  • Page 1 International Edition, Rev. D14...

  • Page 2: Revision History

    Revision History Rev. No. Released Date Description  First Release Rev.B Beta Apr. 16, 2009  Modify “Symbology Reading Control” - “Code 128/EAN-128 Setting” and “ GS1 DataBar Setting” Rev.B0 May 05, 2009  Add “Appendix” - “Symbology ID Table”. ...
  • Page 3 Revision History Rev. No. Released Date Description  Modify “Serial Interface Control” – “ Baud Rate” Rev. B6 May 27, 2010  Modify “Symbology Reading Control” - “UPC-A & UPC-E Setting” Rev. B7 Jun 25 , 2010  Modify “Operation Control” - "Time Delay to Low Power Mode" ...

  • Page 4: Getting Familiar With Your Fuzzyscan

    Revision History Rev. No. Released Date Description  Modify “Symbology Reading Control” - “ Data Matrix Setting Rev. D2 Apr. 22. 2013  Modify “Operation Control” - “Batch Reading rule example”  Modify “Symbology Reading Control” - “Readable Bar Code Setting” Rev.
  • Page 5 © Copyright PC Worth Int’l Co., Ltd Cino makes no warranty of any kind with regard to this publication, including, but not limited to, the implied warranty of merchantability and fitness for any particular purpose. Cino shall not be liable for errors contained herein or for incidental consequential damages in connection with the furnishing, performance, or use of this publication.

  • Page 6: Table Of Contents

    Table of Contents Getting Started Getting Familiar with Your FuzzyScan Connecting to Your Host Using Accessories Configure Your FuzzyScan Bar Code Programming Manual Programming Procedures Host Interface Selection Symbology Reading Control Keyboard Interface Control Serial Interface Control Wand/Laser Emulation Control Operation Control Condensed DataWizard Appendix...
  • Page 7 Getting Started Getting Familiar with Your FuzzyScan A780 Series Thank you for choosing Cino FuzzyScan Bar Code Scanner. All FuzzyScan scanners deliver world-class performance for a broad range of applications to unleash your productivity. FuzzyScan family includes A series area imager, F series linear imager and L series laser imager.
  • Page 8 Getting Started F790/F780/ L780 Series A670/F680/L680 Series F560 Series Power Indicator Scan Window Status Indicator Beeper Trigger Cable Release Hole...

  • Page 9: Connecting To Your Host

    Getting Started Connecting to Your Host RS232 Serial FuzzyScan scanners support USB and RS-232 Serial interfaces. Please choose your desired interface cable, then plug it into the cable interface port of the scanner and connect it to the host. If you would like to remove the cable, please straighten one end of a paper clip, and then insert it into the cable release hole to pull out the cable.

  • Page 10: Using Accessories

    Getting Started Using Accessories Hand-free SmartStand You can enhance productivity of your workforce by using various accessories to fulfill a wide variety of application demand. Universal Holder SmartStand specifically designed hand-free applications to maximize user’s comfort and productivity. You can adjust the scanner holder to desired position for optimized scanning.

  • Page 11: Bar Code Programming Manual

    Configure Your FuzzyScan Bar Code Programming Manual System Command The FuzzyScan bar code commands are specially designed Proprietary bar code labels which allow you to set the The System Command is the highest level bar code FuzzyScan internal programming parameters. There are command which directs FuzzyScan to perform immediate System Command, Family Code and Option Code for operations,...

  • Page 12: Programming Procedures

    Configure Your FuzzyScan Programming Procedures As you scan the bar code command to select the desired If the programming family must take multiple scans parameters, information about the final selected parameters selection, cycling scan selection, or dual level selection represented by the bar code commands are stored in the procedures, the family of the programming menu will be FuzzyScan’s internal Flash Memory ASIC or memory.
  • Page 13 Configure Your FuzzyScan Program & End System List, Group & Master Default Scan Scan “SYSLIST” “PROGRAM” FuzzyScan will list the product information and FuzzyScan will enter programming mode, revision number to host via selected host interface, and inhibit all non-programming functions. then issue the completion beeping.
  • Page 14 Configure Your FuzzyScan Single scan selection Multiple scans selection Scan Scan “PROGRAM” Enter program m ing m ode. “PROGRAM” Enter programming mode. Select one of desired Select one of desired Scan Scan program m ing fam ilies. programming families. One of Family Codes One of Family Codes 1.
  • Page 15 Configure Your FuzzyScan Cycling scan selection Dual level selection S ca n S ca n “P R O G R A M ” E nter program m ing m ode. “P R O G R A M ” E nter program m ing m ode. S elect one of desired S elect one of desired S ca n...

