alert function with intercom.
