Summary of Contents for Vimar ELVOX TVCC

  • Page 1 Installation and operation manual Videorecorder graphical user interface...
  • Page 2 Videorecorder graphical user interface...

  • Page 3: Table Of Contents

    Videorecorder graphical user interface Contents 1 - Introduction 1.1 - Summary ..........................................3 1.2 - Features ..........................................3 1.3 - Front panel descriptions ......................................4 2 - Basic operation guide 2.1 - Startup & Shutdown ........................................5 2.1.1 - Startup ..........................................5 2.1.2 - Shutdown ........................................5 2.2 - Remote controller ........................................6 2.3 - Mouse control .........................................6 2.4 - Text-input instruction .......................................6...
  • Page 4 Videorecorder graphical user interface 8.4.6 - Image management .....................................48 8.4.7 - View backup status ......................................48 9 - Alarm management 9.1 - Sensor alarm .........................................49 9.2 - Motion alarm .........................................49 9.2.1 - Motion configuration .....................................49 9.2.2 - Motion alarm handling configuration ................................50 9.3 - Exception alarm ........................................50 9.3.1 - Exception handling settings ..................................50 9.3.2 - IPC offline settings .......................................50 9.3.3 - Video loss settings .......................................51 9.4 - Alarm event notification ......................................51...

  • Page 5: Introduction

    Videorecorder graphical user interface 1 - Introduction 1.1 - Summary This manual describes all the main functions related to the graphics interface of NVR and AHD DVR. Some features may not be supported by some devices. Refer to your device. 1.2 - Features BASIC FUNCTIONS Below are the main features supported.

  • Page 6: Front Panel Descriptions

    Videorecorder graphical user interface • The snapped images can be attached into the e-mail when alarm linkage is triggered. • Alarm status view of alarm-in, alarm-out, motion detection and exception alarm. • Alarm to be triggered and cleared manually. • System auto reboot when exception happens. NETWORK FUNCTIONS •...

  • Page 7: Basic Operation Guide

    Videorecorder graphical user interface 2 - Basic operation guide 2.1 - Startup & Shutdown Please make sure all the connections are done properly before you power on the unit. Proper startup and shutdown are crucial to expending the life of your device.

  • Page 8: Mouse Control

    Videorecorder graphical user interface Button Function Record manually Search To enter search mode MEUN To enter menu Exit To exit the current interface ENTER To confirm the choice or setup Direction button To move cursor in setup ZOOM To zoom in No function temporarily To control playback. Play(Pause)/Next Frame/Speed Up/Stop/Previous Frame/Speed Down Multi To choose multi screen display mode...

  • Page 9: Wizard & Main Interface

    Videorecorder graphical user interface 3 - Wizard & Main interface 3.1 - Startup wizard The disk icons will be shown on the top of the startup interface. You can view the number and status of each disk quickly and conveniently through these icons ( : no disk;...
  • Page 10 Videorecorder graphical user interface Note: If you use the NVR with the PoE network ports, the online state of the internal ethernet port will be shown on the interface. Refer to the picture below. Please refer to 11.1.1 TCP/IP Configuration for detail introduction of the internal ethernet port. If the NVR has two network ports or above, you can select the network work pattern as required. Network Fault Tolerance and Multiple Address Setting are available. Refer to the pictures below. Please refer to 11.1.1 TCP/IP Configuration for more detailed information.
  • Page 11 Videorecorder graphical user interface 4- QRCode. Enable the NAT function in the interface or set it in the network configuration after exiting the wizard (please refer to 11.1.7 NAT Configuration for details). 5- Add camera. Click “Refresh” to refresh the list of online IP cameras which are in the same local network with NVR/DVR and then click to add the searched camera. Click “Add All” to add all the cameras in the list. Click to delete the added camera. Click “Delete All” to delete all the added cameras.
  • Page 12 Videorecorder graphical user interface Click to edit the searched IP camera as shown on the below left. Input the new IP address, subnet mask, gateway, username and the password of the camera. Click “OK” to save the settings. Click to edit the added camera as shown on the above right. Input the new camera name, IP address, port, username and the password of the camera. You can click “Test” to test the effectiveness of the input information. Click “OK” to save the settings. You can change the IP camera name only when the added camera is online. Click “Next” to continue.

  • Page 13: Main Interface

    Videorecorder graphical user interface 3.2 - Main interface 3.2.1 - Main interface introduction The buttons in area 1 are introduced in the table below. Button Meaning Start button. Click it to pop up area 3. Full screen button. Click it to show full screen; click it again to exit the full screen. Screen mode button.

