POINT I/O Common Terminal Module and
Voltage Terminal Module
Catalog No. 1734-CTM, Series C, and 1734-VTM, Series C
Module Locking Mechanism
Module Wiring Diagram
Mechanical keying
(orange)
The Wiring Base Assembly consists of Mounting Base, 1734-MB,
and Removable Terminal Block, 1734-RTB or 1734-RTBS.
Allen-Bradley Re
DIN Rail
Locking
Screw
(orange)
Interlocking
Side Pieces
Mounting Base
Installation Instructions
Insertable I/O Module
RTB Removable Handle
Removable Terminal
Block (RTB)
Publication
1734-IN024A-EN-E - March 2005
31538-M
Advertisement
Table of Contents
Related Manuals for Allen-Bradley POINT I/O 1734-CTM
Summarization of Contents
Important User Information
Safety Information Icons
Explains symbols used for warnings, important notes, attention, shock, and burn hazards.
Hazard Information and Module Overview
Explosion Hazard
Details explosion hazards and precautions for disconnecting equipment and substitution of components.
About the Modules
Overview of the purpose and functionality of the POINT I/O Common Terminal Module and Voltage Terminal Module.
Installation Procedures
Install the Mounting Base
Step-by-step guide for mounting the base unit onto a DIN rail.
Install the Module
Instructions for correctly installing an I/O module into the mounting base, including keying.
Module Installation Safety Warning
Warning regarding electrical arcs during module insertion/removal when power is on in hazardous locations.
Terminal Block Installation
Install the Removable Terminal Block (RTB)
Procedure for inserting the Removable Terminal Block (RTB) into the wiring base assembly.
Removal Procedures
Remove a Mounting Base
Detailed steps for safely removing a mounting base and its associated modules.
Module Removal Safety Warning
Warning about electrical arcs during module removal when power is on, similar to installation.
Module Wiring Overview
1734-VTM and 1734-CTM Wiring Diagrams
Illustrates basic wiring configurations for Voltage Terminal Module and Common Terminal Module.
Input Wiring Details
Sink Input Wiring
Diagrams showing how to wire sink inputs for various modules like 1734-IB8, 1734-VTM, and 1734-CTM.
Input Wiring Details
Source Input Wiring
Diagrams detailing how to wire source inputs for 1734-IV8, 1734-VTM, and 1734-CTM modules.
Output Wiring Details
Source Output Wiring
Wiring diagrams for connecting source outputs to loads using 1734-OB8 and 1734-CTM.
Sink Output Wiring
Wiring diagrams for connecting sink outputs to loads using 1734-OV8 and 1734-VTM.
General Wiring Context
General Purpose Wiring Diagram
A schematic illustrating the general wiring connection between an adapter, power supply, and modules.
Safety Approvals and Hazardous Location Operation
North American Hazardous Location Approval
Details the approval status for North American hazardous locations and associated conditions.
Hazardous Location Operation Precautions
Outlines safety precautions for operating equipment in hazardous locations, including explosion risks.
Product Specifications
Technical Specifications and Certifications
Comprehensive technical details, environmental conditions, wiring terminations, and product certifications.
Support and Returns
Rockwell Automation Support
Information on accessing technical support, documentation, and online resources from Rockwell Automation.
Installation Assistance and Product Returns
Contact information for installation help and procedures for returning products that are not functioning.
