Summarization of Contents
Introduction
Intended Use
Purpose of the instrument for inspection and observation of machinery interiors.
Instruction Manual
Contains information for safe operation and handling of the instrument.
Safety Precautions
General Safety Precautions
Strict adherence to precautions for safe handling; supplements chapter info.
Battery Precautions
Dangers, warnings, and cautions related to battery handling and charging.
Nomenclature
2-1 Nomenclature
Identifies various parts of the main unit with numbered labels and names.
2-3 LCD Monitor Nomenclature
Identifies icons, indicators, and names displayed on the live and freeze screens.
Pre-operation Preparation and Inspection
3-1 Preparing the Power Supply
Steps for loading and removing the battery and connecting the AC adapter.
Basic Operation
4-1 Turning ON the Power
Steps to turn the instrument on and off.
4-5 Observing the Inspection Object
Procedure for inserting, angulating, and viewing the inspection area.
4-8 Recording Images
Preparing media, recording still images and movies.
Measurement Functions
6-1 Scaler Measurement Function
Measuring object length using a preset reference length.
6-2 Stereo Measurement Function
Performing stereo measurements using a special optical adapter.
Troubleshooting
Error Messages
Lists error messages and recommended actions for troubleshooting.
Common Problems
Lists common issues and their potential causes and solutions.