  • Page 14: Setup Panel

    Videorecorder graphical user interface Introduction of area 2: Click “Camera” to view all the added cameras in the camera list. Select one camera window on the left side of the interface and then double click one camera in the list to preview the camera image in the selected window. Click “Single Channel Sequences” to view all the added groups in the group list; click one group in the list to view all the added cameras in the group (refer to 4.2 Add/Edit Camera Group for detail configuration of the camera group). Select one camera window on the left side of the interface and then double click one group in the group list to preview the cameras’ images one by one in the selected window. Click “Customize Display Modes” to view all the display modes in the display mode list (refer to 5.2.1 Preview By Display Mode for detail configuration of the display mode).

  • Page 15: Main Functions

    Videorecorder graphical user interface Click the main menus on the top of the camera management interface to go to corresponding interfaces. Refer to the picture below. For instance, you can go to system setup interface by clicking “System” tag. 3.2.3 - Main Functions • Camera The module covers the functions such as Camera Management (see Chapter 4 Camera Management for details), Image Settings (see 5.3 Preview Image Configuration for details), Motion (see 9.2.1 Motion Configuration for details) and PTZ (see Chapter 6 PTZ for details) and so on.

  • Page 16: Camera Management

    Videorecorder graphical user interface 4 - Camera management 4.1 - Camera signal (only for DVR) Click StartSettingsCameraManage CameraCamera Signal to go to the interface as shown below. The DVR device supports hybrid access of TVI, AHD and CVI high definition cameras. If the TVI high definition camera is accessed to the DVR, you should select TVI in the following interface to show the camera image normally; if you select AHD, then there will be no image or the image has no color. The default selection of the camera signal is Auto.

  • Page 17: Add/Edit Camera

    Videorecorder graphical user interface • Quickly add Check the cameras and then click “Add” to add cameras. Click to edit the camera’s IP address, username and password and so on. Click “Default Password” to set the default username and password of each camera. • Add manually Input the IP address, port, username and password of the camera and then select the protocol. Click “Test” to test the effectiveness of the input information and then click “Add” button (you can input one camera’s information or above such as IP address, username and password before clicking “Add” button). Click to delete the camera. Click “Default Password” to set the default username and password of each camera. • Add recorder (only for NVR) - Quickly Add: Select the searched NVR/DVR and the click “Add” to add NVR/DVR in the same local network. - Manually Add: Click “Manual Add” and then input the IP address or domain name, port, username and password of the NVR/DVR. Check the added remote channel number and click “Test” to test the effectiveness of the input information. Then click “OK” button to return to the previous interface. Note: Only the local NVR/DVR has unoccupied channels, may the IPC of other NVR/DVR in the same local network be added. And the added IPC supports previewing and recording.

  • Page 18: Add/Edit Camera Group

    Videorecorder graphical user interface Note: If you use the NVR with the PoE network ports, the IP cameras (with PoE function) which directly connect to the PoE port of the NVR will be displayed automatically in the camera list. Refer to the picture below. The IP camera which occupies the PoE resource has a prefix shown before its camera name. The prefix consists of PoE plus PoE port number. The IP camera which connects to the PoE port cannot be deleted from the camera list manually. • The IP camera which directly connects to the PoE port of the NVR through private protocol will be shown automatically in the camera list. •...

  • Page 19: Edit Camera Group

    Videorecorder graphical user interface 4.3.2 - Edit camera group Click to modify the group information such as group name and dwell time. Click to delete the group. 4.3.3 - IP planning Some models may not support this function. Click “IP Planning” to go to the interface as shown below. This function supports searching other NVRs/DVRs that is in the same local network as the local NVR/DVR. The user may add the IPC of other NVRs/DVRs into the unoccupied channels of the local NVR/DVR. Click to edit the IP address, user name or password and other information of the NVRs/DVRs.

  • Page 20: Live Preview Introduction

    Videorecorder graphical user interface 5 - Live preview introduction 5.1 - Preview interface introduction You should add camera first after logging on to the system (see 4.1.1 Add Camera for details). Refer to the interface as shown below, drag one camera in the preview window to another window for camera window exchanging. The record symbols with different colors in the live preview window refer to different record types when recording: green stands for manual record, red stands for sensor based record, yellow stands for motion based record, blue stands for schedule record and cyan stands for intelligence record. Click the preview window to show the tool bar as shown in area 1;...

  • Page 21: Preview Mode

    Videorecorder graphical user interface 5.2 - Preview mode 5.2.1 - Preview by display mode Set different screen modes and cameras’ display sequences as required and then save the display modes classified by surveillance areas, priorities and so on. Refer to the picture below. Double click one display mode in the display mode list to view the live images in this mode. •...