  • Page 16: Host Interface Selection

    Configure Your FuzzyScan Host Interface Selection PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code IBM PS/2, 25-30 series keyboard wedge interface Host Interface Selection Standard/TTL RS-232 peer-to-peer serial Wand Emulation USB Com Port Emulation PS/2 (DOS/V) direct link (keyboard replacement) PS/2 (DOS/V) keyboard wedge turbo mode PS/2 (DOS/V) keyboard wedge standard mode Laser emulation...
  • Page 17 Configure Your FuzzyScan Symbology Reading Control  User Defined Symbol ID  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code 2nd Option Code Code 128 (default=B) (1 character) Symbol ID : 1 character GS1-128 (default=C) (1 character) UPC-A (default=A) (1 character) EAN-13 (default=F) (1 character)

  • Page 18: Symbology Reading Control

    Configure Your FuzzyScan Symbology Reading Control  User Defined Symbol ID  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code 2nd Option Code Aztec Code (default=e) (1 character) Symbol ID : 1 character Chinese Sensible (default=f) (1 character) Australian Post (default=g) (1 character) British Post (default=h) (1 character)
  • Page 19 Symbology ID Transmission Enable prefix CINO symbology ID transmission Enable suffix CINO symbology ID transmission Enable both prefix and suffix CINO symbology ID transmission Enable prefix AIM symbology ID transmission Enable suffix AIM symbology ID transmission Enable both prefix and suffix AIM symbology ID transmission...
  • Page 20 Configure Your FuzzyScan Symbology Reading Control  Readable Bar Code Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Auto  Readable Symbology Setting Popular 1D Code 128 * GS1-128 * UPC-A * UPC-E * EAN-13 * EAN-8 * Codabar/NW-7 * Code 39 * Trioptic Code 39...
  • Page 21 Configure Your FuzzyScan Symbology Reading Control  Readable Bar Code Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Australian Post Readable Symbology Setting British Post Intelligent Mail barcode Japanese Post KIX Post Planet Code Postnet  If your application is known, you may select those known symbologies only to increase the reading speed and decrease the possibility of reading error. Furthermore, to add the “Symbology ID”...
  • Page 22 Configure Your FuzzyScan  Symbology Reading Control   Code 39/Code 32 Setting PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Disable Code 39 Code 39 Family Setting Enable Code 39 Select Standard Code 39 as primary format  Select Full ASCII Code 39 as primary format Select Code 32 (PARAF, Italian Pharmaceutical) as primary format Disable start/stop symbol transmission ...
  • Page 23 Configure Your FuzzyScan Symbology Reading Control   Code 39 Setting PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Level 0 Code 39 Security Level Level 1 Level 2  Level 3   Code 39 Security Level The scanner offers four levels of decode security for Code39 bar codes: Level 0: If you are experiencing misread of poorly-printed or serious out-of-spec.
  • Page 24 Configure Your FuzzyScan Symbology Reading Control  Codabar/NW-7 Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Disable Codabar Codabar Setting Enable Codabar  Select Codabar standard format  Select Codabar ABC format Select Codabar CLSI format Select Codabar CX format Disable start/stop symbol transmission ...
  • Page 25 Configure Your FuzzyScan Symbology Reading Control  UPC-A & UPC-E Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Disable UPC-A UPC Family Setting Enable UPC-A  Disable UPC-E Enable UPC-E  Disable UPC-E expansion  Enable UPC-E expansion Disable UPC standardization ...
  • Page 26 Configure Your FuzzyScan Symbology Reading Control  UPC-A & UPC-E Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Select UPC without supplement digits  UPC Supplement Setting Select UPC with only 2 supplement digits Select UPC with only 5 supplement digits Select UPC with 2/5 supplement digits Disable force supplement digits output ...
  • Page 27 Configure Your FuzzyScan  UPC/EAN Security Level The scanner offers three levels of decode security for UPC/EAN bar codes: Level 0: If you are experiencing misread of poorly-printed or out-of-spec. bar codes, especially in characters 1, 2, 7, and 8 in level 1, please select level 0. Selection of this security level may significantly impair the decoding ability of the scanner.
