- Page 1 ENHGS-500X2 5-Port Gigabit Switch ENHGS-800X4 8-Port Gigabit Switch User’s Manual...
- Page 2 No part of this document can be copied or reproduced in any form without written consent from the company. Trademarks: All trade names and trademarks are the properties of their respective companies. Encore Electronics Inc., Copyright © 2010, All Rights Reserved.
- Page 3 Store-and-forward switching mode promises a low latency plus eliminates all the network errors, including runt and CRC error packets. ENHGS-500X2 / ENHGS-800X4 can provide a backbone link to your switched workgroup or a server fat-pipe link. With flexible architecture, users can easily implement a wired network without bandwidth limitations.
-
Page 4: Led Definition
Led Definition Please refer to the following table for LED definition: ENHGS-500X2 (5-Port switch) ENHGS-800X4 (8-Port switch) Status Operation Power Steady Green Power is on Power is off Link/ACT Steady Green Port connected Blinking Green The port is transmitting/receiving data... - Page 5 Stations connection Connect each station to the switch by twisted-pair cable. Plug one RJ-45 connector into a RJ-45 port of the switch, and plug the other RJ-45 connector into the station’s network adapter. Power on the switch and then system is ready. For cable selection, refer to the following table.
- Page 6 Interface Auto MDI/MDI-X（ Auto crossover） Uplink 10/100/1000Mbps Full/Half duplex mode auto detection (1000Mbps for Full duplex Network Speed only) 1K MAC entries (ENHGS-500X2) MAC Address 4K MAC entries (ENHGS-800X4) Table 104K bytes (ENHGS-500X2) Buffer Memory 128K bytes (ENHGS-800X4) 12K bytes (ENHGS-500X2)