  • Page 22: Quick Sequence View

    Videorecorder graphical user interface Fisheye Mode. Some models may not support this function. In the live preview, select the view mode according to the installation mode and display mode of the fisheye camera. Please refer to User Manual of relevant camera. 5.2.2 - Quick sequence view You can start quick sequence view if the scheme has not been created. If the scheme has been created, please refer to 5.2.4 Scheme View in Sequence for details.

  • Page 23: Camera Group View In Sequence

    Videorecorder graphical user interface Go to the live preview interface and then click to pop up a little window. Set the dwell time in the window and then click to view the live group by group according to the camera number of the current screen mode. Double click the sequence view interface to pause the view; double click again to restore the view.

  • Page 24: Spot View

    Videorecorder graphical user interface • Add scheme Click in area 1 to create a new scheme. Click on the top right corner of the scheme to delete it. • Configure scheme a) Select a scheme in area 1 and then click the screen mode button on the tool bar to set the screen mode of the scheme. b) Select a camera window in area 2 and then double click the camera or group in area 3.

  • Page 25: Preview Image Configuration

    Videorecorder graphical user interface 5.3 - Preview image configuration 5.3.1 - OSD settings Click StartSettingsCameraImageOSD Settings to go to the interface as shown below. Select the camera, input the camera name (or double click the camera name in the camera list to change the camera name), enable or disable the name and time OSDs (if enabled, drag the red name and time OSDs directly in the image view area to change the OSDs’ display position) and select the date and time formats. Click “Apply” to save the settings.

  • Page 26: Fisheye Settings

    Videorecorder graphical user interface 5.3.4 - Fisheye settings Some models may not support this function. Click StartSettingsCameraImageFisheye Settings to go to the interface as shown below. Select the camera and the mode of fisheye and installation. 5.3.5 - Image adjustment Go to live preview interface and then click button on the tool bar under the camera window to go to the image adjustment interface.

  • Page 27: Watermark Setting

    Videorecorder graphical user interface Parameter Meaning Brightness It is the brightness level of the camera’s image. Contrast It is the color difference between the brightest and darkest parts. Saturation It is the degree of color purity. The color is purer, the image is brighter. It relates to the total color degree of the image. Sharpen It relates to the resolution level of the image plane and the sharpness level of the image edge.
  • Page 28 Videorecorder graphical user interface...

  • Page 29: Ptz

    Videorecorder graphical user interface 6 - PTZ 6.1 - PTZ control interface introduction You can control the IP dome or PTZ which connects to the IP camera for PTZ control. Click on the tool bar at the bottom of the live preview window to go to the PTZ control interface as shown below. You can select another IP dome or PTZ which connects to the IP camera on the top right of the interface for PTZ control.
  • Page 30 Videorecorder graphical user interface Refer to the picture as shown below. Drag the mouse from C to D to get a green rectangle and the rectangle area will be zoomed out. • Advanced 3D control Double click the left button of the mouse on any area of the camera image and then the image size will be doubled and centered on the clicked point. Press and hold the left button of the mouse on any area of the camera image to zoom in the image;...

  • Page 31: Preset Setting

    Videorecorder graphical user interface 6.2 - Preset setting Click StartSettingsCameraPTZPreset to go to the interface as shown below. • Add preset Select camera and then click “Add” button to add preset; or click in the camera list on the right side of the interface to display the preset information of the dome and then click to add preset. The operations of the “Add Preset” window are similar to that of the PTZ control interface; please see 6.1 PTZ Control Interface Introduction for details.

  • Page 32: Ptz Protocol Setting

    Videorecorder graphical user interface • Delete cruise Click in the camera list on the right side of the interface to display the cruise information of the dome and then click on the top right corner of the cruise to delete the cruise. 6.4 - PTZ protocol setting (only for DVR) Click StartSettingsCameraPTZProtocol to go to the interface as shown below.

  • Page 33: Record & Disk Management

    Videorecorder graphical user interface 7 - Record & Disk management 7.1 - Record configuration 7.1.1 - Mode configuration Please format the HDDs before recording (refer to 7.5 Disk Management for details). Click StartSettingsRecordMode Settings to go to the mode settings interface. You can set the record time under the “Manual Record Settings” and then click “Apply” button to save the settings. There are two record modes: auto mode and manual mode.

  • Page 34: Advanced Configuration

    Videorecorder graphical user interface Bitrate type: CBR and VBR are optional. CBR means that no matter how changeable the video resources are, the compression bitrate keeps constant. This will not only facilitate the image quality better in a constant bitrate but also help to calculate the capacity of the recording. VBR means that the compression bitrate can be adjustable according to the change of the video resources.
  • Page 35 Videorecorder graphical user interface Click to add a new schedule. Refer to the picture below. Set the schedule name and schedule time and then click “Add” to save the schedule. You can set day schedule or week schedule. : add button; : delete button. • Set day schedule Click and then drag the cursor on the time scale to set record time; click and then drag the cursor on the time scale to delete the selected area.