  • Page 28 Configure Your FuzzyScan Symbology Reading Control  EAN Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Disable EAN-13 EAN Setting Enable EAN-13  Disable EAN-8 Enable EAN-8  Disable EAN-8 expansion  Enable EAN-8 expansion Disable EAN-13 check digit transmission Enable EAN-13 check digit transmission ...
  • Page 29 Configure Your FuzzyScan  The Supplement Scan Voting is the number of times the same UPC/EAN with 2/5 supplement digits has to be decoded before it is transmitted. It is helpful when decoding a mix of UPC/EAN symbols with and without supplement digits. This function is effective when you select UPC/EAN with only 2 supplement digits, UPC/EAN with only 5 supplement digits or UPC/EAN with 2/5 supplement digits.
  • Page 30 Configure Your FuzzyScan Symbology Reading Control  EAN Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Level 0 UPC/EAN Security Level Level 1  Level 2 Only available for UPC-A & EAN-13 Disable all specific prefix supplement digital output  EAN Supplement Control Enable all specific prefix supplement digital output Enable 491 Supplement Digit Output...
  • Page 31 Configure Your FuzzyScan Symbology Reading Control  UCC Coupon Extended Code Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Disable UCC Coupon Extended Code  UCC Coupon Extended Code Enable UCC Coupon Extended Code  UCC Coupon Extended Code When UCC coupon extended code function is enabled, scanner decodes UPC-A barcodes starting with digit “5”, EAN-13 barcodes starting with digit “99”...
  • Page 32 Configure Your FuzzyScan Symbology Reading Control  IATA & Interleaved 2 of 5 Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Disable IATA  IATA Setting Enable IATA Select 15-digit fixed length IATA checking  Select variable length IATA Disable check digit verification ...
  • Page 33 Configure Your FuzzyScan Symbology Reading Control  Code 25 Family Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Disable Standard/Industrial 2 of 5  Code 25 Setting Enable Standard/Industrial 2 of 5 Disable Matrix 2 of 5  Enable Matrix 2 of 5 Disable China Postal Code ...
  • Page 34 Configure Your FuzzyScan Symbology Reading Control  Code 11 & Code 93 Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Disable Code 11  Code 11 Setting Enable Code 11 Disable check digit verification  Select 1-check digit verification Select 2-check digit verification Disable check digit transmission ...
  • Page 35 Configure Your FuzzyScan Symbology Reading Control  MSI/Plessey Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Disable MSI/Plessy  MSI/Plessey Setting Enable MSI/Plessy Select MOD 10 check digit  Select MOD 10-10 check digit Select MOD 11-10 check digit Disable check digit transmission ...
  • Page 36 Configure Your FuzzyScan Symbology Reading Control  Code 128 Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Disable Code 128 Code 128 Setting Enable Code 128  ISBT Concatenation Off  ISBT Concatenation On Default (01)  Code 128 Min.
  • Page 37 Configure Your FuzzyScan Symbology Reading Control GS1-128 Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Disable GS1-128 GS1-128 Setting Enable GS1-128  Default (01)  GS1-128 Min. Length 01-Maximum (2 digits) Scan 2 digits from the option code chart in Appendix; then FuzzyScan will terminate this selection automatically.
  • Page 38 Configure Your FuzzyScan Symbology Reading Control  UK/Plessey Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Disable UK/Plessey  UK/Plessey Setting Enable UK/Plessey Select UK/Plessey Standard Format  Select UK/Plessey CLSI Format Disable Convert X to A-F  Enable Convert X to A-F Disable check digit transmission ...
  • Page 39 Configure Your FuzzyScan Symbology Reading Control  Telepen Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Disable Telepen  Telepen Setting Enable Telepen Select Telepen Numeric mode  Select Telepen Full ASCII mode Disable check digit transmission  Enable check digit transmission Default (04) ...
  • Page 40 Configure Your FuzzyScan Symbology Reading Control  GS1 DataBar Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Disable GS1 DataBar (RSS-14) GS1 DataBar Setting Enable GS1 DataBar (RSS-14)  Disable GS1 DataBar Limited Enable GS1 DataBar Limited  Disable GS1 DataBar Expanded Enable GS1 DataBar Expanded ...
