Viking DDBB536RSS Specification Sheet

Quiet cool built-in 36”w. bottom-mount refrigerator/freezer.
Hide thumbs

1
2
3
4
5
6
7
8
9
10
  • Contents

Advertisement

Table of Contents
Standard Features & Accessories
All models include
• Total capacity—20.3 cu. ft. (574.5 L)
o Refrigerator - 15.2 cu. ft.
o Freezer - 5.1 cu. ft.
o 84"H./24"D.
• ProChill™ Temperature
Management System
o Variable-speed DC Overdrive™
Compressor is one of the quietest,
most technologically advanced com-
pressors available
o Electronic controls maintain the tem-
perature selection within 1ºF
o Multi-channel airflow system and
Odor Eliminator™ Evaporator
removes odors and excess humidity
• Exclusive Plasmacluster™* Ion Air
Purifier
o Eliminates airborne bacteria and
mold spores
o Removes odors
o Enhances food preservation
o Never needs replacing
• Refrigerator Compartment
Model Options
VCBB536/VIBB536
Professional/Professional
Integrated
FINISH DETAILS FOR VCBB/VIBB MODELS
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite
Gray (GG), Stone Gray (SG), Taupe
(TP), Biscuit (BT), Cotton White (CW),
Oyster Gray (OG), Golden Mist (GM),
Lemonade (LE), Sage (SA), Mint Julep
(MJ), Sea Glass (SE), Iridescent Blue
(IB), Viking Blue (VB), Pumpkin (PM),
Racing Red (RR), Apple Red (AR),
Burgundy (BU), Plum (PL), Chocolate
(CH), and Cobalt Blue (CB).
• Finish codes designate door fronts.
Stainless steel upper grille, side trim,
and handles (with chrome-plated
brackets); black lower kickplate.
• Brass Accent Option (BR)—nameplate
and handle endcaps. Brass compo-
nents have a durable protective coat-
ing for maintenance-free normal use.
ORDERING INSTRUCTIONS
First specify model number, followed by hinge preference ("R" for right or "L" for left), and then color code (VCBB536RSS).
If ordering optional brass accent, specify code at end (VCBB536RSSBR).
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M
Quiet Cool™ Built-In 36"W. Bottom-Mount
o Five adjustable tempered glass spill-
proof shelves
• Adjustable Cold Zone™ drawer with
precision ball-bearing glides
o Separate temperature control can be
set for produce or fresh meat storage
o Quick chill option chills foods and
beverages in minutes
• Adjustable Humidity Zone™ drawers
with precision ball-bearing glides
o Humidity can be set high for leafy
greens or low for fruits and vegeta-
bles with skins
• Two conveniently located deli drawers
with full-extension precision ball-bear-
ing glides
• Two in-the-door sealed dairy
compartments with covers
• Four patented adjustable aluminum
door bins with tempered glass fronts
• Top-shelf provides quick chill-down
area
• Full extension freezer drawer on preci-
sion ball-bearing glides
DDBB536
Designer
FINISH DETAILS FOR DDBB MODEL
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite
Gray (GG), Stone Gray (SG), Taupe
(TP), Biscuit (BT), Cotton White (CW),
Oyster Gray (OG), Golden Mist (GM),
Lemonade (LE), Sage (SA), Mint Julep
(MJ), Sea Glass (SE), Iridescent Blue
(IB), Viking Blue (VB), Pumpkin (PM),
Racing Red (RR), Apple Red (AR),
Burgundy (BU), Plum (PL), Chocolate
(CH), and Cobalt Blue (CB).
• Finish codes designate door fronts.
Stainless steel upper grille, side trim,
and handles; black lower kickplate.
•
1 - 8 8 8 - V I K I N G 1
REFRIGERATION
Refrigerator/Freezer
o Positive self-closing feature ensures a
good seal
o Adaptive defrost
o Two slide-out wire baskets
• Super Clog-Resistant™ Condenser is
maintenance-free under normal use
• Tru-Flush™ design
o Allows Professional Integrated and
Custom Panel models to fit flush into
24" deep installation cutout
• Open door alarm sounds and glows to
warn that door has been ajar for three
minutes
• Adjustable door stops standard—90°,
110°, or 120° swing
• Sabbath Mode
• Must be ordered right or left hinge.
(As you face unit, RIGHT has hinge on
right side and handle on left side;
LEFT has hinge on left side and han-
dle on right side.)
*Plasmacluster is a registered trademark
of Sharp Corporation.
DFBB536
Custom Panel
FINISH DETAILS FOR DFBB MODEL
• Handles not included—opt for custom
handles, or purchase a Viking
Professional Series or Designer Series
handle kit (see Installation Notes &
Accessories).
• See Custom Panels section for
more information and additional
specifications.
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
Previous page
Next page