  • Page 36: Record Schedule Configuration

    Videorecorder graphical user interface Click “All” to set all week recording; click “Reverse” to swap the selected and unselected time in a week; click “Clear All” to clear all the selected area in a week. 7.3.2 - Record schedule configuration Click StartSettingsRecordRecord ScheduleSchedule Configuration to go to the interface as shown below. Set the schedule of sensor record, motion record and timed record. Click “None” in the drop-down menu to clear the schedule. Click “Apply” to save the settings. Go to “Edit Schedules” interface and then click to edit the schedule. The settings of “Edit Schedule” are similar to that of the “Add Schedule”. Click to delete the schedule. 7.4 - Record mode 7.4.1 - Manual recording Method one: Click on the tool bar at the bottom of the live preview interface to enable recording of the camera. Method two: Go to live preview interface and then click the right-click menu “Manually Record On” in the camera window or click on the tool bar under the camera window to start recording.

  • Page 37: Physical Disk

    Videorecorder graphical user interface Some models may not support this function. The settings of RAID are as followings. Please skip the settings of physical disk, array and disk mode if the NVR doesn't support this function. 7.5.1 - Physical Disk Click StartSettingsDiskDisk ManagementPhysical Disk to go to physical disk interface.

  • Page 38: Storage Mode Configuration

    Videorecorder graphical user interface 7.5.4 - Storage mode configuration Click StartSettingsDiskStorage Mode to go to the interface as shown below. There are all four disk groups. By using disk group, you can correspond the camera to disk (the record data of the camera in the group will be stored into the disks in the same group).

  • Page 39: Playback & Backup

    Videorecorder graphical user interface 8 - Playback & Backup 8.1 - Instant playback Click on the tool bar at the bottom of the preview camera window to play back the record. Refer to the picture below. Drag the playback progress bar to change the playback time. You can also click the right-click menu “Instant Playback” in the camera window and then set the instant playback time to play back the record.
  • Page 40 Videorecorder graphical user interface Button Meaning Next frame button. It works only when the forward playing is paused in single screen mode. Click to step backward 30s and click to step forward 30s. Click it to show the water mark on the image; click to hide the watermark (only for DVR).

  • Page 41: B - Playback Interface Introduction (Only For Nvr From Fw 1.4.4 Version)

    Videorecorder graphical user interface 8.2b - Playback Interface Introduction Click on the tool bar at the bottom of the live preview interface or click StartPlayback to go to the playback interface as shown below (click the tool bar at the bottom of the live preview interface to set the default playback time). On the panel on the right you will see the channel number and the recorded data coded by color.
  • Page 42 Videorecorder graphical user interface Button Meaning Back button. Click it to return. Note: Some models may not support face search and face smart playback. Introduction of area ②: Button Meaning Click it to go to the intelligent analytics interface. Click it to go to record search and backup interface; see 8.4 Record Search, Playback & Backup for details.

  • Page 43: A - Smart Playback

    Videorecorder graphical user interface format and then click the “Backup” button. In the backup window, you can select backup path and format. Then click “Backup”. Please select “Encryption” or “No Encryption” as needed. After that, click “OK” to start backup. 8.3a - Smart Playback • Smart Playback Settings. Click to go to the following interface. Set the value of “Speed of non-interest video” (Please skip this one if you click “Skip non-interest video”), “Speed of interest video” and “Intrusion percentage”. • Smart Playback by Drawing Rectangle.

  • Page 44: B - Smart Playback (Only For Nvr From Fw 1.4.4 Version)

    Videorecorder graphical user interface Click and draw a rectangle in the desired area. Then the system will automatically search the record files of this area. The cyan blocks indicate that there are intelligent recording files. Move the cursor to such block and click to play the record. • Smart Playback by Drawing Line. Click and draw a line in the desired area. Then the system will automatically search the record files about crossing this line. The cyan blocks indicate that there are intelligent recording files. Move the cursor to such block and click to play the record. • Smart Playback by Drawing Quadrilateral. Click and draw a quadrangle in the desired area. Then the system will automatically search the record files of this area. The cyan blocks indicate that there are intelligent recording files. Move the cursor to such block and click to play the record. 8.3b - Smart Playback In the playback interface, click to go to the smart playback interface as shown below.
  • Page 45 Videorecorder graphical user interface The descriptions of buttons in the smart playback interface Button Description Full screen motion button. Draw grid. You can search the record of motion detection in the pre-defined area. Draw line. You can search the record of crossing the line after drawing the line. Draw quadrilateral. You can search the record in this quadrilateral after drawing it. Search by face Playback settings button Return button.
  • Page 46 Videorecorder graphical user interface  Smart Playback by Drawing Quadrilateral Click and draw a quadrangle in the desired area. Then the system will automatically search the record files of this area. The cyan blocks indicate that there are intelligent recording files. Move the cursor to such block and click to play the record. 8.3.3 - Smart Playback by Face Search Before starting this function, the face recognition function shall be enabled. Please see Face Recognition for details. If your device doesn’t support such function, please skip the following instructions.