  • Page 41 Configure Your FuzzyScan Symbology Reading Control  Composite Codes, Codablock F PDF417/MicroPDF417 & Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Disable composite codes  Composite Codes Setting Enable composite codes UPC Composite Mode: UPC never linked  UPC Composite Mode: UPC always linked If UPC Composite Mode: UPC never linked is selected, UPC barcodes are transmitted whether MicroPDF417 symbol is detected or not.
  • Page 42 Configure Your FuzzyScan Symbology Reading Control  Code 16K & Code 49 Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Disable Code 16K  Code 16K Setting Enable Code 16K Default (01)  Code 16K Min. Length 01-Maximum (3 digits) Scan 3 digits from the option code chart in Appendix;...
  • Page 43 Configure Your FuzzyScan Symbology Reading Control  QR Code Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Disable QR Code  QR Code Setting Enable QR Code  Disable MicroQR Code Enable MicroQR Code  Disable QR Code Append Enable QR Code Append ...
  • Page 44 Configure Your FuzzyScan Symbology Reading Control  Data Matrix Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Disable Data Matrix Data Matrix Setting Enable Data Matrix  Disable Data Matrix Inverse Reading Enable Data Matrix Inverse Reading Auto Detect Data Matrix Inverse Reading ...
  • Page 45 Configure Your FuzzyScan Symbology Reading Control MaxiCode Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Disable MaxiCode  MaxiCode Setting Enable MaxiCode Default (01)  MaxiCode Min. Length 01-Maximum (3 digits) Scan 3 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
  • Page 46 Configure Your FuzzyScan Symbology Reading Control  Aztec Code Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Disable Aztec Code Aztec Code Setting Enable Aztec Code  Default (01)  Aztec Code Min. Length 01-Maximum (4 digits) Scan 4 digits from the option code chart in Appendix;...
  • Page 47 Configure Your FuzzyScan Symbology Reading Control  Australian Post, US Planet, US Postnet, British Post & Japan Post Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Disable Australian Post  Australian Post Setting Enable Australian Post Raw format Output  Numeric Encoding Output (N Encoding Table) Alphanumeric Encoding Output (C Encoding Table) Auto-discriminate Output (Combination C &...
  • Page 48 Configure Your FuzzyScan Symbology Reading Control  Netherlands KIX Code, Intelligent Mail & Korea Post Code Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Disable Netherlands KIX Code  Netherlands KIX Code Setting Enable Netherlands KIX Code Disable Intelligent Mail ...
  • Page 49 Configure Your FuzzyScan Keyboard Interface Control  Keyboard Layout (Language) Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code USA (QWERTY)  Keyboard Layout France (AZERTY) Germany (QWERTZ) United Kingdom - UK (QWERTY) Canadian French (QWERTY) Spain (Spanish, QWERTY) Sweden/Finland (QWERTY) Portugal (QWERTY) Norway (QWERTY)
  • Page 50 Configure Your FuzzyScan Keyboard Interface Control  Record Suffix, Preamble, Postamble, FNC1 Transmit & Caps Lock  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code None Record Suffix RETURN  SPACE ENTER (Numeric Key Pad) User defined character (1 character) 5, (00-7F) None ...
  • Page 51 Configure Your FuzzyScan  FNC1 Symbol Char. Transmit: When this function is enabled and the FNC1 is contained in scanned data, the scanner transmits the FNC1 to the host. Chart of theFNC1 is provided in Appendix- Keyboard Function Code Table. When the scanner interface is set to keyboard, the scan code is converted to corresponding key function before it is transmitted.
  • Page 52 Configure Your FuzzyScan Keyboard Interface Control  Delay Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code None  Intermessage Delay 1-99 (x5) msec. (2 digits) Scan 2 digits from the option code chart in Appendix; then FuzzyScan will terminate this selection automatically.
  • Page 53 Configure Your FuzzyScan Keyboard Interface Control  Emulation Setting, Key Pad Emulation & PROGRAM F_DEFAULT Upper/Lower Case Setting , Dollar Sign Control Family Code Selection Parameter Selection Option Code Enable ASCII 00-31 code as keyboard function code output  Function Key Emulation Ctrl-Output Refer to Appendix –...

