Features And Benefits - Encore ENH924-AUT Specifications

The switch is plug-n-play without any software to configure and also fully compliant with all
kinds of network protocols. Moreover, the rich diagnostic LEDs on the front-panel can
provide the operating status of individual port and whole system.

Features and Benefits

Complies with 10BASE-T specifications of the IEEE802.3 standard
Complies with 100BASE-TX specifications of the IEEE802.3u standard
Supports NWAY protocol for speed (10/100Mbps) and duplex mode (Half/Full)
auto-detection
24 RJ-45 Ethernet ports for 100Base-TX and 10Base-T connectivity
All Ports are Auto MDI/MDI-X auto crossover
Supports full and half duplex operation on all ports
Wire-speed packet filtering and forwarding rate
Store-and-forward architecture filters fragment & CRC error packets
Supports 8K MAC address entries in whole system
160 KB buffer memory
Supports extensive LED indicators for network diagnostics
Internal switching power supply: 100-240VAC
Specification
Standard
Interface
Uplink
Network Speed
MAC Address Table
Memory
Power Supply
EMI
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3x full duplex operation and flow control
24 10/100Mbps RJ-45 Fast Ethernet ports
Auto MDI/MDI-X (Auto crossover)
10/100Mbps & Full/Half duplex mode auto detection
8K MAC address entries
156 Kbytes
Internal power supply: 3.3V 4A (100-240V/ 50-60Hz)
CE and FCC class A