  • Page 47: Record Search, Playback & Backup

    Videorecorder graphical user interface 8.4 - Record search, Playback & Backup The record data and the snapped pictures can be backed up through network, USB (U disk or USB mobile HDD) or e-SATA (only available for some models). The file system of the backup devices should be FAT32 format. 8.4.1 - Search, Playback & Backup by time-sliced image 1- Click StartSearch and BackupBy Time-sliced Image to go to “By Time-sliced Image” tab. There are two view modes: by time and by camera. In the time view mode, a maximum of 64 camera thumbnails can be showed.

  • Page 48: Search, Playback & Backup By Time

    Videorecorder graphical user interface Time slice mode selecting: Method one: Click “Year”, “Month” or “Day” button under the record time scale to select the time slice mode. In “Day” mode, click on the left/right side of the time scale to view the record of the last/next day; click “Minute” in the “Picture” option under the time scale to select “Minute” mode (in “Minute” mode, click the time scale to change the time of the 60 display windows) and click “Hour” to select “Hour” mode. Method two: Click beside “Camera Thumbnail” on the left top corner of the interface to select the time slice mode. Method three: Right-click the mouse on any area of the time-sliced interface to go back to the upper interface. 8.4.2 - Search, Playback &...

  • Page 49: Search & Playback By Tag

    Videorecorder graphical user interface 2- Check the event type in the interface as required. 3- Click to set the start time and end time on the top left of the interface. 4- Check cameras on the left side of the interface and then click to search the record.

  • Page 50: Image Management

    Videorecorder graphical user interface : Smart playback settings button. Click it to set intrusion percentage. : Full screen motion button. : Motion button. : Draw line button. You can search the record of crossing the line after drawing the line. : Draw quadrilateral.

  • Page 51: Alarm Management

    Videorecorder graphical user interface 9 - Alarm management 9.1 - Sensor alarm To complete the entire sensor alarm settings, you should enable the sensor alarm of each camera and then set up the alarm handling of each camera. 1- Click StartSettingsAlarmSensor Alarm to go to the following interface. 2- Select the alarm type (NO or NC) according to trigger type of the sensor.

  • Page 52: Motion Alarm Handling Configuration

    Videorecorder graphical user interface Click “Reverse” to swap the motion area and the non-motion area. Click “Clear” to clear all the motion areas. 4- Click “Apply” to save the settings. Click “Processing Mode” to go to the alarm handling configuration interface of the motion alarm. 9.2.2 - Motion alarm handling configuration Click StartSettingsAlarmMotion Alarm to go to the following interface. 2- Enable or disable “Snap”, “Alarm-out”, “Preset”, “Buzzer”, “Pop-up Video” and “E-mail”. The alarm handling setting of motion alarm is similar to that of the sensor alarm (see 9.1 Sensor Alarm for details). 3- Click “Apply” to save the settings. You can click “Motion Settings” to go to the motion configuration interface. 9.3 - Exception alarm 9.3.1 - Exception handling settings Click StartSettingsAlarmExceptionException Handling Settings to go to the interface as shown below.

  • Page 53: Video Loss Settings

    Videorecorder graphical user interface 9.3.3 - Video loss settings (only for DVR) 1- Click StartSettingsAlarmExceptionVideo Loss Settings to go to the interface as shown below. 2- Enable or disable “Snap”, “Alarm-out”, “Preset”, “Buzzer”, “Pop-up Video”, “Pop-up Message Box” and “E-mail”. The Video Loss Settings are similar to that of the sensor alarm (see 9.1 Sensor Alarm for details). 3- Click “Apply” to save the settings 9.4 - Alarm event notification 9.4.1 - Alarm-out 1- Click StartSettingsAlarmEvent Notification to go to the following interface.