  • Page 54: Serial Interface Control

    Configure Your FuzzyScan Serial Interface Control  Record Suffix, Preamble ,Postamble Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Disable STX/ETX transmission  STX/ETX Control Enable STX/ETX transmission STX/ETX are two characters used to indicate the starting and ending of the total data frame transmitted via serial interface.
  • Page 55 Configure Your FuzzyScan Serial Interface Control  Delay Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code None  Intermessage Delay 1-99 (x5) msec. (2 digits) Scan 2 digits from the option code chart in Appendix; then FuzzyScan will terminate this selection automatically.
  • Page 56 Configure Your FuzzyScan Serial Interface Control  Protocol, ACK/NAK Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code None (free running mode)  Handshaking Protocol RTS/CTS (hardware handshaking) ACK/NAK (software handshaking) Xon/Xoff (software handshaking) 3 times  NAK Retry Count 0~255 times (3 digits) Disable ACK Time-out Indication...
  • Page 57 Configure Your FuzzyScan Serial Interface Control Response Time-out Setting, Baud Rate, Data Frame PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code None 3 seconds Serial Response Time-out 200 mseconds 4 seconds 500 mseconds  5 seconds 800 mseconds 8 seconds 1 second 10 seconds 2 seconds...
  • Page 58 Configure Your FuzzyScan Wand/Laser Emulation Control (F & L Series) Output Polarity, Signal State, Margin/Module Time  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code High level (5Vdc) on Bar (low level on Space)  Output Polarity Low level (0Vdc) on Bar (high level on Space) Determine the output voltage level for both bar and space.
  • Page 59 Configure Your FuzzyScan Wand/Laser Emulation Control (F & L Series) Output Polarity, Signal State, Margin/Module Time  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Disable standard Code 39 emulation  Code 39/Code 128 Emulation Enable standard Code 39 skip emulation Enable standard Code 39 replace emulation Enable Full ASCII Code 39 emulation Enable Code 128 emulation...
  • Page 60 Configure Your FuzzyScan Operation Control (F & L Series)  Operation Mode Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Low Power mode Operation Mode Trigger mode  Presentation mode Alternative mode Flash mode Force mode Toggle mode Diagnostic mode Level mode ...
  • Page 61 Configure Your FuzzyScan Operation Control (F & L Series) Presentation Control, Scan Rate, Flash Duty  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Presentation mode  Presentation Control Flash mode Force mode Dynamic  Scan Rate Control Fixed 1/2 duty cycle ...
  • Page 62 Configure Your FuzzyScan Operation Control (L Series) Laser Imager, LED Illumination Control  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code & LED Illumination Delay Always on LED Illumination Control Intelligent Mode   Only available for L Series. 100 ms LED Illumination Delay 150 ms ...
  • Page 63 Configure Your FuzzyScan Operation Control (F & L Series)  Laser Aiming Control , 1D Barcode Reading Direction PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Disable Laser Aiming Control Enable  Only available for L Series. None ◆ 1D Barcode Forward-reading “S”...
  • Page 64 Configure Your FuzzyScan Operation Control (A Series) PROGRAM   F_DEFAULT Operation , Presentation and Illumination Control Family Code Selection Parameter Selection Option Code Low Power mode (Low power triggering) Operation Mode Trigger mode (External triggering)  Presentation mode (Auto detection) Alternative mode (Periodic power off) Force mode (Continued power on) Toggle mode (Repeat reading)
  • Page 65 Configure Your FuzzyScan Operation Control (A Series) PROGRAM   Aiming Control, Aiming & Decode Aiming Control Delay F_DEFAULT Family Code Selection Parameter Selection Option Code Regular Aiming Aiming Control Intelligent Aiming  Delay Aiming Control 200 ms Delay Aiming Time-out Control 400 ms ...
  • Page 66 Configure Your FuzzyScan Operation Control (A Series) PROGRAM   Center Alignment, Unique Bar Code Reporting F_DEFAULT  Unique Bar Code Reporting, Batch Reading Family Code Selection Parameter Selection Option Code Disable in Hand-Held Mode  Center Alignment Enable in Hand-Held Mode Disable in Hand-Free Mode ...

