Контрольная документация
Инструкции по перевозке, монтажу,
пусконаладке и техническому
обслуживанию осевых вентиляторов типа
Instructions for shipping, mounting, initial
operation and maintenance of axial fans range
97944 Boxberg-Windischbuch
AX...
AX...
Systemair GmbH
Seehöfer Straße 45
www.systemair.de
Advertisement
Table of Contents
Related Manuals for SystemAir AXC 630-9
Summarization of Contents
Fan Description
Fan Characteristics
Details fan performance parameters like airflow, pressure, efficiency, and motor power.
Motor Characteristics
Details motor type, construction, protection class, and power supply information.
Nominal Characteristics
Specifies fan's nominal speed, power, and current ratings.
Electrical Connection Diagrams
Diagrams for Single-Speed Motors
Illustrates wiring for single-phase and three-phase motors with optional thermal protection.
Safety Information
Airflow Direction
Illustrates airflow direction for different fan models (AXC, AXM, AXCBF).
Fan Applications
Standard Fans
Details applications for standard axial fans up to 55°C.
Smoke Extract Fans
Explains use of AXC-B fans for smoke extraction and ventilation.
Technical Description
AXC Fan Description
Describes direct-driven axial fans with motor in airflow, casing details.
AXC-(B) Models
Details specific features of AXC-(B) fans, including fire resistance certification.
AXCBF Models
Describes AXCBF fans with motor outside the airflow and specific casing flanges.
AXR Models
Explains AXR fans with reversible impellers and performance changes in reverse mode.
Transportation and Storage
Fan Transportation
Provides recommendations for transporting fans, advising against lifting by certain parts.
Fan Storage
Outlines conditions for storing fans, including duration and environmental factors.
Mounting Instructions
Pre-Mounting Checks
Lists essential checks before installing the fan, such as connections and foreign objects.
Safety Guidelines for Mounting
Emphasizes preventing unintended fan start and access to moving parts during installation.
General Fan Mounting
Covers general installation laws, airflow direction, vibration isolation, and access for maintenance.
Installation and Air Ducts
Details requirements for uniform airflow at inlet/outlet and blade pitch adjustment.
Electrical Installation
Fan Connections
Details electrical connection procedures, voltage tolerances, and motor protection requirements.
Electrical Wiring Diagrams
Single-Speed Motor Diagrams
Provides wiring diagrams for single-speed motors with optional thermal contacts.
Two-Speed Motor Diagrams
Offers wiring diagrams for two-speed motors and Dahlander motors.
Initial Operation
Pre-Operation Checks
Lists checks like fan mounting, connections, safety devices, and electrical setup before initial run.
Inspection and Acceptance
System Functionality Check
Emphasizes verifying system and control equipment function and conformity to project requirements.
Maintenance
Preventing Accidental Start
Stresses the importance of preventing unintended fan starts during maintenance or repair.
Troubleshooting
Failure Detection and Removal
Covers common issues like fan not running, low air volume, motor protection trips, noise, and vibrations.
Warranty Conditions
Warranty Provision Terms
Outlines warranty validity based on proper installation, connection, and periodic checks.