  • Page 54: Buzzer

    Videorecorder graphical user interface 9.4.4 - Buzzer Click StartSettingsAlarmEvent NotificationBuzzer to go to the buzzer configuration interface. Set the delay time of the buzzer and then click “Apply” to save the setting. You can click “Test” to test the buzzer. 9.4.5 - Push message Click StartSettingsAlarmEvent NotificationPush Message to go to the interface as shown below. Check “Enable” and then click “Apply” button to save the settings. If Push Server is online, it will push messages to the mobile clients. 9.5 - Manual alarm Click on the tool bar at the bottom of the live preview interface to pop up a window. Click “Trigger” to start alarm. Click “Clear” to stop alarm.
  • Page 55 Videorecorder graphical user interface If the exception information is more than one page, you can input the number in the box and then click to jump to the specified page. Click to view the exception alarm information in the previous/next page. Click to play the alarm record.

  • Page 56: Account & Permission Management

    Videorecorder graphical user interface 10 - Account & Permission management 10.1 - Account management Click StartSettingsAccount and AuthorityAccountEdit User to go to the interface as shown below. Area 1 displays the user permissions. Area 2 displays the user list. Click the user in the list to display its user permissions in area 1. There are three default permission groups (“Administrator”, “Advanced” and “Ordinary”) available when adding accounts. You can manually add new permission group (see 10.3.1 Add Permission Group for details).

  • Page 57: User Login & Logout

    Videorecorder graphical user interface • Modify password Only the password of admin can be modified. Click “Modify Password” to pop up a window. Input the current password and then set new password. Click “OK” to save the settings. • Modify Graphical lock Some models may not support this function. Click “Modify Pattern Lock” to pop up a window. Input current password and then check “Enable” to input pattern lock. • Recover password Click “Recover Password” to reset the password to 123456. • Edit user Click “Edit User” to pop up the window as shown below. The admin is enabled, its permission control is closed and permission group cannot be changed by default.

  • Page 58: Permission Management

    Videorecorder graphical user interface 10.3 - Permission management 10.3.1 - Add permission group Click StartSettingsAccount and AuthorityAccountEdit Permission Group to go to the interface as shown below. Click to add permission group. Set the group name, check the permissions as required and then set the “Local” and “Remote” permissions. Click “Add” to save the settings. 10.3.2 - Edit permission group Go to “Edit Permission Group” interface and then click in the group list to edit the permission group (the operations of the “Edit Permission Group” are similar to that of the “Add Permission Group”, please see 10.3.1 Add Permission Group for details). Click to save the group as another group. Click to delete the permission group. The three default permission groups (“Administrator”, “Advanced” and “Ordinary”) cannot be deleted.

  • Page 59: Preview On Logout

    Videorecorder graphical user interface MAC you add be effective). Enter the IP/IP segment/MAC and then click “OK” button. In the above interface, click to edit IP/IP segment/MAC, click to delete it. Click “Apply” to save the settings. 10.5 - Preview on logout Click StartSettingsAccount and AuthoritySecurityPreview On Logout to go to the following interface. Set a camera and then enable or disable the preview permission on logout as required. If a camera’s preview permission on logout is “ON”, you can view the live image of the camera when the system is logged out, or the live image of the camera cannot be seen when logged out. 10.6 - View online user Click StartSettingsAccount and AuthorityUser Status to view the online user information (you can view the online user name, login type, IP address and login time;...

  • Page 60: Device Management

    Videorecorder graphical user interface 11 - Device management 11.1 - Network configuration 11.1.1 - TCP/IP configuration Click StartSettingsNetworkTCP/IP to go to the following interface. Check “Obtain an IPv4 address automatically”, “Obtain an IPv6 address automatically” and “Obtain DNS automatically” to get the network addresses automatically, or manually input the network addresses. You can modify the MTU value according to the network condition (MTU, Maximum Transmission Unit, can be modified according to network condition for higher network transmission efficiency). Click “Apply” to save the settings. Note: • Internal ethernet port If you use the NVR with the PoE network ports, the online state of the internal ethernet port will be shown on the interface.

  • Page 61: Port Configuration

    Videorecorder graphical user interface Refer to the figure as shown below. If “Network Fault Tolerance” is selected, check “Obtain an IPv4 address automatically”, “Obtain an IPv6 address automatically” and “Obtain DNS automatically” to get the network addresses automatically, or manually input the network addresses; select one Ethernet port as the primary card and then click “Apply” button to save the settings. Multiple address setting: If “Multiple Address Setting” is selected, the IP addresses of the two Ethernet ports should be set respectively. Refer to the picture as shown below. Check “Obtain an IPv4 address automatically”, “Obtain an IPv6 address automatically” and “Obtain DNS automatically” to get the network addresses automatically, or manually input the network addresses; select one Ethernet port as the default route and then click “Apply” button to save the settings. 11.1.2 - Port configuration Click StartSettingsNetworkPort to go to the interface as shown below. Input the HTTP port, server port and RTSP port of the NVR/DVR and then click “Apply” to save the ports.
  • Page 62 Videorecorder graphical user interface HTTP port: the default HTTP port of the NVR/DVR is 80. The port number can be changed to others like 81. The port is mainly used to IE remote access. If you want to access the NVR/DVR through IE, you should input IP address plus HTTP port in the IE address bar like http://192.168.11.61:81. Note: The HTTP port and server port of the NVR/DVR should be mapped to the router before you access the NVR/DVR via WAN.

