Summarization of Contents
Preparations Before Using
Install the Battery
Instructions for installing the battery pack into the scanner's battery cavity.
Charge the Battery via Power Supply Unit
Guidance on charging the scanner's battery using a power supply unit and cradle.
Charge the Battery via USB 3.0 Port
Details on charging the scanner's battery using a USB 3.0 port on a host device.
Decide Your Radio Link Mode
PAIR Mode
Connects scanner to cradle for plug-and-play without Bluetooth host. Supports legacy interfaces.
PICO Mode
Allows up to 7 scanners to connect to one smart cradle concurrently for multiple connections.
HID Mode
Scanner functions as a Bluetooth Keyboard, discoverable by remote host for connection.
SPP Master/Slave Mode
Scanner acts as a Bluetooth Serial Device, supporting Master and Slave roles for connection.
Use FuzzyScan in PAIR Mode
Pairing Process
Steps to connect scanner and smart cradle in PAIR mode, including indicator signals.
Use FuzzyScan in PICO Mode
PICO Mode Pairing
Procedure for pairing scanners with a smart cradle in PICO mode, including indicator lights.
Use FuzzyScan in HID Mode
HID Mode Connection
Steps to connect scanner in HID mode, including Bluetooth discovery and indicator status.
Use FuzzyScan in SPP Mode
Establish SPP Master Connection
Guide to setting up SPP Master connection, including virtual COM port and pairing.
Establish SPP Slave Connection
Instructions for setting up SPP Slave connection, including Bluetooth discovery and pairing.
Advanced Scanning Features
Out-of-range Scanning
Enables scanning and storing data when out of radio coverage, transmitting upon reconnection.
Presentation Scanning
Hands-free scanning mode, with auto-sense for placement on stand or cradle.
Power off the Scanner
Methods to power off the scanner, either by timeout or scanning a command.
Batch Scanning and Quantity
Batch Scanning (Inventory Mode)
Stores large volumes of barcode data for inventory, with capacity up to 100,000 EAN-13 barcodes.
Use Quantity Feature
Allows entering quantity information with scanned barcode data for storage.
Data Transmission and Deletion
How to Transmit Stored Data
Methods to transmit stored barcode data, either via command or by placing scanner on cradle.
How to Delete the Last Scanned Data
Command to delete the most recently scanned barcode data to correct errors.
Quick Set Commands
Link Mode Quick Set
Barcodes for quickly setting Link Modes: SPP Master/Slave, HID, and UNINSTALL.
Host Interface Quick Set
Barcodes for setting host interface for Smart Cradle: RS232, USB HID, USB COM.
Keyboard Layout Quick Set
Barcodes to set keyboard layouts for different regions and languages.
System Commands and Operation Modes
System Commands
List of system commands including Paging, Master Default, Power Off, and Factory Default.
Operation Mode Quick Set
Barcodes for setting operation modes, specifically Trigger Mode and Presentation Mode.
Indications and Indicators
Scanner Indications
Details on Link Indicator and Status Indicator behavior for various scanner states.
HB2112 Smart Cradle Indications
Indicator lights (Central and Side) for the Smart Cradle during different operations.
HB2100 USB Charging Cradle Indication
Central Indicator status for the HB2100 USB Charging Cradle.
Disclaimers and Warranty
Disclaimer
Legal notice regarding Cino's warranty, liability, and copyright for the publication.
Warranty
Information on Cino's product warranty against defects in workmanship and materials.
Regulatory Information
Details on regulatory compliance, including FCC, CE, MIC, and eye safety standards.