Advertisement

   Also See for Viking DDBB536RSS

Viking Designer DDFB530 User Manual
Viking Designer DDFB530 User Manual 24 pages
Viking DDWB301CRSS Installation Instructions
Viking DDWB301CRSS Installation Instructions 2 pages
Viking DDBB536RSS Energy Manual
Viking DDBB536RSS Energy Manual 1 page

   Related Manuals for Viking DDBB536RSS

   Summary of Contents for Viking DDBB536RSS

  • Page 1 Lemonade (LE), Sage (SA), Mint Julep (MJ), Sea Glass (SE), Iridescent Blue more information and additional (MJ), Sea Glass (SE), Iridescent Blue (IB), Viking Blue (VB), Pumpkin (PM), specifications. (IB), Viking Blue (VB), Pumpkin (PM), Racing Red (RR), Apple Red (AR),...

  • Page 2: Dimensions And Specifications

    REFRIGERATION Quiet Cool™ Built-In 36”W. Bottom-Mount Refrigerator/Freezer Dimensions & Specifications Please see Installation Notes & PRODUCT DIMENSIONS Accessories for important information, including panel, grille, and handle kits. VCBB536/VIBB536 ALL MODELS Professional/Professional Star-K Kosher Integrated Certification for use on the Jewish Sabbath or Jewish holidays 3 - 1...
  • Page 3 REFRIGERATION Quiet Cool™ Built-In 36”W. Bottom-Mount Refrigerator/Freezer Dimensions & Specifications Please see Installation Notes & PRODUCT DIMENSIONS Accessories for important information, including panel, grille, and handle kits. DDBB536 ALL MODELS Designer Star-K Kosher Certification for use on the Jewish Sabbath or Jewish holidays 3 - 1 ( 8 8...

  • Page 4: Custom Panel

    REFRIGERATION Quiet Cool™ Built-In 36”W. Bottom-Mount Refrigerator/Freezer Dimensions & Specifications Please see Installation Notes & PRODUCT DIMENSIONS Accessories for important information, including panel, grille, and handle kits. DFBB536 ALL MODELS Custom Panel Star-K Kosher Certification for See Custom Panels section use on the Jewish for more information and Sabbath or Jewish...
  • Page 5 REFRIGERATION Quiet Cool™ Built-In 36”W. Bottom-Mount Refrigerator/Freezer Dimensions & Specifications DOOR SWING • Adjustable door stops standard—90°, 110°, or 120° swing VCBB536/VIBB536 DDBB536 DFBB536 Professional/Professional Designer Custom Panel Integrated See Custom Panels section for more information and additional specifications. 3 3 6 6 ” ” ( ( 9 9 1 1 .
  • Page 6 REFRIGERATION Quiet Cool™ Built-In 36”W. Bottom-Mount Refrigerator/Freezer Dimensions & Specifications CLEARANCE DIMENSIONS—PROFESSIONAL TOP VIEW Wall 1-13/16” (4.6 cm) space if 24” standard cabinet depth is used 24” (61.0 cm) standard cabinet depth 3/4” (1.9 cm) full end panel Countertop overhang Door 2-1/2”...
  • Page 7 REFRIGERATION Quiet Cool™ Built-In 36”W. Bottom-Mount Refrigerator/Freezer Dimensions & Specifications CLEARANCE DIMENSIONS—PROFESSIONAL INTEGRATED/DESIGNER TOP VIEW Wall 1” (2.5 cm) if 25” (63.5 cm) 25” cabinet depth is used (63.5 cm) countertop depth 24” (61.0 cm) standard 3/4” cabinet depth (1.9 cm) full end panel Door Flush...

  • Page 8: Installation Requirements

    REFRIGERATION Quiet Cool™ Built-In 36”W. Bottom-Mount Refrigerator/Freezer Installation Requirements UTILITY REQUIREMENTS ACCESS REQUIREMENTS Not applicable VCBB536/VIBB536 DDBB536 DFBB536 Professional/Professional Designer Custom Panel ELECTRICAL Integrated • Three-wire cord with grounded See Custom Panels section three-prong plug for more information and attached to additional specifications.
  • Page 9 REFRIGERATION Quiet Cool™ Built-In 36”W. Bottom-Mount Refrigerator/Freezer Installation Requirements ACCESS REQUIREMENTS – Dual Installation 6 ” ( 1 5 . 2 c m ) 9 ” 9 ” ( 2 2 . 9 ( 2 2 . 9 c m ) c m ) 8 2 - 7 / 8 ”...

  • Page 10: Compliance Information

    • Ninety-day limited warranty—cosmetic parts such as glass, painted, and decorative items (Professional and Designer) * For complete warranty see Use & Care Guide. Warranty valid on Viking products shipped within the United States and Canada. P L A N N I N G A N D D E S I G N G U I D E R E V I S E D 5 / 2 / 1 1 ©...