  • Page 63: Pppoe Configuration

    Videorecorder graphical user interface username and password which shall be as the same as the username and password of API server. Then you can view the video of channel 1. Note: only some versions may support API server function. Please skip the following instructions if your NVR doesn’t support it. Attention : only for NVR from Fw version 1.4.4 need to enable the sending the RTSP stream in the dedicated API server section and select Base64.

  • Page 64: E-Mail Configuration

    Videorecorder graphical user interface Create domain name and then click Request Domain. 4- After you successfully request your domain name, you will see your domain name information in the list. 5- Click StartSettingsNetworkDDNS to go to DDNS setting interface. Enable DDNS and then select the www.dvrdydns.com DDNS type. Input the registered username, password and domain name and then click “Apply”.

  • Page 65: Upnp Configuration

    Videorecorder graphical user interface Click “Edit Recipient” to go to the following interface. Click “Add” and then input the recipient’s e-mail address and select the schedule (if a schedule is selected, the system will send the alarm email and the recipient will receive it only in the selected schedule time) in the popup window. Click “Add” in the window to add the recipient. You can also change the recipient’s receiving schedule by clicking in the “Schedule” column. Click to delete the recipient in the list. Click “Apply” to save the settings. Click “Edit Sender” to go to the e-mail configuration interface of the sender. 11.1.6 - UPnP configuration By UPnP you can access the NVR/DVR through IE client which is in WAN via router without port mapping. 1- Click StartSettingsNetworkUPnP to go to the following interface.

  • Page 66: 802.1X

    Videorecorder graphical user interface 11.1.7 - 802.1X If it is enabled, the NVR data can be protected. When the NVR is connected to the network protected by the IEEE 802.1X, user authentication is needed. To use this function, the NVR shall be connected to a switch supporting 802.1x protocol. The switch can be considered as an authentication system to identify the device in a local network.

  • Page 67: Ftp Configuration

    Videorecorder graphical user interface Platform Access 1 - Set “Access Type” as “Platform Software” and select “Enable” as shown below. 2 - Check the IP address and port of the transfer media server in the ECMS/NVMS. The default server port for auto report is 2009. If it is modified, please go to the transfer media interface to check. 3 - Enable the auto report in the ECMS when adding a new device. Then self-define device ID and complete the remaining information of the device in the ECMS/NVMS. 4 - Enter the above-mentioned server address, port and report ID in the server interface. Then click “Apply” to save the settings. Now the ECMS/NVMS system will automatically connect this device. 11.1.10 - SNMP 1 - Click StartSettingsNetworkSNMP to go to the interface for SNMP configuration. 2 - Check SNMPv1or SNMPv2 to enable this function. 3 - Set the port of the SNMP.

  • Page 68: Date And Time Configuration

    Videorecorder graphical user interface Device name: The name of the device. It may display on the client end or CMS that help user to recognize the device remotely. Video format: Two modes: PAL and NTSC. Select the video format according to the camera. Note: You can set the resolutions of the main output and adjuvant output respectively if the NVR/DVR has dual outputs.

  • Page 69: Factory Default

    Videorecorder graphical user interface 11.3 - Factory default Click StartSettingsSystemMaintenanceFactory Default and then click “Reset to factory default” button in the interface to reset to the factory default settings. 11.4 - Device software upgrade You can click StartSettingsSystemInformationBasic to view MCU, kernel version and firmware version and so on. Before upgrade, please get the upgrade file from your dealer. The upgrade steps are as follows: 1- Copy the upgrade software into the USB storage device.
  • Page 70 Videorecorder graphical user interface • Update via the ByCamera App Make sure that in the DVR/NVR is enabled “Accept notification only”. Select the icon of the device marked with a red dot. Select Device "Cloud Upgrade". Then select "Upgrade immediatly".

  • Page 71: Backup And Restore

    Videorecorder graphical user interface The device will start the update. Do not shut down during the process. Reporting methods update available. By notification on the ByCamera App or by warning on XVR / NVR (displayed at the bottom right). 11.5 - Backup and restore You can back up the configuration file of the NVR/DVR by exporting the file to other storage devices; you can recover the configuration to other NVRs/ DVRs which are of the same model with the NVR/DVR by importing the configuration file to other NVRs/DVRs for time saving. Insert the USB storage device into the USB interface of the NVR/DVR and then click StartSettingsSystemMaintenanceBackup and Restore to go to the interface.
  • Page 72 Videorecorder graphical user interface 11.8 - View system information Click StartSettingsSystemInformation and then click the corresponding menu to view the “Basic”, “Camera Status”, “Alarm Status”, “Record Status”, “Network Status” and “Disk” information of the system.