  • Page 67: Symbology Id Table

     [Cino ID Hex value] Length: 2 byte Please find Cino ID hex value from Symbology ID Table in appendix. Locate the Hex value for the symbology and scan the 2 digit hex values from the Option Code. Note: 99 is the universal number, indicating all symbologies.
  • Page 68 Configure Your FuzzyScan  [Code length] Length: 4 byte Specify what length of data output will be acceptable for this symbology. When you calculate the length, you must consider the whole data string which includes the programmed Preamble, Postamble, Scanned Data Length, Prefix/Suffix Symbol ID or AIM ID. Scan the four digit data length from the Option Code. Note: 40 characters is entered as 0040;...
  • Page 69 Configure Your FuzzyScan You would set up the Batch Reading rule with the following command line: [PROGRAM] [Batch Reading] [0301999941FF07999942FF09999943FF] [FIN] [END] The breakdown of the command line is shown below: The number of elements in the overall rule Code identifier of Code 128 9999 Code length that must match for Code 128, 9999 = all lengths Start character match for Code 128, 41h = “A”...
  • Page 70 Configure Your FuzzyScan The breakdown of the command line is shown below: The number of elements in the overall rule Code identifier of Code 128 0010 Code length that must match for Code 128 A-CODE128 sample length (9) plus Suffix Symbol ID (1) = 10 Start character match for Code 128, 41h = “A”...
  • Page 71 Configure Your FuzzyScan Operation Control (All Series)  Buzzer, Indicator & Vibrator Control  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Buzzer tone – mute Buzzer Tone Adjust Buzzer tone – low (Frequency 1.20 kHz) Buzzer tone – medium (Frequency 2.70 kHz) Buzzer tone –...
  • Page 72 Configure Your FuzzyScan Operation Control (A Series) PROGRAM  Buzzer Volume  F_DEFAULT Family Code Selection Parameter Selection Option Code Buzzer Volume Medium High   Buzzer Volume: Available firmware: A680 / A780 1.00.01 and above A770 rev. 1.00.21, rev. 2.00.04 and above A670 rev 1.00.03 and above...
  • Page 73 Configure Your FuzzyScan Operation Control (All Series) PROGRAM F_DEFAULT  Redundancy & 1D Code Inverse Reading  Family Code Selection Parameter Selection Option Code None Redundancy Level 1  Level 2 Level 3 Level 4 Level 5 To prevent potential miss reading. Disable ...
  • Page 74 Configure Your FuzzyScan Operation Control (All Series)  Reread Delay & Good Read Delay Control  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Reread Delay Disable (Double Scan Verification) Immediate time out  Short time out Medium time out Long time out Force verification None ...
  • Page 75 Configure Your FuzzyScan Operation Control (All Series)  Light Source On Time, Hands Free Time-out  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code Short  Light Source On Time Medium Long Extremely long Short  Hands Free Time-out Medium Long Extremely long...
  • Page 76 Configure Your FuzzyScan Operation Control (All Series)  Presentation Auto-Sense & Sensitivity  PROGRAM F_DEFAULT  & Sensitivity Settings Family Code Selection Parameter Selection Option Code Disable Presentation Auto-sense Enable  Level 1 Presentation Sensitivity Level 2 Level 3 Level 4 Level 5 ...

  • Page 77: Appendix

    Configure Your FuzzyScan Condensed DataWizard  Preamble, Postamble, Data Length & Symbol ID Trans.  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code None  Preamble 1-15 characters [00-7F], [FIN] Maximum 15-character input; scan “FIN” to terminate this selection. None ...
  • Page 78 Configure Your FuzzyScan Condensed DataWizard  Data Formatter Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code 2nd Option Code Disable  Formatter Control Select one bar code symbology (2 digits) automatic termination Select all bar code symbologies automatic termination Disable ...
  • Page 79 Configure Your FuzzyScan Condensed DataWizard  Data Verifier Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code 2nd Option Code Disable  Verifier Control Select one bar code symbology (2 digits) automatic termination Select all bar code symbologies automatic termination Disable ...
  • Page 80 Configure Your FuzzyScan Condensed DataWizard  Data Replacer Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code 2nd Option Code Disable  Replacer Control Select one bar code symbology (2 digits) automatic termination Select all bar code symbologies automatic termination Disable ...

