Summary of Contents for Encore ENHGS-224
- Page 2 FCC Certifications ENHGS-224 has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
-
Page 3: Key Features
Key Features Provide 24 Fast Ethernet (10/100 Mbps) ports and 2 Gigabit Ethernet (10/100/1000 Mbps) ports Allow each port to run at its optimal speed while reducing network congestion Feature plug-n-play operation that doesn’t require any software configuration ... -
Page 4: Front Panel
Front Panel Please refer to the following description for the front panel: Ethernet Ports: This Switch includes 24 Fast Ethernet ports and 2 Gigabit combo ports. LED Definition: Status Operation Power Steady Green Power is on Power is off Link/Act Steady Green The port is connected Blinking Green... - Page 5 Installation Before you install the switch, please check the following items in the package： One 24-port Fast Ethernet +2 Gigabit Combo-port Switch One Power cord One user manual Four rubber feet Rack-mount brackets and screws In the following there are two ways for your installation.
-
Page 6: Network Application
Station Connection Connect each station to the switch by twisted-pair cable. Plug one RJ-45 connector into a RJ-45 port of the switch, and plug the other RJ-45 connector into the station’s network adapter. Power on the switch and then system is ready. Switches Connection In making a switch interconnection, you could use any port to connect another switch with straight or crossover cable. - Page 7 Specification IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-TX Standard IEEE 802.3ab for 1000BASE-T IEEE 802.3x full duplex operation and flow control 24 * 10/100Mbps RJ-45 Ethernet ports Interface 2 * 10/100/1000Mbps RJ-45 ports Buffer 320K bytes Memory Filtering/ 10M: 14881 pps Forwarding 100M: 148810 pps Rate...