  • Page 73: View System Information

    Videorecorder graphical user interface 12 - Remote surveillance 12.1 - Mobile client surveillance 1- Enable NAT in the NVR/DVR. Refer to 11.1.6 NAT Configuration for details. 2- Download and install the mobile client “SuperLive Plus” into the mobile device with the Android or iOS system. 3- Run the mobile client, go to the “Add Device” interface and then click to scan the QRCode of the NVR/DVR (Go to StartSettingsSystemInfo rmationBasic to view the QRCode of the NVR/DVR). 4- After scanning the QRCode successfully, input the login password to log in mobile client. 12.2 - Web LAN access 1- Click StartSettingsNetworkTCP/IPv4 to go to the “TCP/IPv4” interface. Set the IP address, subnet mask, gateway, preferred DNS and alternate DNS of the NVR/DVR.

  • Page 74: Web Remote Control

    Videorecorder graphical user interface Input the serial number (click on the tool bar at the bottom of the live preview interface to see the serial number of the NVR/DVR), user name (the user name of the NVR/DVR, admin by default) and password (the password of the NVR/DVR, 123456 by default) of the NVR/DVR, select the display language and then click “LOGIN” button to go the web client interface.
  • Page 75 Videorecorder graphical user interface • Start preview Select a window in the preview area and then click one online camera on the left panel to preview the camera in the window. You can click in the tool bar to preview all the cameras. •...

  • Page 76: Remote Playback

    Videorecorder graphical user interface Click one camera window in the preview area and then click to set the camera’s live preview stream and record stream to main stream in manual record mode; click to set the camera’s live preview stream and record stream to sub stream. In sub stream tab, set the resolution, FPS and bitrate and then click “Apply” to save the settings.

  • Page 77: Remote Backup

    Videorecorder graphical user interface Introduction of playback control buttons: Button Meaning Stop button. Rewind button. Click it to play video backward. Play button. Click it to play video forward. Pause button. Deceleration button. Click it to decrease the playing speed. Acceleration button.

  • Page 78: Appendix A - Faq

    Videorecorder graphical user interface Appendix A - FAQ Q1. Why can’t I find the HDD? Please check the power and SATA data cables of the HDD to make sure they are well connected. For some NVRs/DVRs with the 1U or small 1U case, the power of the adapter may be not enough for operating them. Please use the power adaptor supplied along with the NVR/DVR.
  • Page 79 Videorecorder graphical user interface b. Please make sure that the internal ethernet port and the IP camera which directly connects to the PoE port through ONVIF protocol are in the same network segment. The internal ethernet port and the IP camera which directly connects to the PoE port through ONVIF protocol should be in the same network segment, or you will fail to add the IP camera.
  • Page 80 Videorecorder graphical user interface 2- Select SecurityCustom Level. Refer to Fig 8-1. 3- Enable all the sub options under “ActiveX controls and plug-ins”. Refer to Fig 8-2. 4- Then click “OK” to finish setup. Other plug-ins or anti-virus may block ActiveX. Please disable or do the required settings. Fig 8-1 Fig 8-2 Q11. How to play the backup file? Record backed up by NVR/DVR: insert the USB device in which the record backup files is saved to the USB interface of the PC and then open the USB device path.
  • Page 81 Videorecorder graphical user interface • If you select the private format when backing up record by NVR/DVR, a RPAS compression package will be backed up to the USB device automatically along with the record data. Uncompress the “RPAS.zip” and then click “RPAS.exe” to set up RPAS. After the setup is completed, open RPAS player and then click “Open Folder” button in the middle of the interface to select the record data. Refer to the above picture. Select camera in the resource tree on the left side of the interface to play the camera record. Click on the tool bar under the camera image to enable audio.

  • Page 82: Appendix B - Calculate Recording Capacity

    Videorecorder graphical user interface Appendix B - Calculate recording capacity The recording capacity is mainly up to the record resolution, record stream and bitrate. Different image quality parameters decide different disk capacity occupation in equal times. The bigger the record resolution, record stream and record bitrate is, the more disk capacity is taken up in equal times. The calculation format of recording capacity is shown as below. Recording Capacity(MB) = Bitrate(Kbps) ÷1024 ÷...
  • Page 83 Videorecorder graphical user interface...
  • Page 84 Viale Vicenza, 14 36063 Marostica VI - Italy 49401261A0_EN 04 2112 www.vimar.com...
