Summary of Contents for Sherwood CD-772
-
Page 3: Ƒu Read This Before Operating Your Unit
Introduction READ THIS BEFORE OPERATING YOUR UNIT This symbol is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclo- sure that may be of sufficient magnitude to constitute a risk of electric shock to persons. : TO REDUCE THE RISK OF ELECTRIC CAUTION This symbol is intended to alert the user to the presence of... - Page 4 SAFETY INSTRUCTIONS 1. Read Instructions - All the safety and operating instructions should Figure 1 be read before the product is operated. Example of antenna grounding as per National Electrical Code, ANSI/NFPA 70 2. Retain instructions - The safety and operating instructions should ANTENNA LEAD IN be retained for future reference.
- Page 5 FOR YOUR SAFETY Units shipped to the U.S.A and Canada are designed for operation on 120 V AC only. Safety precaution with use of a polarized AC plug. However, some products may be supplied with a nonpolarized plug. U.S.A CAUTION : To prevent electric shock, match wide blade of plug to wide slot, fully 120 V insert.
-
Page 6: Table Of Contents
CONTENTS Introduction ƒU READ THIS BEFORE OPERATING YOUR UNIT ............... 2 Rear Panel Connections ......................6 Front Panel & Remote Controls ..................ƒU REMOTE CONTROL OPERATION RANGE ................9 ƒU LOADING BATTERIES ....................... 9 Preliminary Knowledge About Discs ƒU PLAYABLE DISCS ........................10 ƒU MP3 COMPATIBILITY ...................... -
Page 7: Rear Panel Connections
Connect these jacks to CD (or AUX) INPUT jacks of your amplifier/receiver. 2. Connecting DIGI-LINK jack Connect this jack to the DIGI-LINK jack of Sherwood system amplifier/receiver such an RX-772, etc. to control this unit remotely by DIGI-LINK system. (For details, refer to the operating instructions of Sherwood amplifier/receiver.) -
Page 8: Front Panel & Remote Controls
Front Panel & Remote Controls Front Panel Controls Remote Controls... - Page 9 1. POWER SWITCH 10. DIMMER BUTTON Push this switch to turn the power on and to enter the Press this button to select the brightness of the operating mode. fluorescent display as desired. To switch the power off, push again this switch. 11.
-
Page 10: Ƒu Remote Control Operation Range
REMOTE CONTROL OPERATION RANGE • Use the remote control unit within a range of about 7 meters (23 feet) and angles of up to 30 degrees aiming at the remote sensor. LOADING BATTERIES Remove the cover. Load two batteries ("AAA" size, 1.5 V) matching the polarity. -
Page 11: Preliminary Knowledge About Discs
Preliminary Knowledge About Discs PLAYABLE DISCS MP3 COMPATIBILITY This unit supports the following discs. • MP3 discs must be ISO 9660 Level 1 or Level 2, Joliet compliant. Supported formats : Mode 1, Mode 2. Disc Logo Format or file type •... -
Page 12: Ƒu Care And Handling Of Discs
CARE AND HANDLING OF DISCS • In handling a disc, hold it carefully with edges. • Do not stick paper or write anything on the printed surface. • Fingermarks and dust on the recorded surface should be carefully wiped off with a soft cloth. Wipe straight from the inside to the outside of the disc. -
Page 13: Operations
Operations • In this operating instructions, MP3 files are referred to as tracks. PLAYING CDS Turn the power on. • The power is turned on and this unit enters the operating mode. • To switch the power off, push the POWER switch again. -
Page 14: Ƒu Repeat Play
To select tracks during play To skip back To skip ahead • Each time the button is pressed, a track is skipped. • When the REVERSE SKIP ( ) button is pressed once midway through a track, play returns to the beginning of that track. -
Page 15: Ƒu Playing Tracks In Random Order
Repeating a specific passage During play at the beginning of the desired passage, press the REPEAT A/B button. Then "A" is displayed. At the end of the desired passage, press the REPEAT A/B button again. ƒU Then "AB" is displayed and the passage between points A and B is played repeatedly. ƒU To cancel the repeat A/B play, press the REPEAT A/B button again. -
Page 16: Ƒu Playing Tracks In Desired Order (Program Play)
PLAYING TRACKS IN DESIRED ORDER (PROGRAM PLAY) • Up to 20 tracks can be programmed to be played in any desired order. In the stop mode, press the PROGRAM button. • Then "PGM" is displayed. Select the desired track and store it in the memory. •... -
Page 17: Ƒu Listening To Music For A More Detailed Sound Quality
Continued § Checking the programmed tracks ƒU In the program mode (meaning "PGM" is displayed in the stop mode), press the FORWARD/REVERSE SEARCH( ) buttons. Each time these buttons are pressed, the pro- grammed tracks are displayed in the programmed order or in the opposite order. -
Page 18: Ƒu Displaying Disc Information During Play
DISPLAYING DISC INFORMATION DURING PLAY Each time the DISPLAY button is pressed, the dis- play mode changes depeding on the disc types as follows : ƒU In case of Audio CD ƒU In case of MP3 disc Elapsed time of the current track Elapsed time of the current track Remaining time of the current track Name of the current track... -
Page 19: Troubleshooting Guide
Troubleshooting Guide If a fault occurs, run through the table below before taking your unit for repair. If the fault persists, attempt to solve it by switching the unit off and on again. If this fails to resolve the situation, con- sult your dealer. -
Page 20: Specifications
Specifications § TYPICAL AUDIO PERFORMANCES • Number of channels ................2 •...