  • Page 81: Condensed Datawizard

    Configure Your FuzzyScan Condensed DataWizard  Data Organizer Setting  PROGRAM F_DEFAULT Family Code Selection Parameter Selection Option Code 2nd Option Code Disable  Organizer Control Select one bar code symbology (2 digits) Automatic termination Select all bar code symbologies Automatic termination Disable ...
  • Page 82 Configure Your FuzzyScan 2D Bar Code Symbology Select a Bar Code Symbology QR Code MaxiCode You can select one or all types of bar code symbologies to MicroQR Code Aztec Code use Condensed DataWizard for advanced transmission DataMatrix Chinese Sensible Code arrangement.
  • Page 83 Configure Your FuzzyScan Programming Procedure [Data Verifier]  Scan “Program” to enter the programming mode.  Scan “Verifier Control” and set bar code symbology to Application Example “48” (Interleaved 2 of 5). If your bar code label is a 16-digit Interleaved 2 of 5 which ...
  • Page 84 Configure Your FuzzyScan [Data Replacer]  Scan “Replacer Control” and set bar code symbology to “48”. Scan “1st Replacement” and set the identified position to  “00”, then replaced character to “41” (Hex Code of A). [Data Organizer]  Scan “Organizer Control” and set bar code symbology to “48”.
  • Page 85 Appendix Symbology ID Table Each AIM Code Identifier contains the three-character string ]cm where: ] = Flag Character; c = Code Character; m = Modifier Character 1D Symbology ID Table Cino ID AIM ID Cino ID AIM ID Code Family...
  • Page 86 Appendix 2D Symbology ID Table Cino ID AIM ID Cino ID AIM ID Code Family Primary Format Code Family Primary Format Code Modified Char. Code Modified Char. Value Char. Char. Value Char. Char. QR Code QR Code British Post British Post...

  • Page 87: Keyboard Function Code Table

    Appendix Keyboard Function Code Table ANSI ASCII Key Function Ctrl Output ANSI ASCII Key Function Ctrl Output RESERVED Ctrl + @ Ctrl + P CTRL (Left) Ctrl + A Ctrl + Q ALT (Left) Ctrl + B Ctrl + R SHIFT Ctrl + C Ctrl + S...

  • Page 88: Ascii Input Shortcut

    Appendix ASCII Input Shortcut To configure the user definable parameters of FuzzyScan via HEX/ASCII Reference Table programming menu, FuzzyScan will ask you to scan your desired ASCII value in HEX form. You have to refer to the “HEX/ASCII Table” for details. SPACE Example: "...

  • Page 89: Host Interface Quick Set

    Appendix Host Interface Quick Set RS232 Serial PS/2 (DOS/V) KBW Standard Mode USB HID Standard Mode Keyboard Replacement PS/2 (DOS/V) KBW Turbo Mode USB HID Turbo Mode USB HID Legacy Mode USB Com Port Emulation...

  • Page 90: Operation Mode Quick Set

    Appendix Operation Mode Quick Set (F & L Series) Low Power (Low power trigger) Force (Continued power on) Alternative (Periodic power off) Trigger (External triggering) Toggle (Repeat reading) Flash (Pulse driven reading) Presentation (Auto sensing) Diagnostic (Test reading) Level (Auto power off)
  • Page 91 Appendix Operation Mode Quick Set (A Series) Low Power (Low power trigger) Force (Continued power on) Alternative (Periodic power off) Trigger (External triggering) Toggle (Repeat reading) Level (Auto power off) Presentation (Auto sensing) Diagnostic (Test reading) Multiple Read...

  • Page 92: Option Codes

    Appendix Option Codes Abort FIN (Finish) END (Exit)

  • Page 93: System Commands

    Appendix System Commands PROGRAM System Information List (Enter Programming Mode) (SYSLIST) Save User Default FIN (Finish) PowerTool Host Link User Default Factory Default (Exit Programming Mode) Master Default  Factory Default: After scanning” Factory Default” command, all parameters will be returned to factory default value. ...
  • Page 94 Appendix...
