Summarization of Contents
Partition Plate and Sound Blankets Removal
Remove Partition Plate
Procedure to remove the partition plate by unscrewing and lifting.
Remove Sound Blankets
Procedure to remove top and outer sound blankets, cautioning on piping ports.
Electronic Expansion Valve Coil and Four Way Valve Removal
Remove Four Way Valve Coil
Procedure to remove the four way valve coil by unscrewing.
Remove Electronic Expansion Valve Coil
Procedure to pull out the electronic expansion valve coil.
Remove Terminal Cover
Procedure to remove the terminal cover.
Remove Protection Bushing
Procedure to remove the protection bushing.
Disconnect Compressor Lead Wires
Procedure to disconnect compressor lead wires and overload protector.
Remove Putty and Four Way Valve
Procedure to remove putty and heat brazed parts to remove the four way valve.
Compressor Removal
Remove Terminal Cover
Procedure to remove the terminal cover.
Remove Protection Bushing
Procedure to remove the protection bushing.
Disconnect Compressor Lead Wires
Procedure to disconnect compressor lead wires and overload protector.
Disconnect Discharge Side Pipe
Procedure to heat and disconnect the discharge side pipe.
Disconnect Suction Side Pipe
Procedure to heat and disconnect the suction side pipe.
Remove Compressor Nuts
Procedure to remove the two nuts securing the compressor.
Remove Compressor
Procedure to lift and remove the compressor.
