Summarization of Contents
Chapter 1 General Information
1.1 Introduction
Overview of Advantech's industrial-grade monitors designed for intuitive operation in industrial environments.
1.2 Specifications
General technical specifications covering construction, front panel, video port, mounting, and dimensions for the FPM-200 series.
1.3 LCD Specification
Detailed specifications for the 12", 15", and 17" LCD panels, including display type, resolution, luminance, and temperature ratings.
1.4 Connectors
Information on the available ports: DP/HDMI, VGA (DB-15), Touchscreen (USB), and DC 12V Power Input.
1.5 Interface
Diagram illustrating the I/O port arrangement on the FPM-200 series monitors.
1.6 Dimensions
Physical dimensions for the 12", 15", and 17" FPM-212, FPM-215, and FPM-217 models.
Chapter 2 Mounting Methods
2.1.1 Panel Mounting
Instructions for mounting the monitor in a panel using 10 clampers and M4 x 25mm screws.
2.1.2 Wall Mounting
Guide for wall mounting the monitor using the optional FPM-1000T kit and M4 screws.
2.1.3 Desktop Stand Mounting
Procedure for mounting the monitor using a desktop stand with M4 screws.
2.1.4 VESA Mounting
Details on VESA MIS-D, 75 compliance and using M4 screws for mounting.
2.1.5 Power Adapter Bracket Mounting (Optional)
Guide for mounting an optional metal bracket to secure power adapters and cords.
Appendix A Touchscreen
A.1 Introduction
Overview of the advanced 5-wire resistive touchscreen technology used in the FPM series.
A.2 Touchscreen Specifications (12"/15"/17")
Optical, electrical, and environmental specifications for the 12", 15", and 17" touchscreen models.
A.3 Installing Drivers for Windows OS
Instructions for installing Penmount 6000 drivers for Windows 7/8/10 and Linux.
