Fisher 3620J Series Instruction Manual

On page 18, cross out table 6 at the bottom of the
page. Next to this table write a note that says, "See
table 6 on the errata sheet dated October 1999."
Use the following table when selecting a range spring
for the Type 3621JP Positioner.
Table 6. Type 3621JP Positioner Range Spring Selection and
Coarse Span Adjustment
Valve Valve
16 mA
Travel
I Inches h
Range Hole
(mm)
Spring Number
7/16 (11) Blue 4
9/16 (14) Blue 4
3/4 to 2
Blue 3
(19 to 51)
2 to 4
(51 to Blue 3
(3)
102)
1. For positioners mounted on Type 585, 585R, 585C, and 585CR actuators.
2. This table is only valid for the valve travel and range spring combinations listed.
Contact the Fisher sales office or sales representative or the factory for travels or
input spans not shown for the valve travel/range spring combinations.
3. For Type 585, size 100 only.
EFisher Controls International, Inc. 1999; All Rights Reserved
Fisher, Fisher-Rosemount, and Managing The Process Better are marks owned by Fisher Controls International, Inc. or Fisher-Rosemount Systems, Inc.
The contents of this publication are presented for informational purposes only, and while every effort has been made to ensure their accuracy, they are not to be construed as warranties or guarantees, express or
implied, regarding the products or services described herein or their use or applicability. We reserve the right to modify or improve the designs or specifications of such products at any time without notice.
For information, contact Fisher Controls:
Marshalltown, Iowa 50158 USA
Cernay 68700 France
Sao Paulo 05424 Brazil
Singapore 128461
Printed in U.S.A.
Errata Sheet
3610J and 3620J Series Positioners Instruction Manual,
Form 5208, July 1999
(1)
(2)
INPUT SPAN
5.3 mA 8 mA
Range Hole Range Hole
Spring Number Spring Number
Red 1 Red 2
Red 1 Red 2
Yellow 1 Yellow 2
Yellow 1 Yellow 2
for
3610J and 3620J Series
October 1999
